Features
•
8-inch center faucet holes.
•
Sloped-wall rectangular basin.
•
Combines with standard 30-inch vanities and 29-inch iron
console tables.
Material
•
KOHLER® enameled cast iron.
Installation
•
Vanity top.
Recommended Products/Accessories
K-9018 P-Trap
Iron/Impressions
Vanity-top Bathroom Sink
K-3049-8
Codes/Standards
ASME A112.19.1/CSA B45.2
Lifetime Limited Warranty for
KOHLER® Cast Iron Components
See website for detailed warranty information.
®
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Sea Salt™FF
Biscuit96
Almond47
Cane Sugar™FD
DuneNY
Ice™ Grey95
SandbarG9
BasaltFT
Ember™RR
Black 'n TanKA
Black Black™7
GRL
DGB
Black PlumPLM
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-25-2019 07:26 - US/CA/MX
Iron/Impressions
®
Vanity-top Bathroom Sink
K-3049-8
Technical Information
All product dimensions are nominal.
SingleBowl configuration:
Vanity top/ITBInstallation:
Bowl area (Only):
Length: 20-7/8" (530 mm)
Width: 14-1/2" (368 mm)
Water depth: 4" (102 mm)
3Number of deck holes:
8" (203 mm)Faucet hole spacing:
1-3/8" (35 mm)Faucet hole(s):
1-3/4" (44 mm)Drain hole:
Notes
Install this product according to the installation
instructions.
NOTE: When selecting a faucet for this bathroom
sink, ensure the faucet has a spout reach of
4-1/2" (114 mm) to 5" (127 mm) and has a spout
height of 3" (76 mm) to 6" (152 mm).
Product does not have an overflow.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-25-2019 07:26 - US/CA/MX
