KODAK EASYSHARE Camera /
M5350
Extended user guide
www.kodak.com
For help with your camera:
www.kodak.com/go/M5350support
Page 2
Eastman Kodak Company
Rochester, New York 14650
© Eastman Kodak Company, 2011
All screen images are simulated.
Kodak, EasyShare, and Pulse are trademarks of Eastman Kodak Company.
4H8628_en
Page 3
Lens, lens cover
Microphone
Flash
Self-timer/Video light
Shutter button (for pictures)
Battery Charging light
Record button (for videos)
Power button
Product features
Front view
www.kodak.com/go/support
i
Page 4
Product features
OK,
Zoom button
Battery compartment
SD/SDHC Card slot
Trip od
socket
LCD
USB port
Flash button
Strap post
Review: Review, edit, or tag
pictures and videos; change
settings
Share: Share
pictures and videos
Mode: Choose a capture
mode or effect
Display: Switch between
Tools View and Clean View
Delete button
SD/SDHC card
(optional accessory)
Speaker
Back view
ii www.kodak.com/go/support
Page 5
Table of contents 1
1 Setting up your camera .........................................................................1
Loading the battery.......................................................................................1
Charging the battery .....................................................................................2
Turning on the camera ..................................................................................5
Setting the language and date/time...............................................................5
Storing pictures on an accessory SD/SDHC Card.............................................6
Attaching the strap .......................................................................................7
2 Taking pictures/videos ...........................................................................8
Taking pictures..............................................................................................8
Customizing your camera ..............................................................................9
Using Tools to choose actions, preferences ..................................................10
Understanding the picture-taking icons........................................................11
Watch the battery level ...............................................................................11
Taking a video ............................................................................................12
Using the optical zoom................................................................................13
Turning on the date stamp feature...............................................................13
Using the flash............................................................................................14
Using different modes and effects................................................................15
Using the photobooth feature......................................................................16
Using Program mode...................................................................................17
Using the self-timer.....................................................................................18
Using the burst feature................................................................................18
Taking panoramic pictures...........................................................................19
3 Reviewing and editing .........................................................................20
Reviewing pictures/videos ...........................................................................20
Deleting pictures/videos ..............................................................................22
Viewing pictures/videos in different ways.....................................................23
A smarter way to find and enjoy your pictures..............................................24
Understanding the review icons...................................................................25
www.kodak.com/go/support iii
Page 6
Table of contents
Adding a border to a picture........................................................................26
Using photo effects to change a picture’s tint ..............................................27
Cropping a picture ......................................................................................28
Rotating pictures.........................................................................................28
Trimming a video ........................................................................................29
Making a picture from a video.....................................................................30
Making an action print from a video............................................................31
Selecting multiple pictures/videos ................................................................32
Displaying pictures/videos on a television.....................................................33
4 Sharing pictures/videos .......................................................................34
Sharing through email and social networks..................................................34
Tagging pictures .........................................................................................36
Marking pictures/videos as favorites............................................................39
5 Doing more with your camera .............................................................40
Changing settings .......................................................................................40
6 Install software ...................................................................................43
Install software, transfer pictures, and share................................................43
Printing pictures..........................................................................................44
Marking your pictures for print ....................................................................45
7 Troubleshooting ..................................................................................46
Getting help on the Web.............................................................................48
8 Appendix .............................................................................................49
Specifications..............................................................................................49
Care and maintenance ................................................................................51
Upgrading your software and firmware........................................................51
Storage capacities.......................................................................................51
Important safety instructions .......................................................................52
Battery replacement, battery life..................................................................53
Limited warranty .........................................................................................53
iv www.kodak.com/go/support
Page 7
1 Setting up your camera
Load the KODAK Li-Ion Rechargeable
Digital Camera Battery KLIC-7006.
1 2
Use the battery
to slide aside
the battery lock.
Slide open the battery door.
Loading the battery
Purchase extra batteries
Charge the battery see page 2
www.kodak.com/go/support 1
www.kodak.com/go/accessories
Page 8
Setting up your camera
Battery Charging light:
• Blinking: charging
• Steady On: finished charging
Maximize the number of pictures you can take–fully charge the battery
before using. (All rechargeable batteries lose power over time, even if they’re
not being used.) Charge the Li-ion battery whenever necessary.
Turn off the camera.
1
Connect a KODAK Camera USB Cable, Micro B / 5-Pin and charger.
(Use only the cable included with this camera.)
2
Your charger and plugs may differ.
Charging the battery
If your package includes an in-camera battery charger
Watch the battery level See page 11
Purchase extra batteries www.kodak.com/go/accessories
2 www.kodak.com/go/support
Page 9
If your package includes an external battery charger
1
2
Battery Charging light:
• Flashing green: charging
• Steady On green: finished charging
Your charger and plugs may differ.
