Kogan HD22
High Definition LCD TV
USER MANUAL
1
Safety information
To ensure reliable and safe operation of this equipment, please read carefully all of the
instructions in this user guide, especially the safety information below.
Electrical safety
·The TV set should only be connected to a mains power supply which matches that stated
on the label on the mains power adaptor.
·To prevent overload, don’t share the same mains power supply socket with too many
other items of equipment.
·Be careful to route the mains power cable away from areas where people can trip
over it.
·Unplug the TV when it is not going to be used for a long time. Disconnect both the
aerial and the main power cable.
·Take care not to expose the TV set or the remote control to water or moisture.
·Pull the plug out immediately, and seek professional help if:
- the mains power plug or cable is damaged
- liquid is spilt onto the TV set, or if it is accidentally exposed to water or moisture
- anything accidentally penetrates the ventilation slots
- the TV set doesn’t work normally.
·Never remove the cover, there are no user-serviceable parts inside. Allow only
qualified service personnel to repair this equipment.
·To avoid leakage, take out the remote control batteries when:
- the batteries are exhausted
- you are not going to use the remote control for a long time.
·Batteries should be recycled or disposed of in a proper manner.
Physical safety
·Make sure the set is positioned at least 5cm (2inch) from the wall or furniture.
·Never tap or shake the screen for any reason.
·Take care not to drop or sit on the remote control.
·Clean the set using only a soft, clean, dry cloth. Do not use any solvents.
2
OPERATING INSTRUCTIONS
Contents
Safety information--------------------------------------------------------------------------------------- 1
Electrical safety --------------------------------------- -- -- -- -- -- -- -- -- ---------------------------------- 1
Physical safety ------------------------------------- ---- ------ ------ ---- ------ ---- ------ ------ ---- ------ - 1
In the box -------------------------------------------------------------------------------------------------- 3
Connection ------------------------------------------------------------------------------------------------ 4
Rear connection panel -------------------------------------------------------------------------------- 4
Getting Started ------ -- ---- -- ---- -- -- ---- -- ---- -- -- ---- -- ---- -- -- ---- -- ---- -- -- ---- -- ---- -- -- ---- -- ---- -- - 5
Front panel controls ------------------------------------------------------------------------------------ 5
The Remote control ------------------------------------------------------------------------------------- 6
Using the remote control for normal TV functions ---------------------------------------------- 6
Initial Setup Instruction Guide ---------------------------------------------------------------------- 8
Power ON/OFF: Standby mode -------------------------------------------------------------------- 8
Selection of Input Mode ------------------------------------------------------------------------------ 8
On Screen Display (OSD) Menu -------------------------------------------------------------------- 9
Navigating the OSD Menu--------------------------------------------------------------------------- 9
Video Page Menu -------------------------------------------------------------------------------------- 10
Audio Page Menu -------------------------------------------------------------------------------------- 13
TV Page Menu (Only for TV) ------------------------------------------------------------------------ 14
Setup Page Menu -------------------------------------------------------------------------------------- 17
Parental Page Menu ---------------------------------------------------------------------------------- 19
Troubleshooting ------------------------------------------------------------------------------------------ 22
Maintenance ----------------------------------------------------------------------------------------------- 23
Features and Specifications-------------------------------------------------------------------------- 24
3
In the box
TV set
Power supply Power supply cable Remote control
- If any of the accessories are missing, then please contact Kogan Technologies.
- Keep all the original packaging in case you need to return the TV to Kogan Technologies.
4
Connection
Rear connection panel
Number Name Function Description
1 HDMI HDMI input jack (audio and video)
2 VGA VGA computer input
3 VGA AUDIO IN Computer audio input
4 YPbPr (1,2) IN YPbPr inputs
5 YPbPr (1,2) Audio IN YPbPr Audio inputs
6 S-VIDEO S-Video signal input
7 AV IN Video Signal input
8 AV_R / AV_ L Audio signal input for AV/S-VIDEO
9 RF Connect to TV cable/antenna or DVB-t antenna
10 DC Connect to the supplied Power Adaptor
DC
DC
5
Getting Started
1. Connect the aerial or input source to the appropriate input socket a t the rear of
the TV set (see page 4).
