DTV+
Features
•
Upgrade an existing installed DTV I auxiliary interface
(K-686) or DTV II auxiliary interface (K-658) to the DTV+
interface (K-99693).
•
Kit includes a cover plate and a wiring connection adapter to
utilize existing in-wall cables.
•
Note that the installed primary interface must be converted at
the same time using the appropriate conversion kit.
•
Note that DTV I and DTV II landscape auxiliary interfaces
(K-685 & K-657) cannot be upgraded to the new DTV+
interface.
Material
•
Premium material construction for durability and reliability.
Installation
•
The conversion kit cover plate attaches to the existing DTV I/
II interface wall sleeve. The new DTV+ interface clips into the
cover plate (DTV+ mounting bracket is not required).
Required Products/Accessories
K-99693-P Digital interface
Recommended Products/Accessories
K-23723 Faucet cleaner
Codes/Standards
None Applicable
KOHLER® Electronic Faucets,
Valves, and Controls Five-Year
Limited Warranty
See website for detailed warranty information.
™
Conversion Kit - DTV I/II Aux. Interface
K-97171
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 23:25 - US/CA
Page 2
DTV+
4-1/2"
(114 mm)
8-1/2"
(216 mm)
1-9/16"
(40 mm)
Technical Information
All product dimensions are nominal.
Notes
Install this product according to the installation
guide.
™
Conversion Kit - DTV I/II Aux. Interface
K-97171
