OBC
2.5 gpm multifunction handshower with Katalyst
Features
•
Advanced spray engine provides two spray experiences:
full-coverage and targeted massage.
•
Full-coverage spray produces an encompassing spray for
everyday use and utilizes Katalyst® air induction to create large,
full drops.
•
Targeted massage spray is a focused stream for targeting sore
muscles or use as a utility spray.
•
Intuitive and easy push-button activation to switch between two
sprays.
•
Ergonomic design is comfortable and easy to grip.
•
MasterClean™ sprayface resists hard water buildup and is easy
to clean.
•
2.5 gpm (gallons per minute) flow rate.
•
Contains flow-regulating check valve for backflow prevention.
Material
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Bracket or slidebar required for wall-mount installation.
•
Deck-mount holder required for deck-mount installation.
Required Products/Accessories
K-8593 72" Shower Hose
or
K-9514 60" Shower Hose
Optional Products/Accessories
K-9660 Vacuum Breaker
Shift™+ Round
®
K-21335
Codes/Standards
ASME A112.18.1/CSA B125.1
DOE - Energy Policy Act 1992
OBC
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
4-2-2019 08:53 - US
Polished ChromeCP
Vibrant® Polished NickelSN
Vibrant® Moderne Brushed GoldBGD
Vibrant® Brushed NickelBN
Vibrant® Brushed BronzeBV
Oil-Rubbed Bronze2BZ
Matte BlackBL
Vibrant Rose GoldRGD
TitaniumTT
9-7/16"
Shift™+ Round
2.5 gpm multifunction handshower with Katalyst
K-21335
®
Technical Information
All product dimensions are nominal.
NoDrain included:
Handshower:
2.5 gal/min (9.5 l/min)Rated maximum flow:
Notes
For use with automatic compensating valves rated
at 2.2 gal/min (8.3 l/min) or less.
Install this product according to the installation
instructions.
Plumbing codes may require that a vacuum
breaker be installed in-line to handshowers.
Please consult local plumbing codes.
OBC compliant when installed to the specific
requirements of these regulations.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
4-2-2019 08:53 - US
