RGB LASER SHOW SYSTEM
User's Manual
Read this manual before using. Do not attempt to open the housing or repair
this device by yourself without contact us!
DMX Address Chart General instructions
This chart lists the DMX dipswitch setting for DMX address 1 through 511. Follow the Unpacking:
instructions below to configure fixture dipswitches with you desired DMX address. Thank you for purchasing this product. Please read user guide for safety and before using
DMX Address Quick Reference Chart
the product. Keep this manual for future reference. This product can create perfect laser
programs and effects since it has passed a series of strictly tests before delivery. Please check
the attachments listed on the page after opening the carton. Immediately upon receiving
a fixture, carefully unpack the box. Check the box contents to ensure that all parts are present
and that they are in good condition. If any part appears damaged from shipping, or if the
box shows signs of mishandling, notify the shipper immediately. In addition, retain the box
and all the packing material for inspection.In any event, save the carton and all packing material
because, in case that you have to return the fixture to the factory, you will have to do so in its
original box, with its original packing.
1. Laser Light: 1PCS
2. Power Cable: 1PCS
3. User Guide: 1P CS
Safty Notice:
Please read the following notes carefully because they include important safety information
about the installation,usage and maintenance of this product. It is important to read all these
notes before starting to work with this product.
Page 12 Page 1
Lasers can be hazardous and have unique safety consideratio ns. Permanent eye injury and
blindness is possible if lasers are used incorrectly . Pay close attention to each safety REMARK and
WARNING statement in the user manual. Read all instructions careful
There are no user serviceable parts inside the light. Any reference to servicing this unit you
may find from now on in this User Manual will only apply to properly C we certified
technicians. Do not open the housing or attemp t any repairs unless you are o
Please refer to all applicable local codes and regulations for proper
installation of the light.
Keep this manual for future consultation. If you sell the light to another user,
make sure that they also receive this manual.
DipSwitch Position DMX Address
DipSwitch Position
Troubleshooting
1. If the power supply indicator doesn't light up and the laser doesn't work, please
check the power supply, the input voltage and the fuse.
2. In Stand-Alone operation, if the power supply indicator is light up and sound
active indicator isn't light up, but the laser is shut off doesn't work.
A. Because sound is too small make for laser shut off in sound active, please
increase the music volume or increase audio sensitivity with sensitivity knob,
please check as below.
B. Please check if unit has been set up in slave mode, then set up in master mode.
3. In Master-Slave operation, slave unit don't function, please check as below.
A. Make sure to there's only one master in the chain, and the others are set in slave mode.
B. Make sure to control the unit without DMX console controlling.
C. Make sure to take a good quality power cable and connection.
4. In DMX mode operation, the laser is OFF and the DMX signal indicator is
unlighted, please check as below.
A. Make sure to set up the DMX mode.
B. Make sure to have a good connection.
5. In DMX operation, the unit can’t be controlled by the DMX console, but the DMX signal
indicator is flashing, please make sure the DMX console and unit have the same channel.
6. If the unit is fail, please turn off the unit, then turn on again after 5 minutes.
Warranty Warnings:
1. Damages caused by the disregard of this user manual are not subject to Warranty.
The dealer will not accept liability for any
2. Please consider that unauthorized modifications on the device are forbidden due to
safety reasons. Please note that damages caused by manual modifications on the
device or unauthorized operation by unqualified persons are not subject to warranty.
3. If this device will be operated in any way different to the one described in this
manual, it may suffer damages and the guarantee becomes void. Furthermore, any
other operation may lead to dangers like short-circuit, burns electric shock, etc.
After trying the above solution you still have a problem, please contact your dealer
or our company for service.
Page 2 Page 11
Avoid direct eye exposure to the light source while the fixture is on. Always
disconnect the light from its power source before servicing. Always connect the
light to a grounded circuit to avoid the risk of electrocution.
