Kraga
Features
•
Globular glass shades are gracefully suspended from curved
metal bases in artist-inspired arrangements.
•
A great piece for almost any space — especially in a foyer or
dining room.
•
Requires five bulbs with G9 sockets; G9 LED bulbs
recommended (sold separately).
•
Suitable for damp locations, per UL 1598.
Material
•
Manufactured with quality materials and complemented with
a meticulous finishing process.
•
Durable finishes engineered to last and designed to
coordinate with KOHLER faucet finishes.
Installation
•
Installation hardware included.
Codes/Standards
UL 1598
CSA C22.2 No. 250.0
KOHLER® Indoor Lighting Fixtures
Limited Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
BLL Matte Black
2PL Polished Brass
™
45" five-light linear chandelier
K-32380-CH05
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-23-2022 23:43 - US/CA/MX
Page 2
Kraga
6-3/4"
(171 mm)
45" (1143 mm)
1/2"
(13 mm)
4-3/4" (121 mm)
14-13/16"
(376 mm)
59-3/4"
(1518 mm)
30" (762 mm)
Required Electrical Service
One circuit required.
120 V, 60 Hz
Technical Information
All product dimensions are nominal.
Material: Steel, Aluminum, Glass
Number of Lights: 5
Lighting Type: Socket-based
Socket Type: 2 pin G9
Number of Shades: 5
Shade Type: Glass - frosted
Hanging Type: Downrod
Downrod Detail: 4 x 18" (457 mm), 2 x 12" (305 mm), 2 x
6" (152 mm), 2 x 3" (76 mm)
Height: 23-5/8" (600 mm) - 77-5/8" (1972 mm)
™
45" five-light linear chandelier
K-32380-CH05
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-23-2022 23:43 - US/CA/MX
