Page 1
Verdera
Features
•
Vertically adjustable 3x magnifying mirror on inside of door.
•
Three adjustable tempered-glass shelves.
•
Full-overlay mirrored door.
•
Mirrored interior.
•
Slow-close door prevents slamming.
•
Two-way adjustable hinges with 108° opening capability for
easy cabinet access.
•
Can be installed with left- or right-hand swing.
•
Includes mounting hardware for surface or recessed
installation.
Material
•
Anodized aluminum construction with a durable rust-proof
and chip-resistant finish.
•
Anodized aluminum construction with a durable rust-proof
and chip-resistant finish.
Installation
•
Requires K-99012 or K-99675 side mirror kit (sold separately)
for surface-mount installation.
Required Products/Accessories
K-99675 Medicine Cabinet Wood Side Kit
or
K-99012 mirrored side kit for medicine cabinet
Recommended Products/Accessories
K-23723 Faucet cleaner
Optional Products/Accessories
K-99662-24 Medicine Cabinet Surround
K-99662-40 Medicine Cabinet Surround
K-99661-15 Medicine Cabinet Surround
K-99662-15 Medicine Cabinet Surround
K-99663-15 Medicine Cabinet Surround
Codes/Standards
None Applicable
KOHLER® One-Year Limited
Warranty
See website for detailed warranty information.
®
Medicine Cabinet
K-99001
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 08:35 - US/CA/MX
Page 2
Verdera
30"
(762 mm)
30"
(762 mm)
13-3/8" (340 mm)
15" (381 mm)
108°
Wall
Surface
28-1/8"
(714 mm)
4-3/4"
(121 mm)
1-1/4"
(32 mm)
3-9/16"
(90 mm)
4-1/4"
(108 mm)
Technical Information
All product dimensions are nominal.
Notes
Install this product according to the installation
guide.
IMPORTANT! For recess mounting, the wall
cavity must be framed and cabinet secured to
framing studs. Reroute any electrical wires or
water supply piping from the wall cavity. If you
encounter drain or vent piping, or if your wall
is load-bearing, consult a professional before
proceeding.
For surface mounting, use anchors (not
provided) rated for the loaded weight of this
product. Refer to the anchor manufacturer's
instructions.
When determining the height of the cabinet,
ensure the mirrored door will clear all obstacles
(such as a faucet). A minimum distance of
3" (76 mm) is required.
This cabinet is designed for either right or left
door swing. Check for obstructions.
Cutout for recess-mount installations:
13-1/2" (343 mm) width x 28-1/4" (718 mm)
height x 3-11/16" (94 mm) depth.
®
Medicine Cabinet
K-99001
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 08:35 - US/CA/MX
