Kohler KOH20398 Specifications

REVETM

Features

Fireclay

•
8″ (203 mm) centers (-8) or single-hole (-1)

•

With overflow

•

Available with shroud or pedestal

•
23-5/8″ (600 mm) x 18-5/16″ (465 mm) x

•
6-5/16″ (160 mm)

Codes/Standards Applicable

Specified model meets or exceeds the following:

ASME A112.19.2/CSA B45.1

•

Specified Model

BATHROOM SINK

K-5027

ALSO K-5150, K-5152

Colors/Finishes

0: White

•

Other: Refer to Price Book for additional colors/finishes

•

Accessories

0: White

•

F62: Brilliant Blanc

•

F63: Brilliant Ash

•

Other: Refer to Price Book for additional colors/finishes

•

Model Description Colors/Finishes

K-5027-1 Bathroom sink – single-hole (shown) ❑ 0 ❑ Other
K-5027-8 Bathroom sink – 8″ (203 mm) centers ❑ 0 ❑ Other
K-5150-1 Bathroom sink – single-hole with shroud ❑ 0 ❑ Other ____
K-5150-8 Bathroom sink – 8″ (203 mm) centers with shroud ❑ 0 ❑ Other ____
K-5152-1 Bathroom sink – single-hole with pedestal ❑ 0 ❑ Other ____
K-5152-8 Bathroom sink – 8″ (203 mm) centers with pedestal ❑ 0 ❑ Other ____

Recommended Vanity

K-2553 Wall-mount vanity – 22-7/16″ (570 mm) length ❑ F62 ❑ F63

Product Specification

The bathroom sink shall be made of fireclay. Product shall be 23-5/8″ (600 mm) in length, 18-5/16″ (465 mm) in width, and
6-5/16″ (160 mm) in height. Product shall be for 8″ (203 mm) centers (-8) or single-hole (-1). Product shall be with overflow.
Product shall be available with shroud or pedestal. Bathroom sink shall be Kohler Model K-____-____-____.

Page 1 of 2
1114334-4-

C

USA/Canada: 1-800-4KOHLER

(1-800-456-4537)

www.kohler.com

REVETM

Optional Accessories

K-5031 Shroud ❑ 0 ❑ Other ____
K-5032 Pedestal ❑ 0 ❑ Other ____

Technical Information

Fixture*:
Basin area 23-5/8″ (600 mm) x 12″ (305 mm)
Water depth 3″ (76 mm)
Drain hole Ø 1-11/16″ (43 mm)
Faucet hole(s) Ø 1-3/8″ (35 mm)
*Approximate measurements for comparison only.

Components:
K-5150-1 K-5027-1 bathroom sink, K-5031 shroud
K-5150-8 K-5027-8 bathroom sink, K-5031 shroud
K-5152-1 K-5027-1 bathroom sink, K-5032 pedestal
K-5152-8 K-5027-8 bathroom sink, K-5032 pedestal

K-5027-1

6-5/16"
(160 mm)

3-9/16"
(90 mm)

Installation Notes

Install this product according to the installation guide.

10-1/8"
(257 mm)

18-5/16"
(465 mm)

Centerline of Backing

REVETM BATHROOM SINK
Page2of2

1114334-4-

C

23-5/8" (600 mm)

11" (279 mm)

1-1/4" OD

3/8"
Hot

4" (102 mm)
5" (127 mm) for
Shroud Installation

6-5/16"
(160 mm)

12-7/8"
(327 mm)

3/8"
Cold

Product Diagram

7-7/16"
(189 mm)

14-1/2"
(368 mm)

K-5027-8

4" (102 mm)

3-9/16"
(90 mm)
