Page 1
Solid/Expressions
Features
•
Pairs with KOHLER Verticyl rectangular under-mount
bathroom sinks.
•
Pilot holes for 4" (102 mm) centerset, 8" (203 mm)
widespread, or single-hole faucet installation.
•
Sculpted edge.
•
Coordinates with the industry-standard 72" (1829 mm)
KOHLER vanities.
•
Field trimmable for alcove and corner installations.
•
Optional side and backsplashes available (sold separately).
Material
•
Solid surface.
Installation
•
Vanity top.
•
Includes mounting hardware for sinks.
•
Accommodates single, 4" centerset, and 8" widespread
faucet configurations.
Required Products/Accessories
K-2882 Undermount bathroom sink
Recommended Products/Accessories
K-23723 Faucet cleaner
Included Components
Additional Components:
Mounting Screws
Codes/Standards
None Applicable
KOHLER® One-Year Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
S33 White Expressions
S34 Almond Expressions
S35 Biscuit Expressions
S36 Ice Grey Expressions
®
73" vanity top with double Verticyl® rectangular
cutout
K-5462
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-9-2022 19:51 - US/CA
Page 2
Solid/Expressions
73-5/8" (1870 mm)
42" (1067 mm)
Front
Cross Section
View
1-1/8"
(29 mm)
1-1/4"
(32 mm)
3/4"
(19 mm)
17"
(432 mm)
Cross
Section
Line
2-1/2"
(62 mm)
12-9/16"
(319 mm)
15-13/16"
(402 mm)
17"
(432 mm)
2" (51 mm)
10-15/16"
(277 mm)
11-7/8"
(302 mm)
22-13/16"
(579 mm)
2" (51 mm)
Technical Information
All product dimensions are nominal.
Bowl configuration: Double equal
Installation: Vanity top/ITB
Bowl area (Right): Length: 17" (432 mm)
Width: 12-9/16" (319 mm)
Bowl area (Left): Length: 17" (432 mm)
Width: 12-9/16" (319 mm)
Notes
Install this product according to the installation
instructions.
Observe all local plumbing and building codes.
This countertop is designed to be installed with
a KOHLER or standard-size vanity.
Faucet hole and sink-mounting locations are
marked on the underside of the countertop.
®
73" vanity top with double Verticyl® rectangular
cutout
K-5462
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-9-2022 19:51 - US/CA
