Page 1
QUICK START GUIDE
40” SMART FULL HD LED TV
SERIES 9 RF9220
(KALED40RF9220STA)
Page 2
COMPONENTS
A
B D
E
A Kogan 40” Smart
Full HD LED TV
B Remote control
C Stand (x2)
C
QUICK START GUIDE
40” SMART FULL HD LED TV
SERIES 9 RF9220
(KALED40RF9220STA)
F
G
D M4 x 20mm screw (x4)
E AAA battery (x2)
F Quick-start guide
G Warranty card
NOT INCLUDED
Phillips head screwdriver, antenna cable, broadband internet connection.
3
Page 3
REMOTE CONTROL OVERVIEW
1
3
4
6
8
10
12
1 Power, press to enter or exit
standby mode
2
Mute to toggle sound on/o
3 Number buttons
to select channels
or input passwords
INFO displays the current program
4
information
5
EPG Electronic Program Guide in DTV
mode
6
Device preferences to display
sound and picture options
2
5
7
9
11
13
Source displays the list of input
7
source channels.
/// Direction buttons for
8
navigating menus and settings
OK Enter select the current item
9
or confirm selection, display Channel
list in DTV mode
10
Quick Menu to display TV options
with optional, adjustable settings
Back to the previous menu
11
12
13
to open app homepage
to open app homepage
4
Page 4
14
16
17
21
15
18
19
20
14 to open app homepage
15
16
to open app homepage
Google Assistant to launch the
built-in virtual assistant for voice
commands
17
- Volume to adjust the volume
+
up or down
18
19
20
Program to scroll channels
Home to access the home page
Teletext to show/hide Teletext
(Teletext not available in Australia
or New Zealand)
Press to switch to the USB source.
USB
Audio to select available
languages and audio channels.
SUBT
Subtitles to select subtitles
Start playback in media mode;
MIX mode in teletext
II Pause in media/PVR mode;
Timeshi function in DTV mode
Stop in media/PVR mode;
Hold teletext page on display,
press again to release
Record in DTV mode;
Change size of teletext screen
Reverse playback rapidly in
media mode;
Subtitle mode, or
Submenu
Skip to previous in media mode;
Index page
Skip to next in media mode;
Reveal hidden information in
some teletext pages
Advance playback rapidly in
media mode;
Cancel teletext but not exit
Colour buttons for navigational use
21
within apps
5
Page 5
ASSEMBLY AND INSTALLATION
BEFORE YOU GET STARTED
Spread cushioning flat to lay the TV on. This will help to prevent damage.
1. Stand assembly
a. Attach stands to base of TV, ensuring ‘L’ and ‘R’ markings on the TV
and stands match.
b. Insert two 20mm screws for each stand and use Phillips head
screwdriver (not supplied) to tighten.
1a
1b
2. Remote control assembly
a. Open the battery compartment cover on the back side.
b. Insert two 1.5V AAA size batteries, making sure to match the polarity
markings (+ / -) of the batteries with the diagram inside
the compartment.
c. Replace battery compartment cover.
2a 2b 2c
6
Page 6
3. Connect to antenna
a. Connect an antenna cable (not supplied) via the ‘ANT’ input port at
the back of the TV.
b. Ensure the antenna cable is also connected to a working antenna,
either via an antenna wall socket in your home, or directly.
Antenna
wall socket
3b
3a
ANT
Antenna cable
(not supplied)
4. Turning TV on
Plug the power cord into a suitable power outlet, then press the
POWER (
) button on the remote control, making sure to aim it at the
sensor at the front of the TV. Alternatively, you can press the power
button on the lower side of the back panel on the TV.
TURNING TV OFF
Press the
To p o w er d o w n t h e T V c o m p le t e l y , u n p l u g t h e p ow e r c o r d f r o m t h e p ow e r
outlet.
Do not leave your set in standby mode for long periods of time. If you will
not use the TV for a long time, it is recommended to unplug the set from
both the power outlet and aerial.
POWER ( ) button on the remote control to enter standby mode.
7
Page 7
FIRST TIME SETUP
When turning the TV on for the first time, the Welcome screen will
appear. Use the , and OK buttons to navigate the following options.
Bluetooth
Your Android TV remote control has bluetooth capabilities. Follow the
onscreen prompts to pair the remote with the TV. This will allow you to
use voice commands with your remote via the Google Assistant button.
Language
Select your menu language.
Quickly set up with Android phone
If you have an Android smartphone, you can easily transfer your phone’s
Wi-Fi network and Google account to your TV. If not, select ‘Skip’.
Select Wi-Fi network
Your Android TV will automatically scan for wireless networks nearby.
Ensure the TV is within range of your wireless modem or router, and have
your password handy. Follow the prompts to input your password and
connect your TV to your selected network.
If you’d prefer to connect an Ethernet cable to connect to the internet,
simply insert the cable (not supplied) to the ‘LAN’ input port at the back
of the TV (4a), and ensure that it is correctly connected to the internet.
Google Account sign-in
Linking your Google Account to your Android TV will allow you to install
new apps from the Play store, as well as receive recommendations,
movies, and more from Google.
