Kompernass SILVERCREST KH 2352 User Manual

4A

RADIO

KH 2352

KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM

www.kompernass.com

ID-Nr.: KH2352-08/08-V1

RADIO

Operating instructions

RADIO KOMPAKTOWE

Instrukcja obsługi

KOMPAKT RÁDIÓ

Használati utasítás

KH 2352

A

q

s

w
e
r
t

y
u
i

BC

o

a

D

d

f

g

h
j

CONTENT PAGE

Intended Use 2
Technical Data 2
Safety information 2
Operating Elements 4
Commissioning 5

Inserting the back-up batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Additional audio device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Utilisation 6

Radio/AUX operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Setting the alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Cleaning 7
Disposal 7
Warranty and Service 7
Importer 7

Read the operating instructions carefully before using the appliance for the first time and preserve this
booklet for later reference. Pass the manual on to whomsoever might acquire the appliance at a later date.

- 1 -

RADIO KH2352

Intended Use

This device is intended for the reception of FM/ AM
radio transmissions as well as for the playback of
audio signals from external devices. This device is
intended for use only in domestic environments.
It is not suitable for use in commercial or industrial
applications.

Technical Data

This consumer electronics device, being in con­formity with their fundamental requirements
and directions, complies with the relevant re­gulations of both the EMC Guidelines 2004/
108/EC and the Guidelines for Low Voltage
devices 2006/95/EC.

Power supply: AC 230 V ~ 50 Hz
Power consumption: 11 Watt
Standby: 2.7 W
Output level: 4 Watt RMS
Operating temperature range: +5°— +35°C
Humidity: 5 — 90%

(no condensation)
Measurements
(L x W x H): 145 x 235 x 127 mm
Weight : ca. 980 g
Protection class: II /

Audio input AUX:

3,5 mm Stereo jack plug socket

Notice

The technical data of the device makes possible an
adjustable frequency range from 87,5 - 108 MHz
resp. 522 – 1620 kHz. In some countries, different
national regulations may apply to the assigned radio
frequency ranges. Please note that information received
outside of the assigned radio frequency ranges may
not be exploited, passed on to third parties or other­wise misused.

Safety information

• This device is not intended for use by individuals
(including children) with restricted physical, physio­logical or intellectual abilities or deficiences in
experience and/or knowledge unless they are
supervised by a person responsible for their safety
or receive from this person instruction in how the
device is to be used.

• Children should be supervised to ensure that
they do not play with the device.

• Keep batteries well away from children. Children
can put batteries into their mouths and swallow
them. If a battery is swallowed medical assistance
must be sought immediately.

To avoid potentially fatal electric shocks:

• Connect the device only to correctly installed and
earthed mains sockets. Ensure that the rating of
the local power supply tallies completely with the
details given on the rating plate of the device.

• Ensure that the power cable never becomes wet
or damp during operation. Lay the cable so that
it cannot be trapped or otherwise damaged.

Radio frequency range:

Radio: MW (AM): 522 – 1620 KHz

VHF (FM): 87.5 - 108 MHZ

- 2 -

• Always grasp the power cable by the plug. Do
not pull on the cable itself and never touch the
power cable with wet hands, this could result in
a short circuit or you receiving an electrical
shock.

Information regarding the handling
of batteries

For retention of the time settings, the device requires
batteries. For the handling of batteries please observe
the following:

• Arrange for defective power plugs and/or cables
to be replaced at once by qualified technicians
or our Customer Service Department.

• Arrange for Customer Services to repair or re­place connecting cables and/or devices that are
not functioning properly or have been damaged.

• Only use the device in dry environments.

NEVER submerse the device in water.
Wipe it only with a slightly damp cloth.

• Ensure that liquids or foreign objects are never
able to penetrate into the device.

• Do not place water-filled receptacles (e.g. flower
vases) on the device.

• Position the device close to an electrical power
socket. Ensure that the wall socket is easily ac­cessible at all times.

• To avoid the risks of tripping, do not use an
extension cable. In the event of danger, the plug
must be quickly and easily accessible.

• Do not open the housing or attempt to repair the
device yourself. Should you do so, device safety
can no longer be assured and the warranty will
become void. Repairs are to be carried out ex­clusively by a specialist firm or the service centre.

Notice regarding separation from
mains-power

The STANDBY/ON switch for this device does NOT
completely separate it from the mains power
source. Additionally, the device consumes power
when in standby-mode. To completely separate
the device from mains power, the plug MUST be
removed from the power socket.

Risk of explosion!

Do not throw batteries into a fire. Do not re­charge the batteries.

