USER MANUAL

SAFETY INFORMATIONS

TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.

: To reduce the

risk of fire and electric shock, do
not remove the cover (or back) of
the unit. Refer servicing only to qualified service personnel.

The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT AND FULLY INSERT.

The apparatus shall not be exposed to dripping or splashing, and that no
objects filled with liquids, such as vases, shall be place on the apparatus.
Batteries shall not be exposed to excessive heat such as sunshine,fire or the like.
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Where the mains plug or a appliance coupler is used as the disconnect device ,
the disconnect device , the disconnect device shall remain readily operable.

CAUTION

IMPORTANT SAFEGUARDS

In addition to the careful attention devoted to quality standards
in the manufacture of your video product, safety is a major factor
in the design of every instrument. However, safety is your
responsibility, too. This sheet lists important information that will
help to assure your enjoyment and proper use of the video
product and accessory equipment. Please read them carefully
before operation and using your video product.

Installation

Read and Follow Instructions- All the safety and operation instructions

1.
should be read before the video product is operated. Follow all
operating instructions.

Retain Instructions- The safety and operating instructions should be

2.
retained for future reference.

Heed all Warnings-Comply with all warnings on the video product and in

3.
the operating instructions.

Polarization- Some video products are equipped with a polarized

4.
alternating -current line plug. This plug will fit into the power outlet, try
reversing the plug. If the plug still fails to fit, contact your electrician to
replace your obsolete outlet. To prevent electric shock, do not use this
polarized plug with an extension cord, receptacle, or other outlet unless
the blades can be fully inserted without blade exposure. If you need an
extension cord, use a polarized cord.

Power Sources- This video product should be operated only from the

5.
type of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your video dealer or
local power company. For video products intended to operate from
battery power, or other sources, refer to the operating instructions.

Overloading- Do not overload wall outlets or extension cords as this can

6.
result in a risk of fire or electric shock. Overloaded AC outlets, extension
cords, frayed power cords, damaged or cracked wire insulation, and
broken plugs are dangerous, They may result in a shock or fire hazard.
Periodically examine the cord, and if its appearance indicated damage or
deteriorated insulation, have it replaced by your service technician.

Power-Cord Protection- Power-supply cords should be routed so that

7.
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the video product.

Ventilation- Slots and openings in the case are provided for ventilation

8.
to ensure reliable operation of the video product and to protect it from
overheating. These openings must not the blocked or covered. The
openings should never be blocked by placing the video product on a
bed, sofa, rug, or heat register. This video product should not be placed
in a built-in installation such as a book case or rack, unless proper
ventilation is provided or the video product manufacturer's instructions
have been followed.

Attachments- Do not use attachments unless recommended by the video

9.
product manufacturer as they may cause hazards.

10.

Water and Moisture- do not use this video product near water for example,
near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or
near a swimming pool and the like. Caution: Maintain electrical safety.
Powerline operated equipment or accessories connected to this unit should
bear safety certification mark on the accessory itself and should not be
modified so as to defeat the safety features. This will help avoid any and should
not be modified so as to defeat the safety features. This will help avoid any
potential hazard from electrical shock or fire. If in doubt, contact qualified
service personnel.

11.

Accessories- Do not place this video product on an unstable cart, stand, tripod,
bracket, or table. The video product may fall, causing serious injury to a child or
adult as well as serious damage to the video product. Use this video product
only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer's or sold with the video product. Any mounting of the product
should follow the manufacturer's instructions and use of a mounting accessory
recommended by the manufacturer.

11a.

A video product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the video product and cart
combination to overturn.
Note to CATV system installer
This reminder is provided to call the CATV system installer's attention to
Section 820-40 of the NEC which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.

12.

Outdoor Antenna Grounding- If an outside antenna or cable system is
connected to the video product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and built-up
static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70­1984 (Section 54 of Canadian Electrical Code, Part1) provides information with
respect to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.

13.

Power Lines-An outside antenna system should not be located in the vicinity of
overhead power lines, other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching or approaching such
power lines or circuits, as contact with them might be fatal. Installing an
outdoor antenna can be hazardous and should be left to a professional
antenna installer.

Use

14.

Cleaning- Unplug this video product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

15.

Objects that may touch dangerous voltage points or "short-out" parts could result in
a fire or electric shock. Never spill liquid of any kind on the video product.

16.

