SALIENTTM
Features
Cast iron with Safeguard
•
Center drain outlet
•
Three tile-in flanges
•
Alcove installation
•
Complements traditional and contemporary bathroom
•
designs
60″ (1524 mm) x 36″ (914 mm) x 3-15/16″ (100 mm)
•
®
finish
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.19.1/CSA B45.2
•
Specified Model
SHOWER BASE
K-9055
Colors/Finishes
0: White
•
Other: Refer to Price Book for additional colors/finishes
•
Accessories
CP: Polished Chrome
•
PB: Vibrant®Polished Brass
•
Other: Refer to Price Book for additional colors/finishes
•
Model Description Colors/Finishes
K-9055 Shower base with center drain ❑ 0 ❑ Other_____
Recommended Accessories
K-9132 Grid drain ❑ CP ❑ PB ❑ Other_____
Product Specification
The cast iron shower base shall be 60″ (1524 mm) in length, 36″ (914 mm) in width, and 3-15/16″ (100 mm) in height. Product
shall feature a Safeguard finish, center drain outlet, and three tile-in flanges. Product shall be for alcove installations. Product
shall complement traditional and contemporary bathroom designs. Product shall be Kohler Model K-_____-_____.
Page 1 of 2
1069570-4-
F
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
SALIENTTM
Technical Information
Fixture*:
Configuration one-piece
Weight 220 lbs (99.8 kg)
Drain hole Ø 3-3/8″ (86 mm)
* Approximate measurements for comparison only.
Installation Notes
Install this product according to the installation guide.
The dimensions are applicable for this product only and
should not be used to fabricate substitute bases for shower
enclosures.
60" (1524 mm)
3-5/16" (84 mm)
30" (762 mm)
17-1/4"
(438 mm)
36"
(914 mm)
2" (51 mm)
30˚
9/16"
(14 mm)
3-15/16"
(100 mm)
SALIENTTM SHOWER BASE
Page2of2
1069570-4-
F
Product Diagram
