Kohler LBPR3851 Specifications

Page 1
CSA B651
OBC
volume control valve trim with Lever handle
Features
Single Lever handle allows for simultaneous on/off activation and temperature setting.
Coordinates with Components faucets and accessories to complete your bathroom.
Material
Premium material construction with metal handle ensures reliability and durability.
KOHLER finishes resist corrosion and tarnishing.
Technology
Patented K-joint installation technology ensures consistent trim appearance, regardless of variability in valve rough-in.
Required Products/Accessories
K-2974-K 1/2" Volume Control Valve
or
K-2977-K 3/4" Volume Control Valve
Recommended Products/Accessories
K-23723 Faucet cleaner
Components
Codes/Standards
ASME A112.18.1/CSA B125.1 ADA ICC/ANSI A117.1 CSA B651 OBC
K-T78025-4
KOHLER® Faucet Lifetime Limited Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
Vibrant® Brushed NickelBN
Matte BlackBL
1-800-4KOHLER (1-800-456-4537) Kohler Co. reserves the right to make revisions without notice to product specifications. For the most current Specification Sheet, go to www.kohler.com. 8-10-2020 15:10 - US/CA/LM/MX
Page 2
4-7/16" (113 mm)
Ø 3-15/16" (100 mm)
2-1/2" (64 mm)
Components
volume control valve trim with Lever handle
K-T78025-4
Technical Information
All product dimensions are nominal.
NoDrain included:
Notes
Install this product according to the installation instructions.
ADA, OBC, CSA B651 compliant when installed to the specific requirements of these regulations.
1-800-4KOHLER (1-800-456-4537) Kohler Co. reserves the right to make revisions without notice to product specifications. For the most current Specification Sheet, go to www.kohler.com. 8-10-2020 15:10 - US/CA/LM/MX
