tall bathroom sink spout with Ribbon design
Features
•
6-11/16" (170 mm) spout reach.
•
Tall height is ideal for vessel-style sinks.
•
1.2 gpm (4.5 lpm) maximum flow rate at 60 psi (4.14 bar).
•
Laminar flow controls deliver a graceful stream while conserving
water.
•
Includes metal touch-activated drain with 1-1/4" tailpiece.
•
Coordinate with your choice of Components widespread lavatory
handles for a personalized design.
Material
•
Premium metal construction for durability and reliability.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
For 8" - 16" (203 - 406 mm) centers.
•
Widespread or remote valve.
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Recommended Products/Accessories
K-77974-4 bathroom sink handles with Lever design
K-77974-8 bathroom sink handles with Oyl design
K-77974-9 bathroom sink handles with Industrial design
K-77963-8A bathroom sink rocker handle
K-23726 Drain treatment
K-23723 Faucet cleaner
Components
K-77966
Codes/Standards
ASME A112.18.1/CSA B125.1
NSF/ANSI 61
NSF/ANSI 372
All applicable US Federal and State material
regulations
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
®
™
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-1-2020 07:54 - US/CA/LM/MX
DescriptionCodeColor
Polished ChromeCP
Vibrant® Brushed NickelBN
Matte BlackBL
Ø 2-1/8"
(54 mm)
5-1/8"
(130 mm)
3-13/16"
(97 mm)
Touch-Activated Drain
1-1/4" OD
6-11/16"
(170 mm)
10-1/4"
(260 mm)
14-1/8"
(359 mm)
Ø 2-3/8"
(60 mm)
Ø 1-1/4"
(32 mm)
2"
(51 mm) Max
Components
™
tall bathroom sink spout with Ribbon design
K-77966
Technical Information
All product dimensions are nominal.
Notes
Install this product according to the installation
instructions.
Faucet:
1.2 gal/min (4.5 l/min)Flow rate:
60 psi (4.1 bar)Pressure:
YesDrain included:
Spout:
6-11/16" (170 mm)Spout reach:
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-1-2020 07:54 - US/CA/LM/MX
