Features
•
Air-induction technology maximizes the air/water mix for a
powerful, even flow.
•
Optimized sprayface with 48 nozzles delivers a more focused
coverage.
•
Ergonomic sprayhead pivots to allow precise adjustment for
targeted hydromassage.
•
MasterClean™ sprayface is easy-to-clean.
•
1.75 gpm (6.6 lpm) maximum flow rate.
•
Requires K-8593 or K-9514 shower hose (sold separately).
•
Coordinates with other products in the Artifacts collection.
Installation
•
Bracket or slidebar required for wall-mount installation.
•
Deck-mount holder required for deck-mount installation.
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Required Products/Accessories
K-8593 72" Shower Hose
K-9514 60" Shower Hose
Recommended Products/Accessories
K-23723 Faucet cleaner
Artifacts
Single-Function Handshower
K-72776-G
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
®
®
Available Colors/Finishes
Color tiles intended for reference only.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-11-2020 22:57 - US/CA/MX
DescriptionCodeColor
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Brushed NickelBN
Vibrant® Brushed BronzeBV
Oil-Rubbed Bronze2BZ
1-5/16"
(33 mm)
Ø 3-5/8" (92 mm)
9-7/8"
(251 mm)
G1/2
Thread
Artifacts
®
Single-Function Handshower
K-72776-G
Technical Information
All product dimensions are nominal.
Handshower:
1.75 gal/min (6.6 l/min)Rated maximum flow:
45 psi (3.1 bar)Pressure:
Notes
Install this product according to the installation
instructions.
Plumbing codes require an atmospheric vacuum
breaker (such as Kohler Model K-9660) be
installed in-line with handshowers. Please consult
with local plumbing officials.
