Features
•
End drain.
•
Integral lumbar support.
•
Coordinates with other products in the Bancroft® collection.
•
65-7/8" (1673 mm) x 41-3/4" (1060 mm) x 22" (559 mm)
Material
•
Acrylic
Installation
•
Drop-in
Recommended Accessories
K-7161-AF Bath Drain
K-24916 Wireless Music Kit
K-1491 Bath/Whirlpool Pillow
K-7265 Clearflo Bath Drain
K-37382 45" Rough-in Cable Bath Drain
Codes/Standards
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
UL 1795
Greenguard UL 2818 - Gold
CARB P2
Bancroft
5.5' Bath
K-1156
®
KOHLER® One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
Almond47
DuneNY
SandbarG9
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-28-2017 02:39
11-1/4"
Bancroft
5.5' Bath
K-1156
®
Technical Information
All product dimensions are nominal.
Drop-inInstallation:
EndDrain location:
46" x 30" (1168 mm x 762 mm)Basin area, bottom:
57" x 34" (1448 mm x 864 mm)Basin area, top:
80 lbs (36.3 kg)Weight:
47 lbs/ft² (229.5 kg/m²)Minimum floor load:
16" (406 mm)Water depth:
95 gal (359.6 L)Water capacity:
Drop-in, 1043292-7, required, includedTemplate:
Notes
Measure your actual product for rough-in details.
Install this product according to the installation
instructions.
The hot water supply should be 70% of the
capacity of the bath or greater. Installations will
vary.