Lightning-For added protection for this video product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to
the video product due to lightning and power line surges.

Service

17.

Servicing-Do not attempt to service this video product yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.

18.

Conditions Requiring Service-Unplug this video product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
A.When the power-supply cord or plug is damaged.
B.If liquid has been spilled, or objects have fallen into the video product.
C.If the video product has been exposed to rain or water.
D.If the video does not operate normally by following the operating instructions.
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the video product
to its normal operation.
E.If the video product has been dropped or cabinet has been damaged.
F.When the video product exhibits a distinct change in performance-this
indicates a need for service.

19.

Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety characteristics
as the original parts. Use of replacements specified by the video product
manufacturer can prevent fire, electric shock, or other hazards.

20.

Safety Check-Upon completion of any service or repairs to this video product, ask the
service technician to perform safety checks recommended by the manufacturer to
determine that the video product is in safe operating condition.

21.

Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.

22.

Heat-The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that products heat.

CONTENTS

SAFETY INFORMATION

INTRODUCTION
Front panel

Rear panel
Remote control

SYSTEM CONNECTION
General

Connecting the TV
Connecting a HiFi System

GETTING STARTED

Welcome
Installation

OPERATION

Changing channels
Access the Electronic Programme Guide(EPG)

EDIT CHANNEL
Edit Channel menu

TV Channel list
Radio Channel list
Delete All

SYSTEM SETUP
System setup menu
Language
TV System
Local Time Setting
Timer Setting
Parental Lock
OSD Setting
Favorite
Auto Standby

TOOLS
Tools main menu
Information
Load Factory Setting
Software Upgrade
Remove USB device safely

GAMES
Game

REC

REC main menu
USB Device
Record Manager
DVR HDD Information
HDD Format
DVR Configuration

TIMESHIFT/RECORD
Timeshift
Record

TROUBLESHOOTING

SPECIFICATIONS

1
1
2

3
3
3

4
4

5
5

6
6
6
6

7
7
7
7
7
8
8
8
8

9
9
9
9
10

11

12
12
12
12
12
13

14
14

15

16

INTRODUCTION

Front panel

Display

Power indicator

Remote sensor

USB

USB port Standby button

Rear panel

TV aerial
for an external TV aerial

Coaxial Digital Audio

RF OUT RF OUT Coaxial Coaxial

RF INRF IN

RF Loop through
for an external device

Component Video
(Y Pb Pr)

PbPb

PrPr

English

1

1

HDMI Output

HDMIHDMI

Composite Video

AC Mains

CVBSCVBS

RR LLYY

AC 220-240V
~50/60HZ

Down Mix Audio
2 Channel L/R

INTRODUCTION

Remote control

STANDBY

1

2

3

4

5

MENU

6

7

VOL-

8

RECORD

9

10

MEDIA

11

12

13

14

1

2

3

TTX TIMER

STANDBY
(switch the STB on and standby)

INFO
(Press for current channel information )

PLAY

INFO

SUBTITLE

CH+

OK

CH-

TV/RADIO

MUTE

AUDIOUSB

FAV

EXIT

BACK

4

Previous/Next

5

PAUSE(Pause/Active timeshift function)

6

Menu
(Open and close the menu screen)

15

7

Cursor/CH+, -/VOL+,-

16

(Cursor: Navigation buttons used to navigate
menu's items)
(CH+/-: Channel Up and Down)
(VOL+/-: Volume Up and Down)

17

8

OK button
(Confirm a selection within a menu)

9

RECORD
(Record the TV program)

18

10

Numeric entry
(Enter numeric values and select the channel

VOL+

EPG

RES

directly by entering it's number)

11

USB
(Enter File Manager)

12

MEDIA

19

(Enter Recorder menu)

13

TTX (Open interactive service)

20

14

TIMER
(Timer wake-up)

21

15

MUTE (Turn off/on the volume)

16

SUBTITLE (On/Off Subtitle)

17

Search backward /forward

22

23

18

EXIT (Exit from menu)

24

19

STOP
(Stop program playback or recording)

25

20

EPG
(Open up Electronic Program Guide Menu)

26

BACK

21

(Switch to previous channel)

22

TV/RADIO
(Switch between TV and Radio)

23

AUDIO
(Select audio mode and audio track)

24

RES (Switch HDMI resolution)

25

FAV
(Open the Favorite list)

26

RED/GREEN/YELLOW/BLUE Buttons
(For interactive function/Submenu
function buttons)

1

2

English

SYSTEM CONNECTION

General

There are many different types of TV and other equipment that you can connect to the STB.
In this manual you will see some of the most common ways to connect your equipment.