Setting up your camera
Watch the battery level See page 11
Purchase extra batteries www.kodak.com/go/accessories
www.kodak.com/go/support
3
Page 10
Setting up your camera
Battery Charging light:
• Blinking: charging
• Steady On: finished charging
Turn off the camera.
1
Connect a KODAK Camera USB Cable,
Micro B / 5-Pin and charger.
2
The camera charges when the computer is on and awake.
Turn off hibernation, sleep, and standby modes.
Charge via your computer’s USB port
Watch the battery level See page 11
Purchase extra batteries www.kodak.com/go/accessories
4 www.kodak.com/go/support
Page 11
Turning on the camera
to change current field.
for previous/next field.
OK
to accept.
At the prompt, press
OK.
to change.
OK
to accept.
Language:
Date/Time:
to highlight a site.
Sharing Destinations:
to check/uncheck a site.
You can tell the camera which sharing sites to offer
when it’s time to share pictures/videos.
OK
Setting the language and date/time
Setting up your camera
NOTE: To change language in the future, use the Settings menu (see page 41).
www.kodak.com/go/support
5
Page 12
Setting up your camera
CAUTION:
1
Turn off the camera.
2
Insert a card until it clicks.
3
Turn on the camera.
To remove a card, press and release it.
Optional accessory
Storing pictures on an accessory SD/SDHC Card
Your camera has internal memory. We recommend purchasing an SD or SDHC Card
(Class 4 or higher) to conveniently store more pictures/videos.
A card can only be inserted one way; forcing it may cause
damage. Inserting or removing a card while the camera is on may
damage the pictures, the card, or the camera.
IMPORTANT:
new pictures/videos are stored on the card.
If no card is inserted, new pictures/videos are stored in the camera’s internal memory.
If pictures/videos are detected in internal memory and a card is inserted, the camera
prompts you to move the pictures to the card (and erase those in internal memory).
6 www.kodak.com/go/support
When you turn on the camera, it checks to see if a card is inserted. If so,
Purchase cards www.kodak.com/go/accessories
Page 13
Attaching the strap
Setting up your camera
www.kodak.com/go/support
7
Page 14
2 Taking pictures/videos
Framing
marks
In Liveview In Quickview
In Review
Taking pictures
When you turn on the camera for the first time, it’s in Smart Capture mode—great for
general picture taking. (After that, the camera “remembers” the last mode you used.
To change modes, see page 15.)
1 Use the LCD to compose the picture.
2 Press the Shutter button halfway to focus and set
exposure.
area. (If the camera is not focusing on the desired
subject, release the Shutter button and recompose the
scene.)
3 When the framing marks turn green, press the
Shutter button completely down.
The new picture is briefly displayed. If you don’t like it,
press the Delete button, then follow the prompts. (To
delete a picture later, see page 22.)
Framing marks indicate the camera focus
IMPORTANT:
8 www.kodak.com/go/support
Press the Share button to share anytime! To learn more, see page 34.
Page 15
Taking pictures/videos
Display
OK
Review
Clean view
Tool s vi ew
(Tools vary by
camera mode.)
Tools
Other picture-taking features
■ To view available tools, press the Display button
. Press to choose a tool, then press OK.
■ To review, tag, and edit pictures and videos, press
the Review button (see page 20).
■ To change camera settings, see page 40.
■ If it’s hard to see the LCD, you can adjust the
brightness, see page 41.
Customizing your camera
Sometimes, you want to see everything available! (Other times, you want everything
out of your way.) Press the Display button to change between Clean view and
Tools view.
www.kodak.com/go/support
9
Page 16
Taking pictures/videos
tool, then press OK.
In Review, press
to move between Tools and
Previous/Next.
In Liveview, press
to move between Tools and
the most recent picture.
Most recent
Press
press
Some settings can be
chosen using
2
to choose a
1
or
a setting, then press
OK.
.
,
tool’s setting, then press
OK.
Press to change a
Note: If you chose
to choose
Too ls
1
Using Tools to choose actions, preferences
10 www.kodak.com/go/support
Page 17
Battery level
Number of pictures/video time remaining
Zoom slider
Self-timer/Burst
Flash mode
Most recent
picture/video
Settings
Taking pictures/videos
Understanding the picture-taking icons
Watch the battery level
Don’t miss out on great pictures and videos—keep your battery fully charged.
Full
Three quarters
Half
Critical
AC Power
Charge the battery See page 2
Purchase extra batteries www.kodak.com/go/accessories
www.kodak.com/go/support
11
Page 18
Taking pictures/videos
Taking a video
The camera is always ready to take a video—just press the Record button!
1 Use the LCD to compose the video.
2 To start recording, press the Record button
completely down then release it. To stop
recording, press and release the button again.
The first frame of the new video and the play button
are displayed for a few seconds.
■ To play/pause the video, press the OK button.
■ If you don’t like the video, press the Delete
button, then follow the prompts. (To delete a
video later, see page 22.)
Other video-taking features
■ To review and work with pictures and videos, see page 20.
