ANTIQUETM
Features
Brass construction
•
Available with lever handle
•
Front seal plate assembly
•
Handle assembly
•
Complements Antique
•
TM Suite
Codes/Standards Applicable
Specified model meets or exceeds the following:
ADA
•
ASME A112.18.1/CSA B125.1
•
ICC/ANSI A117.1
•
CSA B651
•
OBC
•
Specified Model
THERMOSTATIC TRIM SET
K-T10110
ALSO K-T10111, K-T10113
ADA CSA B651
Colors/Finishes
CP: Polished Chrome
•
PB: Vibrant®Polished Brass
•
Other: Refer to Price Book for additional colors/finishes
•
NA: None applicable
•
OBC
For complete valve, both faucet trim and valving must be specified.
Model Description Colors/Finishes
K-T10110-4 Thermostatic valve trim ❑ CP ❑ PB ❑ Other ____
K-T10111-4 Volume control trim ❑ CP ❑ PB ❑ Other ____
K-T10113-4 Transfer valve trim ❑ CP ❑ PB ❑ Other ____
Product Specification
Thermostatic trim set shall be of brass construction. Thermostatic trim set shall include front seal plate assembly and handle
assembly. Product shall be available with lever handle. Trim shall complement the Antique
be Kohler Model K-T____-____-____, thermostatic valving shall be Kohler Model K-____-__-NA, and ceramic dial faceplate for
Kohler Model K-T10110 shall be K-10140.
Page 1 of 2
1041504-4-
F
TM Suite. Thermostatic trim set shall
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
ANTIQUETM
Required Accessories
K-2972-KS (replaces K-679-KS) 1/2″ Thermostatic valve ❑ NA
K-2974-K (replaces K-681-K) 1/2″ Volume control ❑ NA
K-2975-KS (replaces K-669-KS) 3/4″ Thermostatic valve ❑ NA
K-2977-K (replaces K-671-K) 3/4″ Volume control ❑ NA
K-728-K 3/4″ Transfer valve ❑ NA
K-737-K 3/4″ Diverter valve ❑ NA
K-10140 Ceramic dial faceplate for K-T10110 ❑ Other ____
Installation Notes
Install this product according to the installation guide.
C
L of Valve Inlet
3-3/4" (95 mm)
Thick Wall
2-7/16" (62 mm)
Thin Wall
3-3/4"
(95 mm)
ANTIQUETM THERMOSTATIC TRIM SET
Page2of2
1041504-4-
F
7" (178 mm)
3-3/4" (95 mm)
Thick Wall
2-7/16" (62 mm)
Thin Wall
Product Diagram
C
L of Valve Inlet
3-1/2"
(89 mm)
3-7/8"
(98 mm)
K-T10111/13K-T10110
