Package Contents
Bluetooth Keyboard
Charging Cable (If using the Apple “30 pin” charging interface, this is not needed)
SPECIFICATIONS
Executive Standard: Bluetooth V3.0
Working Distance: 10 metres
Modulation System: FHSS 2.4G
Transmitting Power: Class 2
Operating Voltage: 3.0-5.0V
Working Current: <5.0MA
Standby Current: 2.5MA
Sleeping Current: <200uA
Charging Current: >100mA
Standby Time: 100 days
Theoretical Working Time: 25 days
Uninterrupted Working Time: 90 Hours
Charging Time: 4 – 4.5 hours
Li-ion Battery Capacity: Minimum of 430MAH
Lithium Battery Life: 3 years
Lithium Battery Specifications: 4.5 x 24 x 47mm
Key Strength: 80 +_ 10g
Operating Temperature: -20 – 55C
Storage Temperature: -40 – 70C
PRODUCT FEATURES
With AIROHA 3.0 as the main control chip, bundled with Bluetooth 3.0 interface.
Specifically designed for use with iPad and can be safely carried in an iPad case/bag.
Silent operation design.
Waterproof, dust-proof, anti-pollution.
Works with PC and commercial mobile devices.
Operating temperatures are between -20C and 50C.
Built-in lithium battery, meaning less battery charges.
Note: When you switch on the keyboard, the Bluetooth light will flash for 3 seconds. At this time
the keyboard will not connect to any devices. Once the light comes on for 5 seconds solidly then it
can be connected.
INSTALL BLUETOOTH KEYBOARD
1 – How to install the bluetooth keyboard onto an iPad
Step 1: (1) as shown below, turn on the toggle switch. The Bluetooth light flash for 3 seconds, then
it will go out. At this time, the keyboard is in working condition.
(2) Press the connect button, then the keyboard light will be on and the keyboard will await
a connection.
(3) Click settings on the screen of the iPad, then choose Bluetooth and find the keyboard
listed under the available connections.
Step 2: Enter the correct password and connect.
NOTE: There won't be any prompt, just click ENTER after you enter the password on your iPad
screen. It will connect successfully.
Step 3: Connect successfully and the keyboard is in working condition.
All lights will be off once the keyboard has connected successfully.
CHARGING
While in use, if the charge light starts flashing, it signals that the battery is running low on power
and may need recharging.
CHARGING PROCEDURE
1) Use the iPad charger/USB charging cable plugged into a wall outlet, with the other end
plugged into the keyboard USB charging port.
2) The red indicator will flash. When charging has finished, the light will go off. (Approx
charging time is 4 hours.)
STORAGE
1. When you have finished using the keyboard, please turn the keyboard OFF to preserve and
extend the battery life for further use.
2. When you need to store the keyboard for a long period of time without use, please charge
the battery for approximately 2 hours beforehand to make the life of your lithium battery
longer.
ATTENTION
• Keep away from sharp objects.
• Do not place heavy objects on the keyboard.
• Do not heat keyboard in a microwave or oven.
• Do not twist or squeeze the keyboard.
• Key away from oil, water or other liquids.
FAQ
If you are unable to connect the Bluetooth Keyboard to the computer, or the keyboard is working
unconventionally, please try the following steps.
1. Before you install your Bluetooth keyboard, please be sure to have installed any bluetooth
dongles that may be required prior to operation with your computer.
2. Press and release the connect on the Bluetooth Keyboard. The blue LED light will change
into a flashing mode.
3. Make sure that the keyboard is within the effective range of 10 metres.
4. Make sure that there is no change in the Bluetooth setup. If anything has changed, please
repair the units.
5. If your computer/tablet is connected to multiple devices, please disconnect any Bluetooth
devices that are not required.
6. Please check the batteries. If they are short of power, please recharge or replace them.
7. Check the unit itself for any signs of damage.
Every time you turn on the keyboard after a reboot or the computer shuts down, there is no
response.
1. After the keyboard has been fully charged, turn on the computer and re-install the keyboard
to the computer from a fresh install.
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device.
Pursuant to Part 15 of the FCC rules, these limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed or used in accordance with instructions, may
cause harmful interference to devices. Please correct the interference with one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult with the Kogan customer support team or a radio/TV technician for assistance.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions.
1. This device may not cause harmful interference when used.
2. This device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any change or modifications not expressly approved by Kogan for compliance could
void the user's authority to operate this equipment.
IMPORTANT NOTE
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operation instructions for satisfying RF exposure
compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Important Tip: After your keyboard has been connected to a computer, tablet or smartphone, you
have 15 minutes where if you do not use it, the keyboard will enter a dormant state. Just press any
key and wait 3 seconds for the keyboard to become active again.