Connecting the TV

Antenna

RF cable

Connecting a HiFi system

Hi-Fi

Y Pb Pr cable

HDMI cable

RF INRF IN

Coaxial cable

RF INRF IN

English

1

3

RF OUT RF OUT Coaxial Coaxial

RF OUT RF OUT Coaxial Coaxial

TV

PbPb

CVBSCVBS

PrPr

PbPb

RR LLYY

AC 220-240V

AC 220-240V

~50/60HZ

HDMIHDMI

PrPr

~50/60HZ

CVBSCVBS

RR LLYY

AC 220-240V

AC 220-240V

~50/60HZ

HDMIHDMI

~50/60HZ

GETTING STARTED

Welcome

If you use the STB for the first time, the "Welcome" menu appears.
Press cursor button to setup the Region, Language, Display Mode
and Aspect Mode.
Highlight "OK" and press the "OK" button to start channel search.

Installation

1

Press the "MENU" button to enter main menu.

2

Press "UP"or " DOWN " button to highlight "Installation", press
"RIGHT" button to enter the Installation menu.

3

Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK"button to enter the sub-menu .

4

Press "EXIT" button to exit.

Region

Language
Display Mode
Aspect Mode

Auto Scan
Channel Scan
Aerial Adjustment
LCN

Welcome

OK

Installation

Poland
English

576i
Auto

Auto Scan

1

Select the "Auto Scan", press "OK" button to enter the Auto Scan menu.

2

Press the cursor button to set "FTA Only", then highlight "Search",
press the "OK" button to start auto scan .

FTA Only
Search

Auto Scan

Channel Scan

1

Select "Channel Scan", press the "OK" button to enter the Channel
Scan menu.

2

Press cursor button to set Scan mode, Scan Band ,
Channel No., Frequency and Bandwidth, then highlight "Search",
press "OK" button to start channel scan .

Channel Scan mode:

By channel
By frequency

Aerial Adjustment

1

Select the "Aerial Adjustment", press"OK" to enter the Aerial
Adjustment.

2

Press the cursor button to set the desired setting.
When "Tuner Power" is selected "On", the STB will provide 5V power
to antenna.
It will not provide when selected "Off".

Channel Scan

Scan Mode
Scan Band
Ch No.

Frequency
Bandwidth

Search

Signal Intensity
Signal Quality

Aerial Adjustment

Ch No.
Tuner Power

Signal Intensity
Signal Quality

LCN

If LCN(Logical Channel Number) Select function is activated, you can't change the original
number of TV channels by scanning .
You can activate/disactivate the LCN function by setting the "LCN Mode" to on/off.

English

1

4

No

By channel

UHF

CH37(666000KHz)

666000KHz

8MHz

CH37(666000KHz)

Off

81%
97%

81%
97%

OPERATION

Changing Channels

There are three ways of channel selection - stepping through the channel list, selection by number
and from the on-screen channel list.

Stepping through the channel list:

1

To move through the channel list, press the upward arrow or downward arrow key on the
remote control.

2

Selected by number:
Enter the channel number directly by pressing numeric buttons ,and press the "OK" button
to select desired channel.

3

Selected by on-screen channels list:
You can also select the required channel directly from on-screen channel list. This is
displayed using the STB's main menu. See "Edit Channel" in this manual for operation detail.

Accessing the Electronic Program Guide (EPG)

Accessing the EPG of all channels:

1

Press "EPG" button to enter EPG menu .

2

Press cursor button to switch between channel list, events
schedule of the selected channel and now/next events.

3

Press "Green" button to Timer the events.

4

Press "Red" button to display " Time Bar" menu.

EPG

0010 BBC FOUR

Auntie's War on Smut
01:30-02-30

3/19

Interecon

0008

BBC Parl

0009

BBC FO

0010

CBeebie

0011

301

0012

01:39 xx/xx/xxxx

01:30 02:00 02:30 03:00

The Recor

Commons Questions

Auntie's War on Smut

This is CBeebies!

Proms on FOUR

The Recor

TimerTime

1

5

English

EDIT CHANNEL

Edit Channel menu

1

Press the "MENU" button to enter main menu.

