Page 1
Features
•
Fits minimum 24-inch base cabinet width.
•
Single bowl.
•
9-inch depth.
•
Shortened apron allows sink to be used in most standard
cabinetry or retrofitted to existing standard cabinetry.
•
Self-Trimming apron overlaps the cabinet face for easy
installation and beautiful results.
•
No faucet holes.
•
Center drain.
•
Includes cutout templates.
Material
•
KOHLER® enameled cast iron.
Installation
•
Under-mount apron-front.
Recommended Products/Accessories
K-9000 P-Trap
K-8395 Sink Rack
K-6377 Sponge Caddy
K-6378 Kitchen Brush Caddy
K-6379 Kitchen Squeegee
K-6382 Disinfecting Wipes Dispenser
K-6383 Soap Dispenser
K-8618 Paper Towel Holder
K-8619 Flexible Kitchen Mat
K-8624 Dish Scraper
K-8801 Sink Strainer
K-8799 Sink Strainer
Included Components
Additional Components:
Cutout templates
Whitehaven
®
Under-Mount Kitchen Sink W/Short Apron
K-5664
Codes/Standards
ASME A112.19.1/CSA B45.2
KOHLER® Enameled Cast Iron Kitchen
Sink Lifetime Limited Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Sea Salt™FF
Biscuit96
Almond47
Cane Sugar™FD
DuneNY
Ice™ Grey95
SandbarG9
Mexican Sand™33
CashmereK4
BasaltFT
Thunder™ Grey58
Suede20
Black 'n TanKA
CaviarFP
Black Black™7
Grey LavenderGRL
Indigo BlueDGB
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
9-12-2019 05:27 - US/CA
Page 2
23-1/2" (597 mm)
Whitehaven
®
Under-Mount Kitchen Sink W/Short Apron
K-5664
Technical Information
All product dimensions are nominal.
SingleBowl configuration:
Under-mountInstallation:
24" (610 mm)Min. base cabinet
width:
Bowl area (Only):
Template:
Length: 18-13/16" (477 mm)
Width: 18-1/16" (459 mm)
Bowl depth: 9" (229 mm)
Water depth: 9" (229 mm)
3-5/8" (92 mm)Drain hole:
1247776-7, required, included
1239229-7, required, included
Notes
Install this product according to the installation
instructions.
NOTICE: Countertop manufacturer or cutter must
use the current product template available at
www.kohler.com, or by calling 1-800-4KOHLER.
Kohler Co. is not responsible for cutout errors
when the incorrect cutout template is used.
IMPORTANT! The distance from the top edge of
the cabinet to the top of the cabinet door must be
at least 6-7/8" (175 mm) to install this sink.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
9-12-2019 05:27 - US/CA