This product is for indoor use only! Use only in dry locations. Keep this device
away from rain and moisture, excessive heat, humidity and dust. Do not allow
contact with water or any other fluids, or metallic objects.
Make sure there are no
flammable materials close to
the fixture(s) while operating.
Please prevent this light
away from electrical shock
When hanging this fixture, always secure it to a fastening device using a
safety cable (not provided).
Always make sure that you are connecting the light to the proper voltage, as per
the specifications in this manual or on the product's stick er. Never connect the
light to a dimmer pack. Make sure that the power cable is not cracked, crimped or
damaged. Ne
The maximum ambient temperature (Ta) is 104 F (40 C). Do not operate
the fixture at a higher temperature. In case of a serious operating problem,
stop using this product immediately!
Use cleaning tissue to remove the dust absorbed on the external lenses
periodically to optimize light output.
Do not remove or break the warranty label, otherwise it void the
warranty.
Always replace with the exact same type fuse, replacement with anything
other than the specified fuse can cause fire or electric shock and damage
your unit, and will void your manufactures warranty.
There are no serviceable parts in the light. Please have all servicing and
adjustments made by a qualified service engineer.
Don’t throw this product away just as
general trash, please dispose of this
product following the abandon electronic
product regulation in your country.
To protect the environment,
recycle packing material
wherever possible.
Power
110V 240V
Ground
ch8 value
Color
ch8 value
Color
ch8 value
Color
ch8 value
Color
Laser Safty Warnings
6～7
yellow/Y
70～71
PCR
134～135
WPYB
198～199
WPCYR
8～9
blue/B
72～73
PCG
136～137
PCYB
200～201
WPCYG
10～11
red/B
74～75
PYB
138～139
PCYR
202～203
PCYBR
12～13
green
76～77
CYB
140～141
PCYG
204～205
PCYBG
Caution
14～15
wP
77～79
CYR
142～143
PCBR
206～207
PCBRG
* Avoid direct eye contact with laser light. Never intentionally expose your eyes or others to
16～17
wC
80～81
CYG
144～145
PCBG
208～209
CYBRG
direct laser radiation.
18～19
wY
82～83
CBR
146～147
CYBR
210～211
CYBRW
*This laser product can potentially cause instant eye injury or blindness if laser light directly
20～21
PC
84～85
CBW
148～149
CYBG
212～213
CYBGW
strikes the eyes.
22～23
PY
86～87
YBR
150～151
CYRG
214～215
YBRGW
*It is illegal and dangerous to shine this laser into audience areas, where the audience or other
24～25
PB
88～89
YBG
152～153
CYRW
216～217
YBRGP
personnel could get direct laser beams or bright reflections into their eyes.
26～27
CY
90～91
YBW
154～155
CYRB
218～219
YBRWP
*It is a US Federal offense to shine any laser at aircraft.
28～29
CB
92～93
YCW
156～157
YBRG
220～221
BRGWP
30～31
CR
94～95
YPR
158～159
YBRW
222～223
BRGWC
NON-INTERLOCKED HOUSING WARNING
32～33
YB
96～97
BRG
160～161
YBRP
224～225
BRWPC
*This unit contains high power laser devices internally. Do not open the laser housing, due to
34～35
YR
98～99
BRP
162～163
YBWC
226～227
RGWPC
potential exposure to unsafe levels of laser radiation. The laser power levels accessible if the
36～37
YG
100～101
BRW
164～165
YBPC
228～229
RGWPY
unit is opened can cause instant blindness, skin burns and fires.
