Features
•
30-inch apron sink minimum base cabinet width.
•
Vitreous china.
•
Wall-mount or top-mount installation.
•
Single bowl.
•
Two faucet holes on 8 (203 mm) centers.
•
Integral apron and backsplash.
•
30" (762 mm) x 22" (559 mm) x 8-5/8" (219 mm)
Recommended Accessories
K-1814-P Wall Mount Sink Brackets
K-9000 P-Trap
63002 Bracket, Tie Bar
Optional Accessories
K-6002 Sink Rack
K-8801 Sink Strainer
Gilford
™
Apron-front Kitchen Sink
K-12700
Codes/Standards
ASME A112.19.2/CSA B45.1
KOHLER® One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
Almond47
Black Black™7
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
4-3-2015 03:11
7-1/16"
Gilford
™
Apron-front Kitchen Sink
K-12700
Technical Information
All product dimensions are nominal.
SingleBowl configuration:
Wall-mount, Top-mountInstallation:
Bowl area
Length: 28" (711 mm)
Width: 18" (457 mm)
Bowl depth: 8-5/8" (219 mm)
2Number of deck holes:
1-3/8" (35 mm)Faucet hole(s):
3-5/8" (92 mm)Drain hole:
Notes
Install this product according to the installation
guide.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
4-3-2015 03:11
