Features
CSA B651
OBC
•
Brass construction.
•
Brass valve bodies.
•
Quarter-turn washerless ceramic disc valves.
•
Escutcheon plate.
•
For 8" (203 mm) centers.
•
Lower flow aerator options are available (refer to the Kohler
Price Book).
•
Variety of handle style options.
•
8-1/8" (206 mm) swing spout reach.
•
2.2 gal/min (8.3 l/min) maximum flow rate [max at 60 psi (4.14
bar)].
•
Less drain.
Required Accessories
K-16010-2 Standard Handles for Centerset Base Faucet
or
K-16010-3 Cross Handles for Centerset Base Faucet
or
K-16010-4 Lever Handles for Centerset Base Faucet
or
K-16010-5 Wristblade Lever Handles for Centerset Base Faucet
Optional Accessories
1011402
1160595
Triton
Kitchen Sink Base Faucet
K-7825-K
Codes/Standards
ASME A112.18.1/CSA B125.1
NSF 61
NSF 372
DOE - Energy Policy Act 1992
ADA
ICC/ANSI A117.1
CSA B651
OBC
All applicable US Federal and State material
regulations
®
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 02:57
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
4" (102 mm)
Triton
®
Kitchen Sink Base Faucet
K-7825-K
Technical Information
All product dimensions are nominal.
8-1/8" (206 mm)Spout reach:
Faucet:
2.2 gal/min (8.3 l/min)Flow rate:
60 psi (4.1 bar)Pressure:
Notes
Install this product according to the installation
guide.
ADA, OBC, CSA B651 compliant when installed
to the specific requirements of these regulations.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 02:57