2

Press "UP" or "DOWN " button to highlight "Edit Channel", press
"RIGHT" button to enter the Edit Channel menu.

3

Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the sub-menu .

4

Press "EXIT" button to exit.

TV Channel list

In the Edit Channel menu, select "TV Channel List", press "OK"

1

button to enter TV channel list menu.

2

Press "UP" or "DOWN" button to highlight channel, press the "OK"
button to preview the desired TV channel.

Use this menu to favor, lock, skip, move, sort, delete and rename
channel.

Press "FAV" button, then press "OK" button to edit the FAV
function.

Press "color" button, then press "OK" button to edit the
corresponding function.

Radio Channel list

1

In the Edit Channel menu, select "Radio Channel List", press "OK" button to enter the Radio
Channel list menu.

2

Press "UP" or "DOWN" button to highlight channel press the "OK" button to listen the desired TV
channel.

NOTE:

Basically, the operation of "Radio Channel List" is the same as "TV Channel List",
but there is one point different: In "Radio Channel List" mode, there is no video
information, so it will always display Radio's logo in the right side preview window.

TV Channel List
Radio Channel List
Delete All

TV Channel List

All Channel

Lock

FAV

Skip

0001 No Name
0002 YooPlay Ga
0003 E4+1
0004 UKTV Histor
0005 SKY THREE
0006 Sky Spts Ne
0007 Sky News

TV Channel List

All Channel

Rename

Sort

0001 No Name
0002 YooPlay Ga
0003 E4+1
0004 UKTV Histor
0005 SKY THREE
0006 Sky Spts Ne
0007 Sky News

Edit Channel

Move

Delete

Edit

BBC FOUR

i

xxxxxxxx
xxxxxx
xxxx
xxx

BBC FOUR

i

xxxxxxxx
xxxxxx
xxxx
xxx

Delete All

1

In the Edit Channel menu, select "Delete All", press "OK" button.

2

A warning window appears.
Select "Yes", press "OK" button to delete all channels.
Select "No", Press "OK" button to cancel deleting.

English

1

6

Warning! Do you really want to delete
all channels?

Yes

No

SYSTEM SETUP

System setup menu

System setup menu allows us to set Language, TV System, Local Time
Setting, Timer Setting, Parental Lock, OSD Setting, Favorite and Auto
Standby.

1

Press the "MENU" button to enter main menu.
Press "UP" or "DOWN" button to highlight "System Setup",

2

press "RIGHT" button to enter the System Setup menu.
Press "UP" or "DOWN" cursor button to highlight the desired

3

item and press "OK" button to enter the sub-menu.

4

Press "EXIT" button to exit.

Language

This menu allows you to set Language.

System Setup

Language
TV System
Local Time Setting
Timer Setting
Parental Lock
OSD Setting
Favorite
Auto Standby

Language

Language
First Audio
Second Audio
Subtitle Language
Subtitle Display
Teletext

English
English
German
English

Off

English

TV System

This menu allows us to set Video Resolution, Aspect Mode,
Video Output and Digital Audio Output.

Video Resolution:

Aspect Mode:

Video Output:

Digital Audio Output:

576i/576p/720p/1080i/1080p

Auto/4:3PS/4:3LB/16:9

HDMI/RGB

LPCM Out/ BS Out

Local Time Setting

This menu allows you to set the region and time.
Region:

GMT Usage:

GMT Offset: This menu is valid only when selected "Uesr Define"

Date:
Time:

This menu is used for changing the region setting.
This menu is used for open the usage of GMT.
The options are : Off / On

in GMT Usage menu .
The GMT offset range is "-11:30 ~ +12:00", increasing
half hour progressively.
"Date" and "Time" menus are valid only when selected "Off" in GMT Usage menu.

Press numeric button to input the time.

Timer Setting

This menu allows us to set the program timer. You can set 8 timers.

Timer Mode:
Timer Service:
Wakeup Channel:
Wakeup Date:
Wakeup Time:
Duration:

Off/Once/Daily/Weekly/Monthly
Channel/Record
You can select a desired channel as the wakeup channel.
Press numeric button to input date.
Press numeric button to input the time.
Press numeric button to input the duration time.

