DUOSTRAINER
®
Features
For sink installations with 3-1/2” or
•
4” outlet
Open/close stopper on sink basket strainer [K-8803]
•
1-1/2” diameter connection and brass tailpiece on
•
body [K-8804]
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.18.2/CSA B125.2
•
Specified Model
SINK BASKET STRAINER AND BODY
K-8803
ALSO K-8804
K-8803
Colors/Finishes
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
K-8804
Model Description Colors/Finishes
K-8803 Sink basket strainer ❑ CP ❑ Other_____
K-8804 Body ❑ CP ❑ Other_____
Product Specification
The sink basket strainer [K-8803] shall feature an open/close stopper. The body shall feature a 1-1/2” diameter connection and
brass tailpiece. Product is intended for sink installations with 3-1/2” or 4” outlet. Sink basket strainer shall be Kohler Model
K-8803-_____ AND/OR body shall be Kohler Model K-8804-____.
Page 1 of 2
115152-4-
BD
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
Page 2
DUOSTRAINER
®
Installation Notes
Install this product according to the installation guide.
Ø 3-1/2"
(89 mm)
7/8" (22 mm)
K-8803
Product Diagram
DUOSTRAINER®SINK BASKET STRAINER AND BODY
Page2of2
115152-4-
BD
Ø 3-3/8"
1-1/2" OD
Ø 4-1/2"
(114 mm)
3/4" (19 mm) Max
2-3/8"
(60 mm)
4"
(102 mm)
K-8804
