Features
•
One-piece toilets integrate the tank and bowl into a seamless,
easy-to-clean design.
•
Elongated bowl offers added room and comfort.
•
Skirted trapway simplifies cleaning.
•
Comfort Height® feature offers chair-height seating that
makes sitting down and standing up easier for most adults.
•
1.28 gpf (4.8 lpf).
•
Left-hand Polished Chrome trip lever.
•
2-1/8" (54 mm) fully glazed trapway.
•
Patented ReadyLock™ installation system, a simple solution
for skirted toilets, saves time, hassle, and eliminates the need
to drill into the floor for standard 12" (305 mm) rough-in.
Technology
•
Single-flush gravity uses the force of gravity and a precisionengineered tank, bowl, and trapway to create a strong siphon
during flushing.
•
AquaPiston® canister allows water to flow out of the tank from
all sides (360°), increasing the power and effectiveness of the
flush.
•
Flush valve's 3:2 ratio harnesses the natural force of gravity
and optimizes flush performance.
•
Durable canister design has 90% less exposed seal material
than a 3" flapper for leak-free performance.
•
Light-touch canister flush requires a lower actuation force
than a flapper.
Installation
•
Standard 12" (305 mm) rough-in.
•
10" and 14" (254 mm and 356 mm) rough-in kits also
available.
•
Supply line sold separately.
Recommended Products/Accessories
K-4108 C³®-230 Elongated bidet toilet seat
K-5381 14" Rough-in Full Skirt Trap and Attachment System
K-5383 10" Rough-in Full Skirt Trap and Attachment System
K-21710-L left-hand trip lever
1023457 Wax Ring/Hardware Kit
K-23726 Drain treatment
Included Components
Additional Components:
4008
Codes/Standards
ASME A112.19.2/CSA B45.1
DOE - Energy Policy Act 1992
EPA WaterSense
®
California Energy Commission (CEC)
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER® Toilets and Seats Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
NY Dune
95 Ice™ Grey
G9 Sandbar
7 Black Black™
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
11-10-2021 04:59 - US/CA/LM/MX
Reach® Comfort Height
One-piece compact elongated 1.28 gpf toilet
K-78080
®
Reach® Comfort Height
1"
(25 mm)
29"
(737 mm)
16-1/2"
(419 mm)
12"
(305 mm)
3-15/16"
(100 mm)
6-13/16"
(173 mm)
7/16"
(11 mm)
28-5/8" (727 mm)
13-5/8"
(346 mm)
14-7/16"
(367 mm)
9-9/16"
(243 mm)
10-7/8"
(276 mm)
13-1/2"
(343 mm)
5"
(127 mm)
3/8" NPT
Supply
8"
(203 mm)
Do not use a
double sanitary tee.
For Back-to-Back Toilet Installations
Use a 45° double
wye fitting.
Front of Bowl
L of Outlet
C
Technical Information
All product dimensions are nominal.
Toilet type: One-piece, Floor-mount
Waste Outlet: Floor
Bowl shape: Elongated
Flush type: AquaPiston
®
Trap passageway: 2-1/8" (54 mm)
Water Consumption
Full: 1.28 gpf (4.8 lpf)
Water surface size: 9-1/8" x 8-1/2" (232 mm x 216 mm)
Rim to water
surface:
6-3/8" (162 mm)
Rough-in: 12" (305 mm)
Fixture Supply Requirements
Min static pressure: 20 psi (137.9 kPa)
Max static pressure: 80 psi (551.6 kPa)
Min flowing
pressure:
25 psi (172.4 kPa)
Min flow rate: 0.43 gpm (1.6 lpm)
Notes
Install this product according to the installation
instructions.
For back-to-back toilet installations: Use only a
45° double wye fitting.
ADA, OBC, CSA B651 compliant when
installed to the specific requirements of these
regulations.
Plumbing codes may require elongated toilets
and elongated, open-front seats in public
bathrooms.
Accessibility standards may require controls to
be located on the open side of the toilet.
®
One-piece compact elongated 1.28 gpf toilet
K-78080
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
11-10-2021 04:59 - US/CA/LM/MX
