Page 1
HIFLOW RITE-TEMP
®
Features
Brass valve bodies
•
Pressure-balancing mechanism of one-piece
•
diaphragm cartridge design for ease of maintenance
Mixing valve cycles from ″cold″ to ″hot″
•
3/4″ NPT connections
•
HiFlow Rite-Temp
•
design valve
High-Temperature limit stop
•
Integral shut-off valve stops
•
Minimum operating pressure 15 psi (103.4 kPa)
•
pressure balancing diaphragm
®
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.18.1/CSA B125.1
•
ASSE 1016
•
Specified Model
PRESSURE-BALANCING VALVE
K-2971-KS
Colors/Finishes
NA: None applicable
•
Accessories
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
Model Description Colors/Finishes
K-2971-KS Pressure-balancing valve ❑ NA
Recommended Accessories
88526 HiFlow Rite-Temp
thin wall installation kit ❑ CP ❑ Other_____
®
Product Specification
HiFlow Rite-Temp
the ″off″ position, through the ″cold″ to the ″hot″, and includes a high-temperature limit stop. The pressure-balancing mechanism
shall be of one-piece diaphragm cartridge design for ease of maintenance. Product shall feature integral shut-off valve stops.
Pressure-balancing valve shall be minimum operating pressure 15 psi (103.4 kPa). HiFlow Rite-Temp
single-control valve shall be Kohler Model K-2971-KS-NA.
pressure-balancing single-control valve shall feature a brass valve body. The valve shall mix the water from
®
pressure-balancing
®
Page 1 of 2
1150733-4-B
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
Page 2
HIFLOW RITE-TEMP
®
Installation Notes
WARNING: Risk of damage to the K-2971-KS
valve assembly. When using the K-2971-KS valve
in a fiberglass or acrylic installation, use the thin
wall installation kit (88526).
Install this product according to the installation guide.
Avoid cross-flow conditions. Do not install shut-off device on
either valve outlet.
Product Diagram
HIFLOW RITE-TEMP®PRESSURE-BALANCING VALVE
Page2of2