2. Connect the small round plug on the power a daptor cable to the power input
socket at the rear of the TV set.
3. Connect the power cable between the power adaptor and the mains supply.
4. Switch the power on by pressing the POWER button on the front panel or the
remote control (the LED will show green).
5. Use the AV/TV button on the front panel or the remote control to select which
input source to use : TV-AV-SVIDEO-YPBPR1-YPBPR2-VGA-HDMI
6. You can use the front panel controls to adjust the volume or select a channel as shown
below, or you may use the remote control for these functions.
7. To switch the set off for a short time, press the POWER button, the set will go into
standby and the LED will show red. If you are not going to use the set for some
time, switch the power off completely by unplugging the mains cable.
Front panel controls
6
The Remote Control
Using the remote control for normal TV functions
1. Insert two AAA batteries, making sure that the polarity is correct as marked
inside the compartment.
2. Aim the remote control at the IR sensor just below the green light (see
page 5 for diagram). Keep this area clear at all times.
3. Do not press the buttons on the remote too quickly – allow the TV time to
respond.
01. POWER :
Press to enter or exit the standby mode
02. MUTE :
Press to turn on or off speaker output
03. DISPLAY: Press to show or remove status display
04. VOL+: Press to increase volume
05. VOL-: Press to decrease volume
06. Numbers: Press to select a channel
07. AV/TV: Press to select input source
08. PMODE: Press to select picture display mode.
09. Enter: Press to confirm your selection
10. Directions: Press to Select up (Page+ for TV
teletext), down (Page- for teletext), left, and right
in menu screens.
1 1. LCD Menu Press to display the LCD Menu system (see p.9)
12, 13, 15.: These buttons are unused on this model
14. SUBTITLE Press this button to activate subtitles for Digital
TV programs where available.
16. A/E Press this button in TV mode to make the
current channel a Favourite
17. FAV: Press this button to enter the Favourites menu
directly
18. TIMER: Press to display the time
19. SLEEP: Press to enter Sleep mode, where the TV will
automatically enter standby mode after a set
time (press to toggle between “Off” and up to
240 minutes in 15 minute increments)
20. GREEN Press to activate the “GREEN” function in
teletext
21. RED Press to activate the “RED” function in teletext
7
22-23.: These buttons are unused on this model
24. CH+ Press to select TV channel (see p.15 “Channel
Skip”)
25. CH- Press to select TV channel (see p.15 “Channel
Skip”)
26. DOT Press the number buttons with this to select
channels directly (i.e. channel 108-1 would
need the DOT button pressed after the 8).
27. SMODE Press this button to toggle between preset
sound modes for different echoing effects.
28. EXIT Press this button to exit in a menu.
29. TEXT Press to enter or exit teletext mode for
TV/DVB
30-32.: These buttons are unused on this model
33. EPG In TV/DVB mode, press to display the
Electronic Programming Guide
34. Press to access subpages for teletext
35. This button is not used on this model
36. Press to toggle between available display
aspect ratios for the current input.
37. YELLOW Press to activate the “YELLOW” function in
teletext
38. BLUE Press to activ ate the “BLUE” function in
teletext
Note: The TV will return to TV mode when any of the buttons for changing
channels are used, i.e. the Number buttons, CH+ and CH-
8
Initial Setup Instruction Guide
Power ON/OFF: Standby mode
- Press POWER ( ) button on the remote control or on
the side panel to turn on the unit.
[The power indicator changes from red to green]
- Press POWER ( ) button on the remote control or on
the side panel again to return the display to standby mode.
[The power indicator changes from green to red]
Selection of Input Mode
- Press the Input (AV/TV) button to display the signal source menu.
- Press
or button to select the signal source you desire,
then press the Enter button to confirm.
When selecting the input source, the screen will display the information
of the selected input source. For example:
TV mode
- When there is no signal from the selected source or channel, a warning message will be displayed.
- If you see the “No Signal!” warning, you can select a different channel or press the Input (AV/TV)
button to change the selected source.
- When you first receive your new TV, it is advisable to perform a new “Channel Scan” to setup your
set to receive all of the channels available in your area. Follow the section “Using Channel Scan”’
on page 15.
9
On Screen Display (OSD) Menu
After you have installed the batteries in the remote control, you can set setting preferences on
the TV using the OSD menu system.