English

1

7

TV System

Video Resolution
Aspect Mode
Video Output
Digital Audio Output

Local Time Setting

Region
GMT Usage
GMT Offset
Summer Time

Date
Time

xxxx,xxx,xxxx

Current Time/date: 01:36PM xx/xx/xxxx

Timer Mode
Timer Service
Wakeup Channel
Wakeup Date
Wakeup Time
Duration

Save

576i

Auto
HDMI
LPCM

France

On

GMT+01:00

Off

xxxx/xx/xx

01:51

Daily

Channel
BBC FOUR
xx/xx/xxxx

xx:xx
xx:xx

Cancel

Parental Lock

This menu allows you to protect menu and channel, and change the
Password.

1

In "System Setup" menu, select "Parental Lock" and press "OK" button,
you are asked to input a password(the default password is"0000").

2

After inputting the correct password by pressing numeric buttons,
the parental lock menu appears.

Menu Lock:

Channel Lock:
New Password:
Confirm Password: To confirm the new password.

To lock the Edit channel/ installation/System setup/ Tools/
REC menu. When you want to enter these menus, you must
input the password. You can set menu lock to on/off.

Off/ AGE 10/AGE 12/AGE 16/AGE 18

To change the password.

OSD Setting

This menu allows you to set OSD Timeout, OSD Transparency and load
default OSD setting.

OSD Timeout:

OSD Transparency:

Load Default OSD Setting:

1-10

To set the OSD transparency to Off/10%/20%/30%/
40%.

To clear all OSD setting and reset parameters
as default value.

Favorite

This menu allows you to rename the favorite group.

1

In Channel menu, select "Favorite", press "OK" button to enter
Favorite menu.

2

Select desired group, press "OK" button to open the mock keypad.
Input letter and numeric one by one by pressing the cursor button
and press "OK" button to confirm. After finishing input, highlight
"OK" on mock keypad to confirm, you change Favorite group name
successfully.

3

Press "EXIT" button to quit the group rename menu.

Auto Standby

No command to STB on front panel or Remoter in 3 hours and

On

no timer event,the STB will enter standby mode automatically.

The STB can't enter standby mode automatically.

Off

SYSTEM SETUP

Parental Lock

Menu Lock
Channel Lock
New Password

Confirm Password

OSD Setting

OSD Timeout
OSD Transparency
Load Default OSD Setting

Favorite

1

Fav group 1

2

Fav group 2

3

Fav group 3

4

Fav group 4

5

Fav group 5

6

Fav group 6

7

Fav group 7

8

Fav group 8

Auto Standby

Auto Standby

Rename

Fav group 1

A

B C D E F
G
M

N

O
U

S

T

0

Y

Z

5

6

4

SP

?

CAPS

Off
Off

----

----

5

Off

K LHJI
Q

P

R

V

W

X
3

1

2

7

8

9

<-

OK

Del

OK

On

1

8

English

Tools main menu

1

Press the "MENU" button to enter main menu.

2

Press "UP" or " DOWN " button to highlight "Tools", press "RIGHT"
button to enter the Tools menu.

3

Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the sub-menu.

4

Press "EXIT" button to exit.

Information

This menu can display some parameters information in this STB.

1

In "Tools" menu, select "Receiver Information", press "OK" button
to open receiver information window.

2

Press "EXIT" button to exit.

Tools

Information
Load Factory Setting
S/W Upgrade by OTA

Upgrade By USB
Remove USB device safely

Information

x.x.x

xxx

xxxxx

xxxxx

xxxxx

xxxxx

x.x.x

xxx

x.x.x

xxx

xxxx-x-xx
xxxx-x-xx
xxxx-x-xx
xxxx-x-xx
xxxx-x-xx

Load Factory Setting

This menu allows you to re-set the STB back to factory settings,
clear all existed channels.

1

In the "Tools" menu, select "Load Factory Default", press "OK"
button. You are asked to input a password(the default password
is"0000").
A confirmation window is displayed.

2

Select "Yes" to return back to factory settings and clear all
channels.
Select "No" to cancel back to factory settings.

3

Press "EXIT" button to exit .

Software Upgrade

We offer the functions for user to upgrade software version by OTA
or by USB .

1

Enter "Tools" menu, select "S/W Upgrade by OTA" or "Upgrade
by USB", press "OK" button, Software Upgrade menu is shown.

Press cursor button to select the desired item, then highlight

2

"Start" and press "OK" button to start upgrade.

3

Press "EXIT" button to exit.

English

1

9

Load Factory Setting

This operation will load default and erase all
the channels that user added, the system will
reboot, continue?

