Features
•
6 1/16" spout reach.
•
Includes open flume spout and metal touch-activated drain.
•
Handles sold separately.
•
Coordinate with Artifacts faucets, accessories, and showering
components to complete your bathroom.
Material
•
Brass construction.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Bath- or deck-mount.
•
Quick-Connect hose connections make widespread faucet
installation a snap.
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Required Products/Accessories
K-98068-4 Widespread Bathroom Sink Faucet Handles
or
K-98068-3M Widespread Bathroom Sink Faucet Handles
or
K-98068-9M Widespread Bathroon Sink Faucet Handles
or
K-98068-3 Widespread Bathroom Sink Faucet Handles
Recommended Products/Accessories
K-23726 Drain treatment
K-23723 Faucet cleaner
Artifacts® with Flume design
widespread bathroom sink spout
K-72761
Codes/Standards
ASME A112.18.1/CSA B125.1
NSF/ANSI 61
NSF/ANSI 372
All applicable US Federal and State material
regulations
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
®
Available Colors/Finishes
Color tiles intended for reference only.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-11-2020 22:55 - US/CA
DescriptionCodeColor
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Brushed NickelBN
Vibrant® Brushed BronzeBV
Oil-Rubbed Bronze2BZ
Vintage NickelVNT
6-1/16" (154 mm)
1-1/2"
(38 mm)
5"
(127 mm)
8" (203 mm) Min
16" (406 mm) Max
2-11/16"
(68 mm)
3/8"
(10 mm)
Ø 2-1/8"
(54 mm)
3-13/16"
(97 mm)
5-1/8"
(130 mm)
1-1/4" OD
Touch-Activated Drain
Artifacts® with Flume design
widespread bathroom sink spout
K-72761
Technical Information
All product dimensions are nominal.
Faucet:
1.2 gal/min (4.5 l/min)Flow rate:
60 psi (4.1 bar)Pressure:
YesDrain included:
Notes
Install this product according to the installation
instructions.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-11-2020 22:55 - US/CA