38～39
BR
102～103
BGP
166～167
BRGW
230～231
RGWCY
40～41
BG
104～105
BGW
168～169
BRGP
232～233
GWPCB
Installation
42～43
BW
106～107
RGC
170～171
BRGC
234～235
GWPYB
44～45
RG
108～109
RGP
172～173
BRWP
236～237
GPCYR
46～47
RP
110～111
RGW
174～175
BRWC
238～239
WPCYBR
48～49
RW
112～114
RWC
176～177
RGWP
240～241
PCYBRG
50～51
GC
114～115
RWY
178～179
RGWC
242～243
CYBRGW
52～53
GP
116～117
GWC
180～181
RGWY
244～245
YBRGWP
54～55
GW
118～119
GWY
182～183
RGPC
246～247
BRGWPC
*Laser effects projected 3 meters (9.8 ft) above the audience are eye safe. A survey should be
56～57
WPC
120～121
GPY
184～185
RGPY
248～249
RGWPCY
taken to assess the likelihood of any reflective surfaces (such as high windows, chrome bars
58～59
WPY
122～123
GBC
186～187
GWPY
250～251
GWPCYB
etc) bouncing stray beams back down into the audience.
60～61
WPB
124～125
GRY
188～189
GWPB
252～253
WPCYBRG
*Using a fastening clamps on the light and tight to the ceiling in a strong hook..
62～63
WPR
126～127
WPCY
190～191
GWPR
254～255
moving WPCYBRG
*Make sure its correct power output and plug the power cable to the wall socket.
1. There are 52 static patterns, the sizes of the patterns that DMX value is 170 previous are
* Power must be in earth! Power on the light.
adjustable, the following irregular patterns are non-adjustable. There are 52 dynamic pat- * Do not shoot the beams to the audience!
terns, whose sizes are non-adjustable. *Do not look direct into the laser aperture once the laser light is ON. Please pay attention to
2.Only circle pattern has color segment function, it needs to operate with both CH8 and CH9. the Laser Danger Warning Label!
Page 10 Page 3
AVOID EYE DIRECT
CONTACT!
Potential laser injury hazard exists with this product! Read these Instructions carefully,
which include important information about installation, safe use and service!
Technical Specification
CH2 Parameter Chart For Patterns Selection
1. Voltage: bi-voltage 110V -220V-250V AC, 50HZ-60HZ/ Fuse: 2A/250V
2. Rated Power: 30W
3. Laser:
Color Wavelength Power output
Red 650nm 200mW
Green 532nm 50mW
Blue 470nm 150mW
4. Laser class: Class IIIB
5. Working Modes: DMX, Sound Active, AUTO, Master-Slave
6. DMX Control Channel: 7 channels
7. Graphics & Effects: more than 100 patterns, over 300 effects
8. Interface: 3 pins XLR jack for DMX or Maser-Slave linking
9. inner box: 310*245*170(0.013m³), carton: 515*330*382(0.065m³), 4pcs/carton
10. N.W.: 1.8kg, G.W: 2.4Kg
Features
1. Seven-color laser light
Includes seven-color effects as red, green, blue, yellow, cyan, purple,and white. It can
combine to create rich and dynamic patterns at the same time, more than 100 laser patterns,
over 1000 laser effects.
2. Various working modes
Includes four working modes as DMX, Sound Active, AUTO and Master-Slave Control
mode, different working modes has different program for different applications.
3. DMX control
The unit has 9 channels to control in DMX mode. The unit has BLACK OUT function.
The uint will shut OFF if no DMX512 signal.
4. Master-Slave function
The system allow link many units (as slave unit) together to doing synchro job without
console in sound active or AUTO mode.
5. LED indicating and shut-off function
CH8 Parameter Chart For Color Selection
In sound active mode, the unit's panel has LED indicating for sound active. The unit will
ch8 value
Color
ch8 value
Color
ch8 value
Color
ch8 value
Color
shut off after 8 seconds when the music stops.
0～1
white/W
64～65
WPG
128～129
WPCB
192～193
GWCY
6. DPSS Laser
2～3
purple/P
66～67
PCY
130～131
WPCR
194～195
GWCB
Use Diode-Pumped Solid State green, red blue lasers, stable output and long working life.