Yes No

Upgrade by USB

Upgrade mode
Upgrade File
Start

Allcode
No File

0%

Remove USB device safely

In "Tools" menu, select "Remove USB device safely",
Press "OK" button to confirm. Then a window is displayed.
Press "OK" button again.

SYSTEM SETUP

Tools

Information
Load Factory Setting
S/W Upgrade by OTA

You can safely remove USB device

Upgrade By USB

now!

Remove USB device safely

Yes

10

1

English

Game

This menu allows you to play games.

1

Press the "MENU" button to enter main menu.

2

Press "UP" or "DOWN" button to highlight "Game", press "RIGHT"
button to enter the Game menu.

3

Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK" button to enter the game.

4

Press "EXIT" button to exit.

Othello
Sudoku

Game

11

1

English

REC

REC main menu

1

Press the "MENU" button to enter main menu.

2

Press "UP"or "DOWN" button to highlight "REC", press
"RIGHT" button to enter the REC menu.

3

Press "UP" or "DOWN" cursor button to highlight the desired item
and press "OK"button to enter the sub-menu.

4

Press "EXIT" button to exit.

USB Device

This function allows you to play files from USB port .

1

In "Tools" menu, select "USB Device", press "OK" button to enter
Media Player menu.

2

Press "UP" or "DOWN" cursor button to select a desired item,
and press "OK" button to play the desired files.

3

Press "EXIT" button to exit.

Record Manager

This menu allows you to play the record files

In "REC" menu, select "Record Manage", press "OK" button to enter

1

Record Manage menu.

2

Press "UP" or "DOWN" cursor button to select a desired item, and
press "OK" button to play the desired files.

3

Press "EXIT" button to exit.

DVR HDD Information

This menu can display some parameters of Removable Disk.

1

In "REC" menu, select "DVR HDD Information", press "OK"
button to open DVR HDD information window.

2

Press "EXIT" button to exit.

REC

USB Device
Record Manager
DVR HDD Information
HDD Format
DVR Configuration

Media Player

uda 1

/..

MPG

1

840.mpg

I swear.mp3

2

MP3
MP3

3

MP3

4

MP3

5

JPG

6

JPG

7

Play List
Repeat Mode

Record Manage

BBC FOUR
(DVR)
16:53-16:56(00:03:22)98M

No. Date Time Program

1

19/03

2

12/07

3

12/07

4

19/03

DVR HDD Information

Total
Free
Used
Time shift
Rec Free
File System

I swear.mp3

Why.mp3

3319KB

Lonely.mp3

00:03:32

Because.mp3

00:03:15 00:03:32

0

INFO

All Music

Setup

1

All Image

Sort

01:01-01:02

BBC FOUR

15:39-15:40

The HITS

17:41-17:42

Ideal World

16:53-16:56

BBC FOUR

Lock Delete Rename

FAV

Add File

xx.xxGB
xx.xxGB
xx.xxGB
xx.xxGB
xx.xxGB

xxx

12

1

English

REC & MEDIA

HDD Format

This menu allows you to format the disk.

1

In "REC" menu, select "HDD Format", press "OK" button to
open HDD Format menu.

Highlight "Storage Partition", press "LEFT" or "RIGHT" cursor

2

button to change Partition.

Highlight "Format", press "OK" button, a window appears.

3

Select FAT/NTFS, press "OK" button to format.
Select "Cancel", Press "OK" button to cancel.

HDD Format

Volume
Total
Free
Used
File System

Storage Partition USB Partition1

Format

DVR Configuration

This menu allows us to set the DVR Configuration.
Press "UP" or "DOWN" cursor button to select desired item,
press "LEFT" or "RIGHT" cursor button to change the setting.

TimeShift On/Off

Timeshift to Record On/Off

Record Type TS/PS
TS: Transportation stream which includes information like
teletext, subtitle, epg etc.
PS: Program stream which will be packeted with the file
format of *.mpg and be also playbacked by PC or other devices.

Record Selection You can press "LEFT"or "RIGHT" cursor button to change Selection.

Standby after record On/Off

DVR Configuration

Timeshift
Timeshift to Record
Record Type
Record Selection
Standby after record

no name

xx.xxGB

xx.xxGB

xx.xxGB

FAT32

On
Off
TS

USB Partition1

Off

13

1

English

TIMESHIFT/RECORD

Plugging an external Mass Storage Device on the USB port gives you access to Time Shift/Record
a broadcast programme.

