PPHSS 670 PENDULUM ACTION JIGSAW

For sawing wood, plastic and metal

Dear Customer! We are delighted that you have decided to purchase our high quality PPHSS 670 pendulum action jigsaw. Please make sure
you familiarise yourself fully with the way the equipment works before you use it for the first time and that you understand how to handle
electrical power tools correctly. Please read the operating instructions below and the accompanying safety advice carefully.
Use the equipment only as described and for the indicated purposes. By doing this you will be able to work in complete safety and produce
better results. We hope you enjoy using your jigsaw.

FEATURES OF THE PPHSS 670

 ON - OFF switch  Base plate (with removable rubber shoe)
 Continuous operation locking button  Chip guard
 Chip extraction nozzle  Pendulum action control
 Speed control wheel  No-tool quick adjustment
 Adjustable clear-view cover for dust extractor of base plate

 Parallel guide with mm scale

TECHNICAL DATA

Nominal power consumption: 670 W
Nominal voltage: 230 V ~ 50 Hz
No load speed: 400 – 3200 rpm
Oscillation lift: 20 mm The A weighted noise level of the equipment is typically
Bevel cut up to: 45° Sound pressure level: 87.4 dB(A) ·Sound power level 100.4 dB(A)
Weight: 2.8 kg Hand/arm vibration is typically 4.1 m/s

2

Maximum cutting depth in: aluminium: 030 mm

steel: 010 mm
hardwood: 080 mm
softwood: 100 mm

SPECIFIC SAFETY ADVICE



 To be read in conjunction with the advice in the accompanying booklet on safety.
 Before doing any work on the machine, for example changing the saw blade, always remove the plug from its socket.
 Only connect the machine to the socket when it is switched off.
 Never remove chips or splinters while the equipment is operating - always remove the plug from the socket.
 Always wear ear protectors and safety glasses when using the jigsaw. In addition we recommend safety gloves, robust anti-slip footwear

and an industrial apron.

 Before using the jigsaw, check the mains lead and plug for damage. Have any damaged parts repaired or replaced at a specialist repair centre.
 Always keep the power cable well out of the jigsaw's working area and fed to the rear of the machine.
