Page 1
Artifacts
Features
•
High-arch spout with 360° spout rotation offers superior
clearance for filling pots and cleaning.
•
KOHLER ceramic disc valves exceed industry longevity
standards for a lifetime of durable performance.
•
Single lever handle is simple to use and makes adjusting
water temperature easy.
•
Temperature memory allows faucet to be turned on and off at
the temperature set during prior usage.
•
Available with 8-1/2" (216mm) swing spout reach.
•
Flexible connections for easy installation.
•
1.5 gpm (5.7 lpm) maximum flow rate at 60 psi (4.14 bar).
Installation
•
Single-hole installation (3-hole escutcheon sold separately).
Adapters, Rough-in and Extension Kits
1012715 Range: 3-1/4" (83 mm) -
5-3/8" (137 mm)
Recommended Products/Accessories
1054432 1.5 GPM (5.7 l/min) Aerator Kit
K-99272 Three-Hole Kitchen Faucet Escutcheon
K-77685 Single-Cartridge Water Filtration System
K-77686 Double-Cartridge Water Filtration System
K-77687 single replacement filter cartridge
K-77688 Replacement Filter Cartridges, Two-Pack
K-23723 Faucet cleaner
Codes/Standards
ASME A112.18.1/CSA B125.1
NSF/ANSI 61
NSF/ANSI 372
All applicable US Federal and State material
regulations
DOE - Energy Policy Act 1992
California Energy Commission (CEC)
ADA
ICC/ANSI A117.1
CSA B651
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
CP Polished Chrome
SN Vibrant® Polished Nickel
VS Vibrant® Stainless
2BZ Oil-Rubbed Bronze
2MB
Vibrant® Brushed Moderne
Brass
®
Kitchen Sink Faucet Swing Spout
K-99263
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 23:39 - US/CA
Page 2
Artifacts
Ø 1-5/16"
9-1/16"
(230 mm)
14-11/16"
(373 mm)
8-1/2"
(216 mm)
Ø 2-5/8"
(67 mm)
4-5/16"
(110 mm)
27-5/8"
(702 mm)
Supply Hoses with
3/8" Compression Fitting
3-7/16"
(87 mm)
8-1/4"
(210 mm)
3-1/4"
(83 mm)
Max
2-9/16"
(65 mm)
Technical Information
All product dimensions are nominal.
Spout:
Spout reach: 8-1/2" (216 mm)
Notes
Install this product according to the installation
guide.
ADA, CSA B651 compliant when installed to
the specific requirements of these regulations.
®
Kitchen Sink Faucet Swing Spout
K-99263
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 23:39 - US/CA
