Page 1
Stillness
Features
•
For use with K-8359 floor-mount, K-956 Stillness, and
K-14430 Purist® bath filler spouts.
Material
•
Brass.
Installation
•
Bath- or deck-mount.
Recommended Products/Accessories
K-23723 Faucet cleaner
Codes/Standards
None Applicable
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
®
Bath Filler Spout Shank
K-411-K
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 19:11 - US/CA/MX
Page 2
Stillness
* Indicates items to be supplied by installer.
X= Distance from centerline of spout inlet to front of spout base plus 1/2" (13 mm).
1/4" (6 mm) to 2-1/8" (54 mm)
Max Rim or Deck Mount
Rim or Deck
Mount Installation
*5/8" OD
Ø 7/8"
(22 mm)
Ø 1" (25 mm)
Hole
1/4" (6 mm) To
1-1/4" (32 mm) Max
Finished Deck
2-1/8" (54 mm) Max
Rough Deck
Rough + Finished
Deck Mount Installation
X
Technical Information
All product dimensions are nominal.
Notes
Install this product according to the installation
guide.
®
Bath Filler Spout Shank
K-411-K
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 19:11 - US/CA/MX
