Page 1
Choreograph
Features
•
For use with KOHLER Choreograph wall panels.
•
Four shelves; all removable for easy cleaning.
•
Unique design ensures no water can collect on the shelves.
•
Shower basket offers concealed storage for small items.
•
Shelves and basket are height-adjustable to 10 positions.
•
One shelf includes a hook for hanging storage and a cup for
toothbrushes or razors.
•
Integrated foot ledge makes it easier to shave or wash your
feet.
•
Recommended K-97636 Choreograph seam joint for
installation (sold separately).
•
Acrylic with matte finish to coordinate with Choreograph
shower walls.
Recommended Products/Accessories
K-97636 96" Seam Joint
K-23732 Tub & shower cleaner
Included Components
Additional Components:
Integral hook
Rubber basket
Shelves (3)
Codes/Standards
None Applicable
KOHLER® Limited Warranty
– Choreograph™ Walls and
Accessories
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
NY Dune
G9 Sandbar
9" shower storage
K-97630
®
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 23:32 - US/CA
Page 2
Choreograph
64-1/2"
(1638 mm)
95-5/16"
(2421 mm)
3/16" (5 mm)
10-7/8" (276 mm)
4-1/16" (103 mm)
8-7/8" (225 mm)
Technical Information
All product dimensions are nominal.
Material: Acrylic
Notes
Locker unit must be braced using 2x4’s around
the entire unit.
Use non-solvent based construction adhesive.
If installing accessories, install 2x4 backing
for handrails, shelves, and shower hooks, and
2x10 backing for the flip-down seat.
9" shower storage
K-97630
®
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 23:32 - US/CA
