Purist
Features
•
Includes faceplate with handle.
•
Single handle controls flow to outlets.
•
Cross handle.
•
When used with K-728 Series MasterShower diverter valves,
handle controls flow to two or three outlets individually or any
two outlets at a time.
•
When used with K-737 Series MasterShower diverter valves,
handle controls flow to two or three outlets individually or only
one outlet at a time.
•
Valve (not supplied) can be configured on site for 2- or 3outlet operation.
•
360° handle rotation with three-outlet operation.
•
120° handle rotation with two-outlet operation.
•
Complements Purist faucets and accessories.
Material
•
Premium material construction with metal handle ensures
reliability and durability.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
Trim only; requires valve to complete installation (sold
separately).
•
Patented K-joint installation technology ensures consistent
trim appearance, regardless of variability in valve rough-in.
Recommended Products/Accessories
K-728-K 3/4" Two- or Three-Way Transfer Valve
K-737-K 3/4" Two- or Three-Way Diverter Valve
K-23723 Faucet cleaner
Codes/Standards
ASME A112.18.1/CSA B125.1
ADA
ICC/ANSI A117.1
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
CP Polished Chrome
SN Vibrant® Polished Nickel
BN Vibrant® Brushed Nickel
BV Vibrant® Brushed Bronze
BL Matte Black
2MB
Vibrant® Brushed Moderne
Brass
®
Transfer Or Diverter Valve Trim
K-T14491-3
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 09:12 - US/CA/MX
Page 2
Purist
4-3/16" (106 mm) Ø 3-7/8" (98 mm)
3-1/2"
(89 mm)
Technical Information
All product dimensions are nominal.
Notes
Install this product according to the installation
instructions.
ADA compliant when installed to the specific
requirements of these regulations.
®
Transfer Or Diverter Valve Trim
K-T14491-3
