Features
•
Katalyst® air-induction technology maximizes the air/water mix
for a powerful, even flow.
•
Optimized sprayface for maximum performance.
•
MasterClean™ sprayface prohibits mineral buildup for easy
cleaning.
•
1/2" NPT connection.
•
1.75 gpm (6.6 lpm) maximum flow rate at 45 psi (3.1 bar).
•
Single function showerhead with 48 nozzle 6" (152 mm)
diameter sprayface.
•
Coordinates with other products in the Artifacts collection.
Installation
•
Wall-mount.
•
Shower arm and flange sold separately.
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Recommended Products/Accessories
K-72775 Shower Arm and Flange
K-23723 Faucet cleaner
Artifacts
®
1.75 gpm single-function showerhead
K-72774-G
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
®
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Brushed NickelBN
Vibrant® Brushed BronzeBV
Oil-Rubbed Bronze2BZ
Vintage NickelVNT
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-11-2020 22:57 - US/CA
3-15/16" (100 mm)
Ø 6" (152 mm)
1/2"-14 NPT
Artifacts
®
1.75 gpm single-function showerhead
K-72774-G
Technical Information
All product dimensions are nominal.
Showerhead/Body Spray:
1.75 gal/min (6.6 l/min)Rated maximum flow:
80 psi (5.5 bar)Pressure:
Notes
For use with automatic compensating valves rated
at 1.4 gal/min (5.3 l/min) or less.
Install this product according to the installation
instructions.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-11-2020 22:57 - US/CA