Navigating about the OSD menu:
- The buttons used in the OSD menu include:
’MENU’ (LCD MENU), , ‘ENTER’ and ‘EXIT’.
- Whatever input source is currently selected, press
the Menu button to open the OSD Menu for that source,
then
or to select the sub menu pages
The sub menu pages are displayed in the following sequence
(circular display):
Video Audio TV Setup Parental
Note: The TV sub menu page will only appear for the TV mode OSD Menu.
When pressing the Menu button on the remote control or on
the side panel, it will change in the following sequence:
Main Menu Press Menu or Exit Exit
Sub Menu Press Exit Previous Menu
1. Press the Menu button to display the menu system.
2. Press
or button to select the menu pages.
3. Press the Enter or
button to enter.
4. Press or button to select an item.
5. Press
button to select or adjust a setting.
6. If you do not make a selection within several
seconds, the main menu will close automatically,
7. Press the Menu or Exit button exit the OSD menu.
10
On Screen Display (OSD) Functions
Video Page Menu
Adjustment of “Brightness” or “Contrast”
1. Press the Menu button, and the “Video” menu
appears.
2. Press or Enter to enter the “Video” sub menu .
3. Press or to highlight your selection.
4. Press or
to adjust.
5. Press the Menu button to exit the OSD Menu, or
press Exit to select another OSD submenu.
Adjustment of “Saturation” (inactive for VGA)
1. Press the Menu button, and the “Video” menu
appears.
2. Press or Enter to enter the “Video” sub menu .
3. Press or to highlight “Saturation”.
4. Press or
to adjust.
5. Press the Menu button to exit the OSD Menu, or
press Exit to select another OSD submenu.
Adjustment of “Hue” (only for NTSC)
1. Press the Menu button, and the “Video” menu
appears.
2. Press
or Enter to enter the “Video” sub menu .
3. Press or to highlight “Hue”.
4. Press or
to adjust.
5. Press the Menu button to exit the OSD Menu, or
press Exit to select another OSD submenu.
Adjustment of “Sharpness” (inactive for VGA)
1. Press the Menu button, and the “Video” menu
appears.
2. Press or Enter to enter the “Video” sub menu .
3. Press or to highlight “Sharpness”.
4. Press or
to adjust.
5. Press the Menu button to exit the OSD Menu, or
press Exit to select another OSD submenu.
11
Selection of “Color Temperature”
1. Press the Menu button, and the “Video” menu
appears.
2. Press or Enter to enter the “Video” sub menu .
3. Press or to highlight “Color Temperature”.
4. Press
or Enter to enter the Color Temperature
submenu.
5. Press or
to select one of:
“Cool”, “Standard”, “Warm” or “User”
6. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
If you adjust one item of “R Gain”, “G Gain”, or
“B Gain”, the color temperature selection will change
to “User” automatically. Other settings can be selected
but not changed.
Selection of “Advanced Video” (Inactive for VGA)
1. Press the Menu button, and the “Video” menu
appears.
2. Press
or Enter to enter the “Video” sub menu .
3. Press
or to highlight “Advanced Video”.
4. Press
or Enter to enter the Advanced Video
submenu.
5. Press
or to highlight your selection
(see table on next page for details)
6. Press or
to adjust.
7. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
12
T able of Advanced Video Adjustment Settings
Setting Options Description
DNR
Off, Low, Medium,
Strong, Auto
Select to control the sharpness
and noise reduction.
CTI Off, Low, Medium, Strong Select to improve the dynamic color level.
Flesh Tone On, Off
Select “On” to correct the flesh
tone automatically.
Adaptive
Luma
Control
On, Off
When this is on, this feature will set
the contrast and brightness levels
for optimum performance.
Selection of “VGA” (only for VGA)
1. Press the Menu button, and the “Video” menu
appears.
2. Press or Enter to enter the “Video” sub menu .
3. Press or to highlight “VGA”
4. Press
or Enter to enter the VGA submenu.
Selection of “Auto Adjust”
After entering the “VGA” menu:
1. Press or to highlight “Auto Adjust”
2. Press
or Enter to confirm your selection.
3. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Note: This item will auto-adjust the picture display.
