Features
•
Cast iron with Safeguard® finish
•
Undermount installation
•
Comfort Depth® with low step-over height and slotted overflow
increases bathing depth
•
Less all trim
•
65-7/8" (1673 mm) x 32-5/16" (821 mm) x
Required Accessories
K-7271 Slotted Overflow Bath Drain
or
K-7272 Slotted Overflow Bath Drain
Parity
Bath
K-895
Codes/Standards
ASME A112.19.1/CSA B45.2
KOHLER® Lifetime Limited Warranty
for Cast Iron Components
See website for detailed warranty information.
®
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 03:23
2-9/16"
Parity
Bath
K-895
®
Technical Information
All product dimensions are nominal.
Under-mountInstallation:
ReversibleDrain location:
45-3/4" x 21-3/8" (1162 mm x 543 mm)Basin area, bottom:
53-7/8" x 25-1/8" (1368 mm x 638 mm)Basin area, top:
61 lbs/ft² (297.8 kg/m²)Minimum floor load:
61 gal (230.9 L)Water capacity:
Template:
Under-mount, 1106074-7, required,
included
Notes
Install this product according to the installation
guide.
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 03:23
