Kohler K1191-L, K1191-LC, K-1191-RC, K1191-R User Manual

Installation Guide
Purist™ Effervescent Bath
K-1191-L, K-1191-R, K-1191-LC,
M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (e.j.
K-12345M) Français, page “Français-1” Español, pagina “Español-1”
1012493-2-A
Important Information
WARNING: When using electrical products, basic precautions should always be followed, including the following:
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI).
WARNING: Risk of electric shock. A licensed electrician should make all electrical connections.
WARNING: Risk of electrical shock. Disconnect power before servicing.
WARNING: Risk of injury or property damage. Please read all instructions thoroughly before
beginning installation, including the following requirements.
NOTICE: Follow all local plumbing and electrical codes.
Install to permit access for servicing. A green lead wire is provided within the wiring compartment. To reduce the risk of electrical shock, connect
this wire to the grounding terminal of your electric service or supply panel with copper wire equivalent in size to the circuit conductor supplying this equipment.
A pressure wire connector is provided on the exterior of the pump or control within this unit to permit connection of a bonding conductor between this unit and all other exposed metal in the vicinity, as needed to comply with local requirements.
Grounding is required. The unit should be installed by a qualified service representative, and grounded. Building materials and wiring should be routed away from the pump body and other heat-producing
components of the unit.
Important Product Information
Product Notices
WARNING: Unauthorized modification may cause unsafe operation and poor performance of the effervescent bath. Do not relocate the pump, or make other modifications to the overflowing bath
system, as this could adversely affect the performance and safe operation. Kohler Co. shall not be liable under its warranty or otherwise for personal injury or damage caused by any such unauthorized modification.
Product Inspection
Carefully unpack the product, and inspect the unit for damage. Return the unit to the carton during construction to prevent damage.
NOTICE: Make sure the union connections to the pump and in-line heater are securely tightened. Do not overtighten.
Factory-Assembled Features
Factory installed components include pump, in-line heater, submerged chromatherapy lights, control and switch. The pump and piping are factory-assembled.
Connections and Service Access
NOTICE: Provide unrestricted service access to the pump. Provide unrestricted service access to the pump, in-line heater, and control box. You must construct an access panel to provide sufficient clearance for servicing the pump, in-line heater, and control box. The access panel must be located immediately next to the pump and in-line heater. Study the roughing-in information.
1012493-2-A 2 Kohler Co.
Important Product Information (cont.)
Electrical Requirements
The installation must have a Class A Ground-Fault Circuit-Interrupter (GFCI). The GFCI protects against line-to-ground shock hazard. Use a 240V, 15A, 60 Hz dedicated service.
An equipment grounding terminal is provided in the field wiring compartment. To reduce the risk of electrical shock, this terminal must be connected to the grounding means provided in the electrical supply panel with a conductor equivalent in size to the circuit conductors supplying this equipment.
Install this unit in accordance with the Canadian Electric code, Part I.
Table of Contents
Important Information .............................................................. 2
Important Product Information ....................................................... 2
Product Notices ................................................................ 2
Product Inspection .............................................................. 2
Factory-Assembled Features ...................................................... 2
Connections and Service Access ................................................... 2
Electrical Requirements .......................................................... 3
Thank You For Choosing Kohler Company .............................................. 4
Recommended Tools and Materials ................................................... 4
Introduction ..................................................................... 4
Before You Begin ................................................................. 4
List of New Terms ................................................................ 5
Roughing In Information ............................................................ 7
Construct the Stud Framing ......................................................... 7
Install the Rough Plumbing .......................................................... 7
Prepare the Unit ................................................................. 7
Position the Unit ................................................................. 8
Install the Plumbing ............................................................... 8
Make the Electrical Connections ...................................................... 9
Test Run the Bath ................................................................ 9
Check the Connections and Fill the Unit .............................................. 9
Test the Control Switch .......................................................... 9
Complete the Finished Wall or Deck .................................................. 11
Install the Faucet Trim ............................................................ 11
Clean-Up After Installation ......................................................... 11
Using Your Bath ................................................................. 12
Fill the Bath .................................................................. 12
Operating Sequence ........................................................... 12
Chromatherapy Light Operation ..................................................... 13
Kohler Co. 3 1012493-2-A
Thank You For Choosing Kohler Company
We appreciate your commitment to Kohler quality. Please take a few minutes to review this manual before you start installation. If you encounter any installation or performance problems, please don’t hesitate to contact us. Our phone numbers and website are listed on the back cover. Thanks again for choosing Kohler Company.
Recommended Tools and Materials
Pipe Wrench
Assorted Screwdrivers
Adjustable Wrench
Plumbers Putty
Strap Wrench
Thread Sealant
Hacksaw or Tube Cutter
Propane TorchSolder
Introduction
Please read these instructions carefully to familiarize yourself with the required tools, materials, and installation sequences. Follow the sections that pertain to your particular installation. This will help you avoid costly mistakes. In addition to proper installation, read all operating and safety instructions.
All information in this manual is based upon the latest product information available at the time of publication. At Kohler, we constantly strive to improve the quality of our products; we therefore reserve the right to make changes in product characteristics, packaging, or availability at any time without notice.
Before You Begin
This product is designed for drop-in island installation. Undermount and alcove installations are also
possible.
You must install the bath onto an adequately supported, level subfloor.
Provide properly dimensioned framing.
Choose a fill spout which will provide adequate reach and a minimum 2” (5.1cm) air gap above the
bathing well rim of the unit. You may need to build up the deck material to obtain adequate air space
because the outer rim may be lower than the bathing well rim depending on the specific area of the bath.
Follow local plumbing codes.
The unit must be filled with water through the bathing well, not the overflow channel.
If you plan to install a deck-mounted, hand-held shower, the diverter vacuum breaker must maintain a
minimum 1” (2.5cm) air gap above the outer rim.
When using the K-922 or K-923 Laminar Bath Spout with drip tray K-924, the distance from the finished
wall to the outside wall of overflow channel should not exceed 2” (5.1cm).
1012493-2-A 4 Kohler Co.
System Controll ( On/Of f )
Chromatherapy
Lights
Pump Motor
Bathing Well Rim
Bathing Well
Effervescence Port
Overflow Drain
Overflow
Channel
Chromatherapy Light Control
1. List of New Terms
Bathing well-The deep portion on the bath used by the bather.
Bathing well rim-The high rim between the bathing well and the overflow channel. Water will cascade
over the bathing well rim and into the overflow channel when entering the bath.
Cavitation-When air is drawn into the pump instead of water to a point where it impairs or stops the
pump’s ability to circulate water.
Chromatherapy lights-Lights provided in the basin of the bath to enhance your bathing experience.
Outer rim-The rim along the outside of the bath.
Overflow channel-The overflow water collection channel at the drain end.
Plastic suction cover-The plastic guard attached over the water intake port located in the bathing well.
The suction cover must always be installed during product use to ensure user safety.
Kohler Co. 5 1012493-2-A