Selection of “H. Position”, “V. Position”, “Phase”, “Clock”.
After entering the “VGA” menu:
1. Press or to highlight your selection
2. Press or
to adjust.
3. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
13
T able of VGA Display Adjustment
Items Description
H. Position
Use
or button to select it.
Use or
button move the display left or right.
V. Position
Use
or button to select it.
Use or
button to move the display up or down.
Phase
Use
or button to select it.
Use or
button to adjust.
Clock
Use
or button to select it.
Use or
button to adjust.
Audio Page Menu
Adjustment of “Balance”, “Bass” or “Treble”
1. Press the Menu button, and then press
or
until the “Audio” menu appears.
2. Press or Enter button to enter the “Audio” menu.
3. Press or to highlight your selection.
4. Press or
to adjust.
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Selection of “Sound Surround”
1. Press the Menu button, and then press
or
until the “Audio” menu appears.
2. Press or Enter button to enter the “Audio” menu.
3. Press or to highlight your “Surround Sound”
4. Press or
to select “On” or “Off”
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
14
Selection of “SPDIF Type”
1. Press the Menu button, and then press
or
until the “Audio” menu appears.
2. Press or Enter button to enter the “Audio” menu.
3. Press or to highlight “SPDIF Type”.
4. Press or
to select “Dolby Digital”,
“PCM” or “Off”.
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
TV Page Menu (Only for TV)
Setting the “Country Region”
1. Press the Menu button, and then press
or
until the “TV” menu appears.
2. Press or Enter button to enter the “TV” menu.
3. Press or to highlight “Country Region”.
4. Press or
to select “NSW/ACT”, “VIC”,
“QLD”, “SA”, “WA”, “TAS”, “NT”.
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Using the “Audio channel” (Analogue TV OSD Menu only)
1. Press the Menu button, and then press
or
until the “TV” menu appears.
2. Press
or Enter button to enter the “TV” menu.
3. Press
or to highlight “Audio Channel”.
4.
Press or to select Mono, Stereo, Dual1 or
Dual2.
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
15
Using the “Channel Scan”
1. Press the Menu button, and then press
or
he “TV” menu appears.
2. Press or Enter button to enter the “TV” menu.
3. Press or to highlight “Channel Scan”.
4. Press or Enter button to start the channel search.
5. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Note:
- This may take a few minutes to complete a full scan
- The channels found will store automatically.
- This TV will scan for Analogue and Digital channels
- All previously stored channels, as well as channel
related information (eg. Channel Block, Channel Skip),
is deleted when performing this scan.
Using the “Channel Skip”
This feature allows you to choose which channels will be
part of the normal channel rotation when using the
CH+ and CH- buttons. Channels chosen to be skipped
will still be accessible by entering it's channel number
directly, eg. 20 for HDTV ABC.
1. Press the Menu button, and then press
or
until the “TV” menu appears.
2. Press or Enter button to enter the “TV” menu.
3. Press or to highlight “Channel Skip”.
4. Press or Enter button to enter the submenu.
5. Press or to choose a channel, then press
Enter to confirm or cancel your selection.
6. When you select
, this channel will be skipped.
7. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
16
Selection of “Channel Edit”
1. Press the Menu button, and then press
or
until the “TV” menu appears.
2. Press or Enter button to enter the “TV” menu.
3. Press or to highlight “Channel Edit”.
4. Press or Enter button to enter the submenu.
5. Press or to choose a channel, then pres s
Enter or
to enter the Edit Submenu (below)
7. When finished, press the Menu button to exit the
OSD Menu, or press Exit to make another selection.
Channel Edit Submenu
Note: for digital channels, only Channel Number and
Channel Name information can be changed.
- Channel Number: use the number buttons to assign
a new channel number. This may be up to 4 digits.
- Channel Name: use the Number buttons to enter
letters or numbers in the Channel Name
(1 = ABC, 2=DEF, etc. eg. Press 1 twice to enter B).
- See table below for a list of options for the other
Channel Edit settings. These can be edited for
analogue channels only.
Settings Options
Frequency 0~999. Use DOT button for decimal point.
