Page 1
OUTDOOR FESTOON
STRING LIGHT – 20M
WITH LED FILAMENT BULBS
NBOTLTFL20A, NBOTLTFL2BA
Page 2
Page 3
SAFETY & WARNINGS
Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
• Ensure the power cord is unplugged before installing, connecting, or when replacing the
LED filament bulbs.
• Ensure the power cord is unplugged when servicing the string light.
• CAUTION: Do not replace the LED filament bulbs during rain or when the string light is
wet.
• WARNING: To prevent breakage during windy conditions, install the bulbs far enough
apart to prevent them from hitting each other.
• If using extension cords, do not use them near water.
• To prevent the risk of electric shock, do not submerge the string lights into water.
• The voltage of this string light is 220-240V. Ensure the power socket used matches this
voltage.
• Keep the power cord in a dry place.
• To prevent damage or abrasion, do not expose the string light to edges of sheet metal
or other sharp objects.
• Cover empty lightbulb sockets and the ends of the string light with caps to limit
corrosion and wear and tear.
• If connecting multiple string lights together, do not exceed a combined power of 700W
and/or reach a length of 200m.
• If connecting multiple string lights together, ensure there is support near the power
socket to prevent the power cord from being pulled out.
Page 4
COMPONENTS LIST
• String light (x1)
• LED filament bulb (x20)
• User guide (x1)
INSTALLATION
Step 1: Arrange the string light to your liking.
It can be arranged on the surface or be secured using additional fixings sold separately
(nails, cup hooks, zip ties, or guide wires).
Arranged on surface Secured using a nail Secured with a cup hook
Secured using a zip tie Secured using a guide wire
Page 5
Step 2: Twist and secure the LED filament bulbs to the string light.
Female
Male
Note:
Step 3: Connect the male end of the string light to the power cord and connect the power
cord to a socket. Switch the power on.
Connecting two or more string lights
To connect two or more string lights, follow the steps and diagram below.
• Connect the female connector of string light 1 into the male connector of string light 2.
• Continue connecting additional string lights the same way (female to male).
• Connect the male connector of string light 1 into a socket and switch the power on.
String light 1
String light 2
Do not exceed a combined power of 700W and/or reach a length of 200m.
Page 6
SPECIFICATIONS
Power 220-240V
Socket E27 (Edison bulb, 27mm)
Wattage 2W per bulb
Length 20m
Page 7
Page 8
Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
