Features
OBC
•
With innovative Flipstream® technology, the Flipside
handshower dedicates a single sprayhead surface to each of
four unique sprays.
•
Changing sprays is as easy as turning the head on its axis.
•
Ergonomic design is easy to use, even with soapy hands.
•
Komotion™ spray delivers a soothing, circular water pattern.
•
Kotton™ spray releases a dense, luxurious downpour of water.
•
Koverage™ spray delivers full-coverage spray for everyday
showering.
•
Kurrent™ spray offers a targeted massage to ease away aches
and pains.
•
1.75 gpm (6.6 lpm) flow rate.
®
Material
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Bracket or slidebar required for wall-mount installation.
•
Deck-mount holder required for deck-mount installation.
Water Conservation & Rebates
•
This product can help a building earn Water Efficiency points
in LEED® Green Building Rating System.
Required Products/Accessories
K-8593 72" Shower Hose
or
K-9514 60" Shower Hose
Recommended Products/Accessories
K-23723 Faucet cleaner
Flipside
®
Multifunction Handshower, 1.75 gpm
K-45425-G
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
OBC
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
®
Available Colors/Finishes
Color tiles intended for reference only.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
6-16-2020 14:04 - US/CA/MX
DescriptionCodeColor
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Brushed NickelBN
Oil-Rubbed Bronze2BZ
4-3/16" (106 mm)
Ø 5-3/8" (137 mm)
11"
(279 mm)
1/2" NPT
Flipside
®
Multifunction Handshower, 1.75 gpm
K-45425-G
Technical Information
All product dimensions are nominal.
Faucet:
1.75 gal/min (6.6 l/min)Flow rate:
45 psi (3.1 bar)Pressure:
NoDrain included:
Handshower:
1.75 gal/min (6.6 l/min)Rated maximum flow:
45 psi (3.1 bar)Pressure:
Notes
Install this product according to the installation
instructions.
Plumbing codes require approved backflow
prevention devices to be installed in-line to
handshowers. Please consult with local plumbing
officials.
OBC compliant when installed to the specific
requirements of these regulations.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
6-16-2020 14:04 - US/CA/MX
