Features
CSA B651
•
Washout urinal.
•
3/4" top spud.
•
0.125 gpf (0.47 lpf) to 1.0 gpf (3.8 lpf).
•
14" (356 mm) extended rim.
•
Will replace K-4904-ET.
Material
•
Vitreous china.
Water Conservation & Rebates
•
WaterSense-compliant when used with a 0.125 gpf or 0.5 gpf
WaterSense flushometer.
Recommended Accessories
K-10668 WAVE DC 1/8 GPF Urinal Flushometer
K-10949 Tripoint™ DC 1/8 GPF Urinal Flushometer
K-13520 Manual 1/8 GPF Urinal Flushometer
K-7528 WAVE HES 1/8 GPF Urinal Flushometer
K-7546 Tripoint™ HES 1/8 GPF Urinal Flushometer
K-10675 WAVE DC 0.5 GPF Urinal Flushometer
K-10958 Tripoint™ DC 0.5 GPF Urinal Flushometer
K-7537 Tripoint™ HES 0.5 GPF Urinal Flushometer
K-7526 WAVE HES 0.5 GPF Urinal Flushometer
K-13519 Manual 0.5 GPF Urinal Flushometer
K-10676 WAVE DC 1.0 GPF Wshdwn Flushometer
K-10960 Tripoint™ DC 1.0 GPF Wshdwn Flushometer
K-13518 Manual 1.0 GPF Wshdwn Flushometer
K-7539 Tripoint™ HES 1.0 GPF Blwout Flushometer
K-7542 Tripoint™ HES 1.0 GPF Wshdwn Flushometer
K-7527 WAVE HES 1.0 GPF Wshdwn Flushometer
Bardon
™
High-Efficiency Urinal
K-4991-ET
Codes/Standards
ASME A112.19.2/CSA B45.1
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
ADA
ICC/ANSI A117.1
CSA B651
KOHLER® One-Year Limited Warranty
See website for detailed warranty information.
®
Components
Additional included component/s: 3/4" inlet spud, 2" outlet spud,
Strainer, and Hangers (2).
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-31-2018 08:18
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
Almond47
Black Black™7
Page 2
14-1/8"
Bardon
™
High-Efficiency Urinal
K-4991-ET
Technical Information
All product dimensions are nominal.
WashoutFlush outlet
technology:
3/4", Inlet, TopSpud size:
0.125 gal (0.5 L)Min. Water per Flush:
1 gal (3.8 L)Max. Water per Flush:
Designed for the above water use when installed with a
water-saving flushometer.
Notes
Install this product according to the installation
guide.
Refer to manufacturer’s instructions and local
codes for flushometer requirements.
ADA, CSA B651 compliant when installed to the
specific requirements of these regulations.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-31-2018 08:18