4～5
cyan/C
68～69
PCB
132～133
WPCG
196～197
WPCYB
Page 4 Page 9
Static patterns Dynamic patternsDMX value St atic patterns
circle to big
130～134
Dynamic patterns DMX value
triangle 2
two hori dot line move
5～9
empty circle empty circle to big
135～139
dot triangle 2 vertical line move
0～4
one circle
10～14
dot circle dot circle to big
140～144
square
two vert-dot line move
15～19
scan circle scan circle to big
145～149
chiasma line vert-dot line move
chia-dot line
two vertical line move
dot square square extend
20～24
two circle
25～29
three circle empty circle roll
155～159
circle roll
150～154
30～34
four circle dot circle roll
160～164
many hori-line square turn
35～39
two emp-circle circle turn
165～169
rectangle dot square extend
dot rectangle pentagon extend
many vert-line pentagon turn
40～44
two dot circle
45～49
hor-extend line circle jump
175～179
dot circle to add
170～174
50～54
hori-shrink line scan circle extend
180～184
pentagon 1 wave turn
55～59
hori-flex line circle flash
185～189
tetragon 1 line scan
tetragon 2 dot line scan
pentagon 2 dot wave turn
60～64
horizontal line
65～69
hori-dot line two circle turn
195～199
empty circle roll
190～194
70～74
vertical line four circle turn
200～204
wave line 2 sine wave
75～79
hori-dot line diagonal jump
205～209
pentagon 3 wave flowing
wave line 1 dot wave flowing
wave line 3 dot sine wave
80～84
45° diagonal
85～89
dot diagonal dot sector to big
215～219
sector to big
210～214
90～94
two hori-line diagonal move
220～224
welcome pentagon star 2 turn
95～99
two hori-dot line
dot diagonal move
225～229
wave dot line tetragon turn
spirality line pentagon star 1 turn
horizontal dot square dot jump
100～104
two vert-line
105～109
two vert-dot line
short sector round
235～239
long sector round
230～234
110～114
V line three line round
240～244
square dot V pattern move
115～119
V dot line hori line move
245～249
vertical dot bird fly
many dot 1 many dot jump 1
many dot 2 many dot jump 2
120～124
triangle 1
125～129
dot triangle 1 two hori line move 255
hori dot line move
250～254
Mixed white: 400mW
DMX address calculation
Front/Rear Panel
For DMX mode, DMX address from #1 to 9# dipswitches must be set, the address is set
from 1 to 511. Each dipswitch represents a binary value.
Dipswitch Value Dipswitch Value
＃1
1
＃6
32
＃2
2
＃7
64
＃3
4
＃8
128
＃4
8
＃9
256 Front Panel Figure
＃516 ＃10
DMX, Set to "0" 1. Laser Aperture 2. Sound Active Microphone
One unit has 5 channels, so each unit must be assigns 5 channels at least. We may 3. Sound Active Indicator:Blue 4. Power Indicator:Red
assign 8 channels for one unit, then DMX address = 8*N + 1, N=0, 1, 2, 3 …… Example,
One loop address=1, two loop address=9, three loop address=17, four loop address=25
Loop Address Binary Dipswitches
1 1 100000000 ＃1
2 9 100100000 ＃1+#4
3 17 100010000 ＃1+#5
4 25 100110000 ＃1+#4+#5
The dipswitches setting for DMX address see the " DMX Address Quick Reference Chart ". Rear Panel Figure
DMX Control
1. Power Jack 2. Cooling Fan
The system only accepts the DMX512 signal of international standard to control the system.
3. Audio Sensitivity Knob 4. DMX Signal Indicator: Green
DMX Control Parameter Chart
5. Dipswitches: Function Setting 6. DMX or Linking Jack
Close, laser OFF
Function & Setting
Static patterns of DMX mode
Dynamic patterns of DMX mode
Sound Active
Sound active mode The change of the laser pattern is controlled by sound, that is, the rhythm of the sound
Auto mode control the effect of the changing laser pattern. Turning the sensitivity knob in the
Pattern selection 52 static/dynamic patterns clockwise direction to increase the fixture’s sensitivity to sound, the knob in the counter
Position-X Adjust position-X clockwise direction to decrease. The laser diode will automatically turn off after 8
Position-Y Adjust position-Y seconds when the music stops.
