Features
•
Single-function showerhead with 48 nozzle 5" (127 mm)
diameter sprayface.
•
Single-function showerhead with Katalyst® air-induction
technology.
•
Optimized sprayface for maximum performance.
•
2.5 gpm (9.5 lpm) maximum flow rate at 45 psi (3.1 bar).
•
MasterClean™ sprayface features an easy-to-clean surface that
withstands mineral buildup.
•
1/2" - 14 NPT connection.
•
Coordinates with other products in the Parallel collection.
Material
•
Premium material construction for durability and reliability.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Wall-mount.
Recommended Products/Accessories
K-7397 Shower Arm and Flange
Parallel
™
2.5 gpm single-function showerhead
K-24805
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
Vibrant® Brushed NickelBN
Matte BlackBL
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-13-2020 05:40 - US/CA/CN/IN/MX
5"
(127 mm)
3-1/8" (79 mm)
1/2"-14 NPT
5" (127 mm)
Parallel
™
2.5 gpm single-function showerhead
K-24805
Technical Information
All product dimensions are nominal.
Showerhead/Body Spray:
NoDrain included:
2.5 gal/min (9.5 l/min)Rated maximum flow:
45 psi (3.1 bar)Pressure:
Notes
Install this product according to the installation
instructions.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-13-2020 05:40 - US/CA/CN/IN/MX