Color system Auto, P A L, SECAM, NTS C
Sound system BG, A2 BK, L, L’, I, DK, DK, A2 DK, A2 DK1
“Analog channel Fine Tune”
Please note that this function has been by replaced by the “Channel Scan” option, which will search for
both analogue and digital channels. Manual changes to analogue chann el tuning can be made from
the Channel Edit menu.
17
Setup Page Menu
Use of the “Time Setup” menu
1. Press the Menu button, and then press
or
until the “Setup” menu appears.
2. Press or Enter button to enter the “Setup” menu.
3. Make sure “Time Setup” is highlighted, press
or as required.
4. Press or Enter button to enter the submenu.
5. Press or to choose “Time Zone”,
“Time” or “Sleep Timer”.
6. When finished, press the Menu button to exit the
OSD Menu, or press Exit to make another selection.
Time Setup Submenu
Selection of “Time Zone”
After entering the “Time Setup” submenu:
1. Make sure "Time Zone" is highlighted, press
or as required.
2. Press or
to select your timezone.
Australian Timezones are as follows:
- GMT+8:00 Perth
- GMT+9.30 Darwin and Adelaide
- GMT+10:00 Canberra, Melbourne, Sydney, Brisbane, Hobart
3. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
”Time” Options
After entering the “Time Setup” submenu:
1. Press
or to highlight “Time”.
2. Press
or Enter button to enter the “Time” submenu.
- When “Auto Synchronisation” is set to “Off”, Date and
Time information can be changed using the Number buttons.
- When “Timer” is set to “On”, the TV will turn On and Off from
Standby mode every day at the “Power On/Off Timer” times.
Use the Number button to edit these times.
Note: If the unit is unplugged, or main power is otherwise
disrupted, the memory for all Time settings will be lost.
18
“Sleep Timer” Option
This option is replaced by use of the SLEEP button on the remote contr ol. See Page 6, button 19 for
more details.
“Reset Default”
Selecting this option will return items in the setup
menu to factory default (Note: this will not reset the
Parental password)
1. Press the Menu button, and then press
or
until the “Setup” menu appears.
2. Press or Enter button to enter the “Setup” menu.
3. Press or to highlight “Reset Default”.
4. Press or Enter button and the “Are you sure”
Popup menu will appear.
5. Press or
to choose between “OK” and
“Cancel”. Choose “OK” to reset default.
6. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
19
Parental Page Menu
Some programs and movies include signals
that classify the content of the program (dialog,
language, sex, violence). The “Parental” control
feature in this detects the signals and blocks the
programs according to your selections. To use this
feature, perform the following.
1. Press the Menu button, and then press
or
until the “Parental” option is highlighted.
2. Press or Enter button to enter.
3. Use 0-9 buttons input the password, and the
Parental Control menu will appear.
Note: The initial password for the system is “0000”.
If you have changed the password and forgotten it,
please contact Kogan Technologies.
It is advised that the password be changed the first
time the Parental Menu is accessed. Do not forget your
new password!
Using the “Change Password” function
1. After entering the “Parental” menu, press
or
to highlight “Channel Password”.
2. Press
or Enter button to confirm.
3. Using 0-9 Number buttons, enter your new password
in the “New Password” blank.
4. Using 0-9 Number buttons, enter your new password
again in the “Confirm Password” blank.
5. When this is complete, the previous menu will be
displayed.
20
Using the “Program Block” function
1. After entering the “Parental” menu, press
or
to highlight “Program Block”.
2. Press or Enter button to confirm.
3. Press
to choose from the following options:
- Block All
- No Block
- Block R and above: restricted 18+
- Block AV and above: adult audience. Strong violence 15+
- Block MA and above: adult audience 15+
- Block M and above: mature audience 15+
- Block PG and above: Parental guidance suggested
- Block G and above: suitable for all audiences
4. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Using the “Input Block” function
1. After entering the “Parental” menu, press
or
to highlight “Input Block”.
2. Press or Enter button to confirm.
3. Press or to choose an input to block. The options
are “TV”, “AV”, “S-Video”, “YPbPr”, “VGA”, “HDMI”
4. Press Enter button to confirm your selection.
5. When you select
, all signals from this input source will
be blocked from being displayed.
6. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
21
Using the “Clean All” function
1. After entering the “Parental” menu, press
or
to highlight “Clean All”.
