EVANDALETM
Features
Frame of mahogany solids (F25 Sapele finish)
•
Frame of birch solids and painted substrate (F44 Lily
•
finish)
Frame of birch solids (F80 Cocoa finish)
•
Vertical wall-mount installation
•
Includes hanger
•
Coordinates with Evandale vanities
•
23-1/2″ (597 mm) x 32″ (813 mm) x 1″ (25 mm)
•
Codes/Standards Applicable
Specified model meets or exceeds the following:
CARB P2
•
Specified Model
Colors/Finishes
F25: Sapele
•
F44: Lily
•
F80: Cocoa
•
MIRROR
K-2746
Model Description Colors/Finishes
K-2746 Mirror – vertical wall-mount ❑ F25 ❑ F44 ❑ F80
Recommended Vanities
K-2732 Evandale vanity, 30″ (762 mm) width ❑ F25 ❑ F44 ❑ F80
Product Specification
The mirror shall be 23-1/2″ (597 mm) in width, 32″ (813 mm) in height, and 1″ (25 mm) in depth. Mirror frame shall be made
of mahogany solids (F25 Sapele finish), or birch solids and painted substrate (F44 Lily finish), or birch solids (F80 Cocoa finish).
Mirror shall be for vertical-mount installation and include hanger. Mirror shall coordinate with Evandale vanities. Mirror shall be
Kohler Model K-2746-_____.
Page 1 of 2
1156334-4-
USA/Canada: 1-800-4KOHLER
C
(1-800-456-4537)
www.kohler.com
EVANDALETM
Installation Notes
Install this product according to the installation guide.
Select the type of fastener based on the wall material. A
minimum 20 lb (9.07 kg) load bearing fastener is
recommended.
Install the fastener to a stud to avoid possible property and
product damage.
1"
(25 mm)
32"
(813 mm)
23-1/2" (597 mm)
EVANDALETM MIRROR
Page2of2
1156334-4-
C
Product Diagram