Pause a broadcast programme and continue watching it later (Time Shift )
Record a broadcast programme.
When the space available on the Mass Storage Device runs out, recording operation of
broadcast will stop.

NOTE:

Please use USB 2.0 disk when recording or timeshift.
For timeshift and recording feature, you need take bigger size USB pen
driver or HDD (>2GB) for recording.

Timeshift

Initiate

Time Shift can be done in viewing mode by pressing the
"PAUSE" button.
Press "RIGHT" or "LEFT" button to move the cursor to
the time you desired to view. Press "OK" button to confirm.

Trickmodes

During the playback, it is possible to perform the following actions :
Press "PAUSE" button to pause the playback
Press "FORWARD" button to fast forward the playback
Press "BACKWARD" button to rewind the playback

Stop the Time Shift

Press "STOP" button to stop TimeShift.

Record

Instant record

In viewing mode, press "RECORD" button to instantaneously start a record on the current channel.
If "RECORD" button is pressed again, the instant record switches to duration mode.
Press "STOP" button to stop recording, then a confirmation window appears.
Select "Yes" to stop recording. Select "No" to continue recording.

BBC FOUR

Play 00:02:37 00:07:12

03/19

TS

01:36

2%

NOTE:

Please select famous brand USB 2.0 USB HDD or USB stick for Recording and Timeshift, such as SAMSUNG,
HITACHI and SONY. Some USB devices maybe can't be supported due to its quality.

English

1

14

TROUBLESHOOTING

In some region, the digital terrestrial signal may be weak. So you'd better use the antenna in
which the booster was built,for watching the weak signal channels.

Problem

Standby light not lit

No signal found

No picture or sound

Scrambled channel
message

No response to remote
control

Forgotten channel lock
code

Forgotten menu lock
code

The remote control will
not operate your STB

After moving the STB to
another room you find you
are no longer able to
receive digital reception

Possible cause What to do

Mains lead unplugged
Mains fuse blown

Aerial is disconnected
Aerial is damaged/misaligned
Out of digital signal area

Scart/AV is not selected on your TV

Channel is scrambled

Receiver off
Handset not aimed correctly
Front panel obstructed
Hand set batteries exhausted

(1) The batteries in your remote
control need replacing
(2) There is an obstruction
blocking the signal path
between the remote control
and the box.

The aerial feed former new point
may come through a distribution
system which may reduce the
digital signal now received by the
box.

Check mains lead
Check fuse

Check aerial lead
Check aerial
Check with dealer

Reduce to another channel

Select alternative channel

Plug in and turn on plug
Aim handset at front panel
Check for obstructions
Replace handset batteries

Re-install channels to cancel
channel lock

Contact help line

(1) Replace the batteries
(2) Check that there is nothing in
the way of the path between
the remote control and the
receiver

Try a direct feed from the antenna

15

1

English

SPECIFICATIONS

TUNER & CHANNEL

DECODER

Video decoder

Audio decoder

INPUT RATE

VIDEO FORMATS

VIDEO OUTPUT

MODULATION

CONNECTION

MAIN POWER CABLE
TUNER
SPDIF
DATA PORT
RCA OUTPUT

HDMI HDMI OUTPUT x1

POWER SUPPLY

INPUT VOLTAGE

POWER CONSUMPTION

NOTE:

Design and Specifications are subject to change without notice.

MAX. 48Mbit/s

RF INPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, FEMALE)

RF OUTPUT CONNECTOR x1
(IEC-TYPE, IEC169-2, MALE (LOOPTHROUGH))

FREQUENCY RANGE:
174MHz~230MHz(VHF)
470MHz ~862MHz (UHF)

SIGNAL LEVEL:

-15 ~ -70 dbm

MPEG-2 MP@HL, AVC/H.264 HP @L4.1
MPEG-4 ASP SUPPORTED

MPEG-1 Layer 1,2/PCM/HE-AAC V1.0
ICE958 SPDIF/ AC3

4:3/,16:9 SWITCHABLE

HDMI, RGB
QPSK,16QAM,64QAM

FIXED TYPE

ANTENNA INPUTx1, RF OUTPUT x1
COAXIAL x1
USB slot
V/L/R x1

AC220~240V, 50/60Hz

MAX. 8W

16

1

English
