TRADITIONAL ROUND
Features
Single-function Rain showerhead
•
MasterClean
•
for easy cleaning
Katalyst
•
joint (patent pending)
Optimized sprayface for maximum performance
•
Solid brass construction
•
2.5 gallon (9.5 L) per minute flow rate
•
1/2″ - 14 NPT connection
•
TM spray nozzles prohibit mineral buildup
TM Spray Technology with air induction ball
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.18.1/CSA B125.1
•
Energy Policy Act of 1992
•
Specified Model
RAIN SHOWERHEAD
K-13692
ALSO K-13693, K-13694
Colors/Finishes
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
Accessories
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
Model Description Size Nozzles Colors/Finishes
K-13692 Rain showerhead 8-7/16″ (214 mm) 78 ❑ CP ❑ Other___
K-13693 Rain showerhead 10-7/16″ (265 mm) 78 ❑ CP ❑ Other___
K-13694 Rain showerhead 12-7/16″ (316 mm) 102 ❑ CP ❑ Other___
Optional Accessories
K-7392 12″ (305 mm) straight ceiling-mount shower arm and flange ❑ CP ❑ Other____
K-7394 6″ (152 mm) straight ceiling-mount shower arm and flange ❑ CP ❑ Other____
K-7396 3″ (76 mm) straight ceiling-mount shower arm and flange ❑ CP ❑ Other____
K-10124 Right-angle shower arm and flange ❑ CP ❑ Other____
Product Specification
The single function rain showerhead shall be made of solid brass construction with MasterCleanTM spray nozzles to prohibit
mineral build up for easy cleaning. Showerhead shall have Katalyst
pending) and optimized spray face for maximum performance. Showerhead shall have a flow rate of 2.5 gallons (9 L) per
minute. Showerhead shall have a 1/2″-14 NPT connection. Showerhead shall be Kohler Model K-13692-____, K-13693-____
or K-13694-____.
Page 1 of 2
1142015-4-
C
TM spray technology with air induction ball joint (patent
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
TRADITIONAL ROUND
Installation Notes
Install this product according to the installation guide.
1/2"-14 NPT
Ø 8-7/16" (214 mm)
K-13692
1/2"-14 NPT
Ø 10-7/16" (265 mm)
K-13693
1/2"-14 NPT
Ø 12-7/16" (316 mm)
K-13694
3-3/4"
(95 mm)
3-3/4"
(95 mm)
3-3/4"
(95 mm)
TRADITIONAL ROUND RAIN SHOWERHEAD
Page2of2
1142015-4-
C
Product Diagram