Te r m s o f S e r v i c e
This page will allow you to read each of the Google Terms of Service,
Privacy Policy, and Google Play Terms of Service in full, and to accept.
Location
Grant permission for your Android TV to detect your location. You can
adjust these permissions at any time from Settings.
Help improve Android
Grant permission for your Android TV to detect your location to
automatically send diagnostic information to Google.
8
Page 8
4a
LAN
‘LAN’ input
HDMI 3
HDMI 2
USB 2.0
(5V 500mA)
HDMI 1
(ARC)
ANT
DIGITAL
AUDIO OUT
AV IN
USB 2.0
(5V 500mA)
4b
‘ANT’ input
Following these options, the Auto Tuning screen will appear. Ensure you
have an antenna cable connected to the ‘ANT’ input port at the back of
the TV (4b).
The auto tuning function will search for and save all available free-to-air
TV channels. After confirming your settings (the default will be set for
Australia), the process will automatically begin. The number of searched
channels will be displayed on the screen.
When setup is complete, you will be able to access the Home page.
9
Page 9
HOME PAGE
1 3 4 52 6 7
8
10
11
12
1 Google Assistant
Click to launch the built-in virtual
assistant, which will begin listening
for voice commands. Give it a try, ask
“What’s the weather today?”
2 Text search
Enter text manually to search TV apps.
3 System notifications
This option will only appear when
notifications are present.
4 Source
Access free-to-air channels (‘DTV’)
or other input source channels.
5 Internet connection
This will display as a Wi-Fi or LAN icon,
depending on your connection. Select
for connectivity options.
6 Settings
Access the global settings menu.
7 Clock
Time and date settings can be adjusted
in the global settings.
9
8 Apps
Access the App Centre to display all
installed apps. Free-to-air channels can
be accessed under the ‘Live TV’ option.
9 Favourites list
A customisable list of apps available at
a single click.
10 Play next
Displays the program you are watching
or have queued to play next. You can
add to this list by long pressing the OK
button, then selecting “Add to play
next”. If the play next queue is empty, it
will not be shown on the home page.
11 Pinned channels
Show the program list of pinned
channels. The order of this list can be
adjusted by pressing from the channel
icon and selecting the “<>” icon. Empty
channels will not be shown on the home
page.
12 Customise channels
Add or remove pinned channels from
the home page.
10
Page 10
SETTINGS
Global settings
To a c c e ss t h e g l o b al s et t i n g s m e n u , s i m p l y n a v i g at e to t he ‘ ’ icon
on the Home screen. Here you will find all of the adjustable options for
Android TV’s interface, connectivity, and apps.
(5a)
In DTV mode you can also press the
remote control and use the / buttons to navigate to the Settings
option.
Quick Menu
button on your
5a
Quick Menu
Options for your TV (picture, aspect ratio, speakers, etc) can be
accessed by pressing the button on your remote control.
Use / buttons to navigate through the submenus, and / buttons to
access Channel and Recording/Time Shift options.
Quick Menu
uick enu
Device preferences
To open the device options submenu directly during live TV playback,
press the
Device preferences
button on your remote control.
11
Page 11
BASIC TROUBLESHOOTING
Poor picture and sound quality
• Tr y a d i f f e r en t c h a n n e l
• Adjust the antenna
• Check all connections
No picture or sound in TV status
• Tr y a n o t h e r c ha n n e l
• Press the TV/AV button
• Make sure TV is plugged in
• Check the antenna connection
No sound or sound is too low at
maximum volume
• Check the volume settings on any
external speakers connected to your
television
• Adjust the TV volume accordingly
• Check another channel or input
• Check that MUTE hasn’t been
turned on
No colour, wrong colour or tints
• Make sure the program itself is
broadcast in colour
• Select the picture menu, then adjust
the colour and tint submenus
Remote control malfunctions
• Replace remote control batteries
• Check battery terminals
• Remote is out of range, move closer
to TV
• Remove any obstructions between
remote and IR sensor of TV
• Make sure the power cord to your TV
is plugged in and turned on
Image is not centred on the screen
• Adjust the horizontal and vertical
position
“No Signal” on HDMI source
• Test the device with a different HDMI
cable
• Plug the device into another HDMI
port
• Try a different device connected to
the same cable and port
• Perform a factory reset on your TV
For our full TV troubleshooting guide
and extended User Manual for this
TV, head online to help.kogan.com
Picture rolls vertically
• Check all connections
Blurred or snowy picture, distorted
sound
• Check direction, location and
connections to your antenna
• Issues may be caused by the use of
an indoor antenna (poor signal)
12
Manufactured under license from Dolby
Laboratories, Dolby, Dolby Audio, and
the double-D symbol are trademarks of
Dolby Laboratories.
Page 12
NOTES
13
Page 13
NOTES
14
Page 14
15
Page 15
Need more information?
This is a Quick Start Guide, and while we hope that this
has given you the assistance needed for a simple set-up,
a full user guide outlining all of this product’s instructions
and features can be found online at help.kogan.com