4. Press or Enter button and the “Are you sure”
Popup menu will appear.
5. Press or
to choose between “OK” and
“Cancel”. Choose “OK” to Clean All. This will remove
all Parental Blocks from the system (the password
changes will remain).
6. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
Using the “Channel Block” item
1. After entering the “Parental” menu, make sure
"Channel Block" is highlighted, press or as required.
2. Press
or Enter button to confirm.
3. Press or to choose from the saved channels.
4. Press Enter button to confirm your selection.
5. When you select
, this channel will be blocked
from being displayed.
6. Press the Menu button to exit the OSD Menu, or
press Exit to make another selection.
22
Troubleshooting
Before contacting a service technician for any problems that arise, perform the following simple checks. If
the problem persists, unplug the LCD TV and contact Kogan Technologies.
PROBLEM POSSIBLE SOLUTION
No sound and picture
- Check that the main plug has been properly connected to a power outlet.
- Check that you have pressed the POWER button on the front of TV set.
- Check the picture contrast and brightness settings.
Normal picture but no
sound
- Check the volume.
- Sound muted? Press the MUTE button.
- Try another channel as the problem may be with the broadcast.
- Are the audio cables installed properly?
The remote control does
Not work
- Check if there is any object between the product and remote control
causing an obstruction.
- Are batteries installed with correct polarity (+ to +, - to -)?
- Correct remote operating mode set: TV, VCR etc.?
- Install new batteries.
Power is suddenly turned
off
- Is the sleep timer set?
- Is the Power On/Off Timer (page 16) option on?
Picture appears slowly
after switching on
- This in normal, the image is muted during the product startup process.
Please contact you service center, if the picture has not appeared after
five minutes.
No or poor color or poor
- Adjust the color in menu option.
- Try another channel, the problem may be with the broadcast.
- Are the Video cables installed properly?
- Change the Video OSD Settings (page 10-12)
Horizontal/vertical bars
Or picture shaking
- Check for local interference such as an electrical appliance or power tool.
Poor reception on some
channels
- Station or cable product experiencing problems. Tune to another station.
- Station signal is weak, reorient antenna to receive weaker station.
- Check for sources of possible interference.
Lines or streaks in pictures - Check the antenna (Change the direction of the antenna).
No output from one of the
speakers
- Adjust balance in menu option.
23
The following troubleshooting problems below refer only to VGA mode.
PROBLEM POSSIBLE SOLUTION
The image is not appearing on
the screen properly
- Adjust resolution, horizontal frequency, or vertical frequency.
- Check it whether the signal cable is connected or loose.
- Check the input source.
Vertical bar of stripe on
back ground & Horizontal
Noise & Incorrect position.
- Activate the auto adjust function (see page 12)
- Configure or adjust clock, phase, or H/V position settings
Screen color is unstable
or single color.
- Check the signal cable.
- Reinstall the PC video card.
Maintenance
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you will
have your new TV. Be sure to turn the power off and unplug the power cord before you begin any cleaning.
Cleaning the screen
The LCD screen should be handled with care. It is recommended to use anti-static wipes or an LCD-screen
cleaning kit if you need to clean the screen.
Cleaning the cabinet
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure not to use a wet
cloth.
Extended Absence
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea
to unplug the power cord to protect against possible damage from lightning or power surges.
24
Features
·High Definition display.
·Support HDMI Interface (HIGH-DEFINITION MULTIMEDIA INTERFACE).
·DVB-T Tuner Built In.
·RF, HDMI, VGA, YPbPr, AV, S-Video inputs.
·Stereo audio inputs.
·Automatic or manual channel search.
·Auto-shutdown to save power when no signal is present.
Specifications
TV
TV System PAL/Secam/NTSC
Screen size 22“ (diagonal)
Resolution 1680 x 1050
Aspect Ratio 16:10
Response time 5ms
Aerial input
75Ω
(unbalanced)
Audio output power 2 x 3W
Mains power 12V 4A
Power consumption Stand by: 3W<60W, Operating
Remote control Yes
Type Infra-red
Control distance 8m
Control angle
30°(horizontal)
Batteries 2 x 1.5V size AAA
Dimensions 55cm x 45cm x 18.5cm
Loading...
