Page 1
BANCROFTTM
Features
MasterClean
•
72 individual spray nozzles
•
Multi-function showerhead delivers wide, full
•
coverage spray, aerated spray and massage spray
1/2″ - 14 NPT connection
•
Complements Bancroft
•
2.5 gal (9.5 L) per minute flow rate
•
TM spray nozzles prohibit mineral build-up
Suite
®
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.18.1/CSA B125.1
•
Specified Model
SHOWERHEAD
K-10590
ALSO K-10591
Colors/Finishes
CP: Polished Chrome
•
PB: Vibrant®Polished Brass
•
Other: Refer to Price Book for additional colors/finishes
•
Model Description Colors/Finishes
K-10590 Single-function showerhead ❑ CP ❑ Other ____
K-10591 Multi-function showerhead ❑ CP ❑ Other ____
Recommended Accessory
K-7397 7-1/2″ (137 mm) shower arm and flange ❑ CP ❑ Other ____
Product Specification
Showerhead shall include single or multi-function spray. Multi-function showerhead shall deliver wide, full coverage spray, soft
aerated spray and therapeutic massage spray. Showerhead shall include MasterClean
build-up. Showerhead shall include 72 individual spray nozzles. Showerhead shall have 1/2″-14 NPT connection. Showerhead
shall be part of Bancroft Suite. Showerhead shall feature 2.5 gal (9.5 L) per minute flow rate. Showerhead shall be Kohler Model
K-_____-____.
TM spray nozzles to prohibit mineral
Page 1 of 2
1040132-4-
USA/Canada: 1-800-4KOHLER
C
(1-800-456-4537)
www.kohler.com
Page 2
BANCROFTTM
Installation Notes
Install this product according to the installation guide.
1/2"-14 NPT
4-3/4"
(121 mm)
Ø 5-15/16"
(151 mm)
K-10590 K-10591
Ø 5-15/16"
(151 mm)
Product Diagram
1/2"-14 NPT
4-11/16"
(119 mm)
BANCROFTTM SHOWERHEAD
Page2of2
1040132-4-
C
