Tea-for-Two
Features
•
44 airjets release thousands of bubbles that surround,
support, and massage the body.
•
Variable-speed blower lets you adjust massage intensity to
18 levels.
•
Zones of Control™ feature allows you to target massage to
back, midsection, or feet.
•
Electronic keypad.
•
Spacious design accommodates up to two bathers.
•
Safeguard® slip-resistant surface on bath floor.
•
Automatic and manual purge cycles remove residual water
from air channels after use.
Material
•
KOHLER® enameled cast iron.
Hydrotherapy
•
BubbleMassage™.
Installation
•
Reversible drain.
•
Undermount.
•
Drop-in or undermount.
•
Requires K-23856 cable pop-up bath drain and K-23857 bath
drain trim (sold separately).
Required Products/Accessories
K-23856 1-1/2" cable pop-up bath drain
or
K-23857 Bath drain trim
Recommended Products/Accessories
K-1491 Bath/Whirlpool Pillow
K-1601 Bath/whirlpool footstop, removable
K-1705 Whirlpool/BubbleMassage™ Remote Control
K-582 Under-Mount Installation Kit
K-9498 3" Keypad Trim
K-1179 Vinyl Tiling-in Bead
Codes/Standards
ASME A112.19.1/CSA B45.2
ASME A112.19.7/CSA B45.10
ASTM F462
UL 1795
CSA C22.2 No. 218.2
KOHLER® Enameled Cast Iron Bath
and Shower Base Lifetime Limited
WarrantyKOHLER® Hydrotherapy
Components Five-Year Limited
Warranty
See website for detailed warranty information.
®
71-3/4" x 36" drop-in BubbleMassage™ air bath
K-865-G0
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 08:18 - US/CA
Tea-for-Two
No change in measurements if connected
with drain illustrated. (K-7169-AF)
Blower Motor/Control Access
34" (864 mm) W x
15" (381 mm) H
36" (914 mm)
71-3/4" (1822 mm)
15-5/8"
(397 mm)
20-7/8"
(530 mm)
18"
(457 mm)
1-1/2" Bath Drain
2-7/8"
(73 mm)
3" (76 mm)
2-1/2"
(64 mm)
3/4"
(19 mm)
3-1/2"
(89 mm)
1/4" (6 mm)
Lumbar
Angle 28°
Required Electrical Service
One dedicated circuit required, protected with Class A GroundFault Circuit-Interrupter (GFCI). Outside North America, this
device may be known as a Residual Current Device (RCD).
Blower: 240 V, 15 A, 50/60 Hz
Technical Information
All product dimensions are nominal.
Installation: Drop-in, Under-mount
Drain location: End
Basin area, bottom: 49" x 22" (1245 mm x 559 mm)
Basin area, top: 62" x 28" (1575 mm x 711 mm)
Weight: 455 lbs (206.4 kg)
Minimum floor load: 69 lbs/ft² (336.9 kg/m²)
Water depth: 17" (432 mm)
Water capacity: 89 gal (336.9 L)
Cutout: Drop-in, 70-1/4" x 34-1/2" (1784 mm x
876 mm)
Template: Under-mount, K-582, required, not
included
Electrical component
rating:
Blower: 240 V, 5 A, 50/60 Hz
Notes
Measure your actual product for rough-in
details.
Install this product according to the installation
instructions.
The hot water supply should be 70% of the
capacity of the bath or greater. Installations will
vary.
Kit is required for under-mount installations
(sold separately).
If relocating the blower motor, do not relocate
or alter the PVC tee or coiled flexible tubing
connected to the blower. Follow the blower
relocation instructions exactly. Provide access
for servicing the blower.
®
71-3/4" x 36" drop-in BubbleMassage™ air bath
K-865-G0
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 08:18 - US/CA
