Freewill
Features
•
45"L x 37-1/4"W x 84"H.
•
One-piece module for installation ease.
•
Grab bars in brushed stainless steel and slip-resistant floor
for added safety.
•
Fold-up seat on left side.
•
Fits slide bar 24" and under.
Installation
•
Center rear drain.
Recommended Products/Accessories
K-1665 Shower Light
K-9132 Shower Drain
K-23726 Drain treatment
K-23723 Faucet cleaner
K-23732 Tub & shower cleaner
Codes/Standards
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
ADA
ICC/ANSI A117.1
KOHLER® Plastic Baths and
Receptors Lifetime Limited Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
96 Biscuit
47 Almond
®
45" x 37-1/4" one-piece barrier-free shower stall
K-12101-C
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 14:51 - US//CA
Freewill
36" (914 mm)
36"
(914 mm)
*84"
(2134 mm)
3-1/4"
(83 mm)
18"
(457 mm) Max
37"
(940 mm)
1-1/4"
(32 mm)
2-1/2"
(64 mm)
37-1/4"
(946 mm)
*Recess opening must be 45-1/4" (1149 mm) x 84-1/4" (2140 mm).
Represents control area for faucets
Represents 24" (610 mm) wall mount slide bar.
Represents clear floor space for
36" (914 mm) x 48" (1219 mm).
5" (127 mm)
3/4"
(19 mm)
Elbow Supply
48" (1219 mm)
1/2" (13 mm)
2-1/2"
(64 mm)
*45" (1143 mm)
9"
(229 mm)
22-1/2"
(572 mm)
Drain
Drain
Technical Information
All product dimensions are nominal.
Installation: Three-wall alcove
Drain location: Center rear
Weight: 170 lbs (77.1 kg)
Notes
Measure your actual product for rough-in
details.
Install this product according to the installation
instructions.
For increased accessibility, utilize "pit"
installation as detailed in installation guide.
The fixture is not drilled for supply fittings.
Shimming may be required to level the fixture.
Stud opening tolerance + 1/4" (6 mm).
When fire rated construction is specified,
dimensions are to the inside of the fire-rated
wall.
Some shimming between stud frame and fixture
may be required.
For optimum accessibility, specify faucets and
fittings to install and operate within the control
area shown.
ADA compliant when installed to the specific
requirements of these regulations.
®
45" x 37-1/4" one-piece barrier-free shower stall
K-12101-C
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 14:51 - US//CA
