Kogan XU9220 Quick Start Guide

QUICK START GUIDE

55” SMART HDR 4K LED TV

SERIES 9 XU9220

(KALED55XU9220STA)

COMPONENTS

A

B D

E

A Kogan 55” Smart

HDR 4K LED TV

B Remote control
C Stand (x2)

C

QUICK START GUIDE

55” SMART HDR 4K LED TV

SERIES 9 XU9220

(KALED55XU9220STA)

F

G

D M4 x 25mm screw (x4)
E AAA battery (x2)
F Quick-start guide
G Warranty card

NOT INCLUDED

Phillips head screwdriver, antenna cable, broadband internet connection.

3

REMOTE CONTROL OVERVIEW

1

3

4

6

8

10

12

1 Power, press to enter or exit

standby mode

2

Mute to toggle sound on/o

3 Number buttons

to select channels

or input passwords

INFO displays the current program

4

information

5

EPG Electronic Program Guide in DTV

mode

6

Device preferences to display

sound and picture options

2

5

7

9

11

13

Source displays the list of input

7

source channels.

/// Direction buttons for

8

navigating menus and settings

OK Enter select the current item

9

or confirm selection, display Channel
list in DTV mode

10

Quick Menu to display TV options

with optional, adjustable settings

Back to the previous menu

11

12

13

to open app homepage

to open app homepage

4

14

16

17

21

15

18

19

20

14 to open app homepage

15

16

to open app homepage

Google Assistant to launch the

built-in virtual assistant for voice
commands

17

- Volume to adjust the volume

+

up or down

18

19

20

Program to scroll channels

Home to access the home page

Teletext to show/hide Teletext

(Teletext not available in Australia
or New Zealand)

Press to switch to the USB source.

USB

Audio to select available

languages and audio channels.

SUBT

Subtitles to select subtitles

Start playback in media mode;

MIX mode in teletext

II Pause in media/PVR mode;

Timeshi function in DTV mode

Stop in media/PVR mode;

Hold teletext page on display,

press again to release

Record in DTV mode;

Change size of teletext screen

Reverse playback rapidly in

media mode;

Subtitle mode, or

Submenu

Skip to previous in media mode;

Index page

Skip to next in media mode;

Reveal hidden information in

some teletext pages

Advance playback rapidly in

media mode;

Cancel teletext but not exit

Colour buttons for navigational use

21

within apps

5

ASSEMBLY AND INSTALLATION

BEFORE YOU GET STARTED

Spread cushioning flat to lay the TV on. This will help to prevent damage.

1. Stand assembly

a. Attach stands to base of TV, ensuring ‘L’ and ‘R’ markings on the TV

and stands match.

b. Insert two 25mm screws for each stand and use Phillips head

screwdriver (not supplied) to tighten.

1a

2. Remote control assembly

a. Open the battery compartment cover on the back side.
b. Insert two 1.5V AAA size batteries, making sure to match the polarity

markings (+ / -) of the batteries with the diagram inside
the compartment.

c. Replace battery compartment cover.

1b

2a 2b 2c

6
