Kogan XU9210, KALED5 XU9210ST Quick Start Guide
QUICK START GUIDE
75” SMART HDR 4K LED TV
SERIES 9 XU9210
(KALED75XU9210STA)
COMPONENTS
A
B C D
QUICK START GUIDE
75” SMART HDR 4K LED TV
SERIES 9 XU9210
E
A Kogan Ŧ5” Smart
HDR 4K LED TV
B Remote control
C Stand (x2)
(KALED75XU9210STA)
F G
D
M6 x 20mm screw (x6)
E AAA battery (x2)
F Quick-start guide
G Warranty card
NOT INCLUDED
Phillips head screwdriver, antenna cable, broadband internet connection.
3
REMOTE CONTROL OVERVIEW
1
3
4
6
8
10
12
1 Power, press to enter or exit
standby mode
2
Mute to toggle sound on/o
3 Number buttons
to select channels
or input passwords
info displays the current program
4
information
5
epg Electronic Program Guide in DTV
mode
6
Device preferences to display
sound and picture options
2
5
7
9
11
13
Source displays the list of input
7
source channels.
/ / / Direction buttons for
8
navigating menus and settings
ok Enter select the current item
9
or confirm selection, display Channel
list in DTV mode
10
Quick Menu to display TV options
with optional, adjustable settings
Back to the previous menu
11
12
13
to open app homepage
to open app homepage
4
14
16
17
21
15
18
19
20
14 to open app homepage
15
16
to open app homepage
Google Assistant to launch the
built-in virtual assistant for voice
commands
17
- Volume to adjust the volume
+
up or down
18
19
20
Program to scroll channels
Home to access the home page
Teletext to show/hide Teletext
(Teletext not available in Australia
or New Zealand)
Press to switch to the USB source.
USB
Audio to select available
languages and audio channels.
SUBT
Subtitles to select subtitles
Start playback in media mode;
MIX mode in teletext
II Pause in media/PVR mode;
Timeshi function in DTV mode
Stop in media/PVR mode;
Hold teletext page on display,
press again to release
Record in DTV mode;
Change size of teletext screen
Reverse playback rapidly in
media mode;
Subtitle mode, or
Submenu
Skip to previous in media mode;
Index page
Skip to next in media mode;
Reveal hidden information in
some teletext pages
Advance playback rapidly in
media mode;
Cancel teletext but not exit
Colour buttons for navigational use
21
within apps
5
