Features
Metal construction
•
Complements the Forté
•
Traditional faucet line
Can be positioned facing up or down
•
Maximum 100-W bulb (not supplied) required for
•
each light
Sculpted and Forté
®
Codes/Standards Applicable
Specified model meets or exceeds the following:
UL 1598
•
CSA C22.2 No. 250.0
•
Specified Model
TRANSITIONAL WALL SCONCE
ALSO K-11366, K-11367
Colors/Finishes
CP: Polished Chrome
•
BN: Brushed Nickel
•
G: Brushed Chrome
•
K-11365
Model Description Colors/Finishes
K-11365 Wall sconce – single-light ❑ CP ❑ BN ❑ G
K-11366 Wall sconce – double-light ❑ CP ❑ BN ❑ G
K-11367 Wall sconce – triple-light (shown) ❑ CP ❑ BN ❑ G
Product Specification
The wall sconce shall be of metal construction. Product shall include installation hardware. Product shall require a maximum
100-W bulb (not supplied) for each light. Product shall be positioned facing up or down. Product shall complement the Forté
Sculpted and Forté Traditional faucet line. Wall sconce shall be Kohler Model K-____-____.
Page 1 of 2
1041770-4-
USA/Canada: 1-800-4KOHLER
E
(1-800-456-4537)
www.kohler.com
Installation Notes
Install this product according to the installation guide.
23" (584 mm)
K-11367
5-7/16"
(138 mm)
K-11365
TRANSITIONAL WALL SCONCE
Page2of2
1041770-4-
E
6-7/16"
(164 mm)
6-1/2"
(165 mm) 8-3/4"
(222 mm)
Side View
5-7/16"
(138 mm)
15-7/16" (392 mm)
K-11366
Product Diagram