• Never open batteries, never solder or weld
batteries. The risk of explosions and injuries
exists!

• Regularly check the condition of the batteries.
Leaking batteries can cause damage to the
device.

• If you do not intend to use the device for an
extended period, remove the batteries.

• In the event of the batteries leaking acids, wear
protective gloves when removing the batteries.

• Clean the battery compartment and the battery
contacts with a dry cloth.

To avoid the risks of fire or injury:

• Do not place candles or other open fire sources

on the device.

• Do not use the device in the vicinity of hot surfaces.

• Do not place the device in locations exposed to

direct sunlight. If you do, it may overheat and be­come irreparably damaged.

• To prevent heat build up, place the device at a

location with adequate ventilation .

• Never cover the ventilation openings!

• Avoid any additional heat build up, e.g. direct

sunlight, heaters, other devices, etc.

• Keep children away from the connecting cable and

the device. Children frequently underestimate the
dangers of electrical devices.

• Provide for a safe location for the device.

- 3 -

• Do not operate the device if it has sustained a
fall or is damaged. Arrange for the appliance
to be checked and/or repaired by qualified tech­nicians.

• Keep batteries away from children. Children can
put batteries into their mouths and swallow them.
If a battery is swallowed immediately seek medical
assistance.

Thunderstorm warning!

Before a storm and/or a thunderstorm with a risk
of lightning, please separate the device from the
electrical power source!

Notice regarding electrical power
surges (EFT / electrical fast transient)
and electrostatic discharges:

In a case of malfunction due to an electrical
fast transient (power surge) and/or electrosta­tic discharge, the device must be returned to
default settings in order to re-establish normal
operation. Possibly the power supply must be
separated and then reconnected.

Operating Elements

A Front panel

Loudspeaker

q

Display

w

Button AL.SET: Setting the alarm time

e

Button TIME SET: Setting the time

r

Button STANDBY/ON: Device on/off switch

t

Button AL.ON/OFF: Switch alarm on/off

y

Button MIN: Adjust minutes

u

Button HOUR: Adjust hours

i

B Right side

Tuning regulator: Adjusting the frequency

o

C Upper side

VOLUME/BUZZ: Sound volume

a

adjustment,
BUZZER alarm tone

AUX/AM/FM: Select radio waveband

s

or external audio input

POWER: Operation LED

d

Note:

This device is equipped with non-slip rubber pads.
As furniture surfaces may be made of a variety
of materials and are treated with many different
types of cleaning agents, it cannot be completely
ruled out that some substances contain ingre­dients which may corrode the rubber rests and
soften them. If possible place an anti-slip materi­al under the pads of the device.

D Rear

Telescope aerial

f

AUX: Audio input

g

Battery compartment

h

Power cable

j

- 4 -

Commissioning

Unpacking the device

• Remove all packaging material.

Attention!

Do not permit small children to play with plastic
packaging. There is a risk of suffocation!

Check the items supplied

Whilst unpacking, check that all of the following
items are available to you:

- Compact radio

Placement

• Place the radio on a level and horizontal surface.

Inserting the back-up batteries

With back-up batteries fitted, the adjusted timings
will not be lost in the event of a power failure.
For this, you require two 1.5V batteries of the type
Micro AAA/R03 (not supplied).

1. Open the flap of the battery compartment on the
rear of the radio.

2. Insert the batteries. Make sure the polarities are

correct.

3. Replace the flap of the battery compartment.
The flap must audibly engage.

Note:

When the device is separated from mains power
the time is not displayed, however, the internal
clock continues to run.

Antenna

The swivelling telescope aerial on the device is
effective in the FM transmission range.

• Completely withdraw and extend the aerial
and then adjust it into the position for the best
possible reception.

The telescope aerial does not function in the MW
transmission range. In these ranges, reception is
made by the built-in ferrite aerial.

• Position the device for the best possible recep­tion.

Additional audio device

You can connect additional audio devices to the
radio, for example, an MP3 player, for playback
through the radio.

• Connect the stereo jackplug of the audio device

with the socket AUX on the rear of the device.

Power supply

• When all of the required connections have been

made, insert the plug on the power cable into
a wall power socket. The device is now in stand­by and the time is shown in the display.
If the time has not yet been programmed in, it
begins with 0:00. In this case, programme in
the time as described in the next section.

Setting the time

1. In standby, press and hold the button TIME SET.

2. Enter in the hour by repeatedly pressing on the

button

HOUR.

3. Enter in the minutes by repeatedly pressing on

the button

4. Release the button

now programmed.

MIN.

