Kohler KOH20541 Specifications

SHIFTTM

Features

Adjustable sprayface rotates to select wide-coverage

•

or forceful utility spray options
MasterClean

•

for easy cleaning
Handshower contains flow regulating check valve for

•

backflow prevention

TM sprayface resists hard water buildup

Codes/Standards Applicable

Specified model meets or exceeds the following:

ASME A112.18.1/CSA B125.1

•

Energy Policy Act of 2005

•

Specified Model

ELLIPSE HANDSHOWER

K-10257

ALSO K-45415

Colors/Finishes

CP: Polished Chrome

•

Other: Refer to Price Book for additional colors/finishes

•

Accessories

CP: Polished Chrome

•

Model Description Colors/Finishes

K-10257 Ellipse handshower – black handle, 2.5 gpm (9.5 lpm) ❑ CP ❑ Other ____
K-10257-A Ellipse handshower – metallic handle, 2.5 gpm (9.5 lpm) ❑ CP ❑ Other ____
K-10257-GR Ellipse handshower – grey handle, 2.5 gpm (9.5 lpm) ❑ CP ❑ Other ____
K-45415 Ellipse handshower – black handle, 2.0 gpm (7.6 lpm) ❑ CP ❑ Other ____
K-45415-A Ellipse handshower – metallic handle, 2.0 gpm (7.6 lpm) ❑ CP ❑ Other ____
K-45415-GR Ellipse handshower – grey handle, 2.0 gpm (7.6 lpm) ❑ CP ❑ Other ____

Required Accessories

K-8593 72″ (1829 mm) metal shower hose OR

K-9514 60″ (1524 mm) metal shower hose ❑ CP

❑ CP

Product Specification

The multi-function ellipse handshower shall feature adjustable sprayface that rotates to select wide-coverage or forceful utility
spray options. Handshower shall feature a MasterClean sprayface which resists hard water buildup for easy cleaning.
Handshower shall contain flow regulating check valve for backflow prevention. Handshower shall be Kohler Model
K-10257-____-____ or K-45415-____-____.

Page 1 of 2
1085896-4-

USA/Canada: 1-800-4KOHLER

D

(1-800-456-4537)

www.kohler.com

SHIFTTM

Installation Notes

Install this product according to the installation guide.

Plumbing codes require an atmospheric vacuum breaker
(such as Kohler Model K-9660) be installed in-line with
handshowers. Please consult with local plumbing officials.

NOTE: Handshower contains flow regulating check valve for
backflow prevention.

1-1/8"
(29 mm)

8-11/16"
(221 mm)

15/16"
(24 mm)

9"
(229 mm)

SHIFTTM ELLIPSE HANDSHOWER
Page2of2

1085896-4-

D

Product Diagram
