FORTÉ
®
Features
3-function showerhead with wide coverage, medium
•
coverage, and concentrated spray options
1.75 gpm (6.6 L) per minute flow rate
•
5-15/16″ (151 mm) diameter showerhead
•
Complements Forté
•
MasterClean
•
for easy cleaning
1/2″ - 14 NPT connection
•
TM spray nozzles prohibit mineral buildup
®
Suite
Codes/Standards Applicable
Specified model meets or exceeds the following:
ASME A112.18.1/CSA B125.1
•
EPA WaterSense
•
®
Specified Model
MULTI-FUNCTION SHOWERHEAD
K-10240
Colors/Finishes
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
Accessories
CP: Polished Chrome
•
Other: Refer to Price Book for additional colors/finishes
•
Model Description Colors/Finishes
K-10240 Multi-function showerhead ❑ CP ❑ Other ____
Recommended Accessories
K-7397 Shower arm and flange – 7-1/2″ (137 mm) length, 1/2″ NPT ❑ CP ❑ Other ____
Product Specification
The showerhead shall feature a Masterclean sprayface nozzles to prohibit mineral build-up for easy cleaning. Showerhead shall
have a 5-15/16″ (151 mm) diameter showerhead and a 1/2″-14 NPT connection. Showerhead shall feature a 1.75 gpm (6.6 L)
per minute flow rate. Showerhead shall be available with a 3-function showerhead with wide coverage, medium coverage and
concentrated spray options. Showerhead shall complement Forte suite. Showerhead shall be Kohler Model K-10240-____.
Page 1 of 2
1101925-4-
C
USA/Canada: 1-800-4KOHLER
(1-800-456-4537)
www.kohler.com
FORTÉ
®
Installation Notes
Install this product according to the installation guide.
Ø 5-15/16" (151 mm)
FORTɮMULTI-FUNCTION SHOWERHEAD
Page2of2
1101925-4-
C
1/2"-14 NPT
4-11/16"
(119 mm)
Product Diagram