TIME SET. The time display is

Note:

So that the time is saved in the event of a power failure
or withdrawal of the plug, the back-up batteries
must be inserted.

- 5 -

Utilisation

Device on/off switch

• Switch the device on by pressing the button

STANDBY/ON on the front side of the device.

The green operational LED

• To switch the device back into the standby mode,
press the button
green operational LED

• To switch the device off completely, remove the
plug from the power socket.

Radio/AUX operation

• First of all, switch the device on as described
above.

• Turn the regulator
you feel that a slight resistance has been overcome.
The Radio/AUX operation is now switched on.

• For radio operation, use the switch
to select either the wave band AM or FM.

In radio operation:
To select the radio station frequency

To select the radio station frequency, turn the tuning
regulator to either the left or the right. The station
frequency will be shown in the display.

• For playback of an external audio device, use
the switch

Adjusting the volume.

• Turn the regulator VOLUME/BUZZ further to the right
to increase the sound level.

• Turn the regulator
decrease the sound level.

AUX/AM/FM to select the setting AUX.

POWER glows.

STANDBY/ON once again. The

POWER extinguishes.

VOLUME/BUZZ to the right, until

AUX/AM/FM

VOLUME/BUZZ to the left to

Setting the alarm time

1. Press and hold the button AL. SET. A bell symbol

appears on the display .

2. Enter in the hour by repeatedly pressing on the
button

HOUR.

3. Enter in the minutes by repeatedly pressing on
the button

4. Release the button
extinguishes. The alarm time is now programmed.

MIN.

AL. SET. The bell symbol

Alarm with the buzzer (BUZZ)

• To programme an alarm call with the buzzer,
turn the regulator
left, until you feel that a slight resistance has
been overcome.

VOLUME/BUZZ all the way to the

Alarm with AUX-/Radio operation

• Turn the regulator VOLUME/BUZZ all the way to the
right, until you feel that a slight resistance has been
overcome, and then set the sound level at which
you wish to be woken.

• Using the switch
which you wish to be woken. If you wish to be
woken by the radio, tune in to a radio station
as described under “Radio/AUX operation”.

AUX/AM/FM select the manner in

Aktivating the alarm

• To activate the alarm, press the button AL.ON/OFF.
In the display the symbol appears.

Note:

So that the alarm can switch itself on, the radio must
be in the standby mode.

Deactivating the alarm/Ending the alarm

• When the alarm has switched itself on, you can
switch the alarm off by pressing the button

AL.ON/OFF. The alarm switches itself off, however,

it remains activated.

• To deactivate the alarm, press the button

OFF until the symbol in the display ex-

tinguishes.

AL.ON/

- 6 -

Cleaning

Warranty and Service

• Clean the housing exclusively with a soft damp
cloth and a mild detergent. Ensure that moisture
cannot permeate into the device during cleaning!

Warning!

Moisture penetrating the device creates the
risk of electric shock! Additionally, the device
could become irreparably damaged!

Disposal

Do not, under any circumstances, dispose
of the device with household waste. This
product is subject to the provisions of
European Directive 2002/96/EC.

Dispose of the device through an approved disposal
centre or at your community waste facility.
Observe the currently applicable regulations. In
case of doubt, please contact your waste disposal
centre.

Disposal of batteries/accumulators

Used batteries/rechargeable batteries may not be
disposed of in household waste. Every consumer
is statutorily obliged to dispose of batteries at a
collection site of his community/city district or at a
retail store.
The purpose of this obligation is to ensure that batte­ries are disposed of in a non-polluting manner. Only
dispose of batteries when they are fully discharged.

You receive a 3-year warranty for this device as of
the purchase date. Should you, in spite of our high
quality standards, have grounds for complaint please
contact our Service Hotline.
In the event that processing of your complaint is not
possible by telephone, here you will receive

• a processing number (RMA-Number) as well as

• an address, to which you can send your
product for warranty processing.

In the case of a mail-in shipment please enclose a
copy of the purchase receipt (sales slip). The device
must be securely packed and the RMA number clearly
visible. Goods sent in without the RMA number cannot
be processed.

Notice

The warranty provisions cover only material
or factory defects.
The warranty is not valid;

• for parts subject to wear

• for damage to breakable parts such as
switches or consumables such as or re­chargeable batteries.

This product is for private use only and is not inten­ded for commercial use. The warranty is void in the
case of abusive and improper handling, use of force
and internal modifications not carried out by our
authorized Service Centre.
Your statutory warranty claims are not restricted by
this warranty.

Dispose of the packaging materials in an

environmentally responsible manner.

Importer

KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY

www.kompernass.com

- 7 -

- 8 -