Scanning speed 0 is speedy, 255 is slow
Dynamic pattens 0 is speedy, 255 is slow, has ten
AUTO
play speed grade speed
Auto cycles the built-in programs without being controlled externally. It has no laser OFF.
Static pattern size 0 is small, 255 is big
Color Selection RGBYCPW, 7 colors combinered The mode allows a single unit to react to the beat of the music in the master mode.
Color Segment Divide into 1 to 51 segment 1. Install the units in a suitable position (laying or appending).
Page 8 Page 5
Channel Function Value Description
CH1
Mode
0～49
50～99
100～149
150～199
200～255
0～255
CH5
0～255
CH2
0～255
CH3
0～255
CH8
0～255
CH9
0～255
CH6
0～255
CH7
0～255
CH4
2
3
4
1
1
5
6
2
3
4
2. Set dipswitch to select Sound Active or AUTO mode. 2. Use standard XLR microphone cable chain your units together via the XLR connector
3. Turn on the unit power, the unit begins reset, then the unit begins working. on the rear of the units. For longer cable runs we suggest a terminator at the last fixture.
4. The unit will react to the low frequencies of music via the internal microphone. 3. Assign a DMX address to each the unit using dipswitches, see the "DMX Address
Adjust the audio sensitivity knob on the back of the unit to make the unit more or less Quick Reference Char".
sensitive in sound active.The panel has LED indicating for sound active.
Master-Slave Operation
This mode will allow you to link up to 32 units together without controller.
1. Install the units in a suitable position (laying or appending).
2. Choose a unit to function as Master mode, set dipswitch to select Sound Active or
AUTO mode. The others must be set to Slave mode, set dipswitch to select Slave mode.
3. Use standard XLR microphone cable chain your units together via the XLR connector
on the rear of the units. For longer cable runs we suggest a terminator at the last fixture. 4. Turn on the all units' power, the units begins reset, then the unit begins working.
Cabling must have a male XLR connector on one end and a female XLR connector on the other end.
5. Use DMX console to control your units.
Notes:
1. DMX console can not be used in Master-Slave operation (Sound Active or AUTO mode ).
2. There should be only one master unit in Master-Slave operation.
DMX Control
The system only accepts the DMX512 signal of international standard to control the
system mode, the laser beam ON /OFF, running direction, running speed and twinkle
speed etc.
Caution: Do not allow contact between the common and the ficture's chassis ground.
Function setting
Grounding the common can cause a ground loop, and your fixture may perform erratically. Uses dipswitches to assign a unit’s function: DMX/slave, or sound active, or AUTO mode.
Test cables with an ohm meter to verify correct polarity and to make sure the pins are For the unit is DMX mode, set the DMX address using dipswitch. Each dipswitch
not grounded or shorted to the shild or each other. represents a binary value. See the “Function chart”.
4. Turn on the all units' power, the units begins reset, then the unit begins working.
The slave units will react the same as the master unit.
5. The units will react to the low frequencies of music via the internal microphone.
Adjust the audio sensitivity knob on the back of the master unit to make the unit more
or less sensitive in sound active.The panel has LED indicating for sound active.
Universal DMX Operation (DMX mode)
This mode allows you to use universal DMX-512 console to operate.
1. Install the units in a suitable position (laying or appending).
Page 6 Page 7
1：MASTER: SOUND/AUTO/DMX
2：SLAVE
DMX Signal
Light No 1
Light No 2
Light No 3
Light No ….
……...
2：SLAVE
Built-In Program Function Chart
Loading...