■ To change camera settings, see page 40.
■ If it’s hard to see the LCD, you can adjust the brightness, see page 41.
12 www.kodak.com/go/support
Page 19
Taking pictures/videos
Zoom
Using the optical zoom
You can use the zoom while taking a video or before taking a picture.
1 Use the LCD to frame your subject.
2 To zoom in, press Telephoto (T).
To zoom out, press Wide Angle (W).
3 Take the picture or video.
NOTE: For focus distances, see Specifications starting on page 49.
Using digital zoom
Use digital zoom to get up to 5X magnification beyond optical zoom. (Digital zoom is
not available in Smart Capture mode.) Press Telephoto (T) until the slider on the LCD
is at the end of the optical zoom range. Release Telephoto (T), then press it again.
NOTE: You may notice decreased image quality when using digital zoom.
Turning on the date stamp feature
You can add a stamp—showing the date taken—to pictures you take next.
IMPORTANT:
1 Press the Display button until tools appear at the top of the LCD.
You cannot add a date stamp to pictures already taken. Once a date stamp
is applied, it cannot be removed on the camera.
2 Press to choose More Tools , then press OK or .
3 Press to choose Date Stamp (Off) , then press OK.
4 Press to choose Date Stamp (On) , then press OK.
The date is stamped on pictures you take next. The feature stays on until you turn it off.
To return to picture-taking mode, press the Shutter button halfway down.
www.kodak.com/go/support
13
Page 20
Taking pictures/videos
Flash button
Using the flash
Press the Flash button repeatedly until the LCD displays the desired flash mode. Flash
modes differ between capture modes.
Flash modes Flash fires
Auto When the lighting conditions require it. The camera processes
the picture to correct red eye.
Flash On (Fill) Every time you take a picture, regardless of the lighting
conditions. Use when the subject is in shadow or is “backlit”
(when the light is behind the subject).
Red-eye
Reduction
Off Never
A preflash fires, shrinking the eye pupil, before the picture is
taken.
14 www.kodak.com/go/support
Page 21
Taking pictures/videos
Using different modes and effects
To take pictures/videos using different modes or effects:
1 Press the Mode button .
2 Press to choose:
■ Smart Capture: For general picture taking.
■ Film Effects: Experiment with picture/video
effects. (Each effect shows an example of what
your picture/videos will look like.)
■ Scene Modes: (See table below.) Choose the
Scene mode that matches your picture-taking
situation–for the best possible pictures.
■ Photobooth: Like a vintage photobooth, the
camera uses a self-timer to take 4 pictures, then
combines them into a single strip. (See
page 16.)
SCN mode For
Program Access to more advanced settings. (See page 17.)
Portrait Full-frame portraits of people.
Sport Action pictures.
Landscape Distant scenes.
Close-up Close range. Use available light instead of flash, if possible.
Sunset Subjects at dusk.
Backlight Subjects that are in shadow or “backlit.”
Candle Light Subjects illuminated by candle light.
Children Action pictures of children in bright light.
www.kodak.com/go/support
15
Page 22
Taking pictures/videos
SCN mode For
Manner/
Museum
Text Documents. For best results, place the camera on a steady surface or
Bright Bright beach or snow scenes.
Fireworks Fireworks. For best results, place the camera on a steady surface or tripod.
Self-Portrait Close-ups of yourself. Assures proper focus and minimizes red eye.
Night Portrait Reduces red eye of people in night scenes or low-light conditions.
Night Landscape Distant scenery at night. Flash does not fire.
High ISO People indoors, in low-light scenes.
Blur Reduction Reducing blur caused by camera shake or subject motion.
Long Time
Exposure
Panorama R-L,
L-R
Quiet occasions, like a wedding or lecture. Flash and sound are disabled.
For best results, place the camera on a steady surface or tripod.
tripod.
Imparting a sense of motion. The settings are: None, 0.5 Sec., 1.0 Sec.,
2.0 Sec., 4.0 Sec., 8.0 sec.
“Stitching” 2 or 3 pictures into 1 panoramic scene. (See page 19.)
Using the photobooth feature
Like a vintage photobooth, the camera uses a self-timer to take 4 pictures, then
combines them into a single strip. For best results, place the camera on a tripod or
steady surface.
1 Press the Mode button .
2 Press to choose Photobooth, then press OK.
3 Compose the scene. Press the Shutter button halfway, then completely down.
The camera takes 4 pictures after 8-second delays, then produces a single strip.
16 www.kodak.com/go/support
Page 23
Taking pictures/videos
White
Balance
Exposure
compensation
ISO
Focus
Zone
Color
Mode
Selftimer
Sharpness
Settings
Using Program mode
Program mode gives access to manual settings like ISO, White Balance, Focus Zone,
and Exposure Compensation.
1 Press the Mode button , choose Scene mode (see page 15), and press OK.
Choose Program, then press OK.
2 Press to choose a setting, then press OK.
Press to change a setting, then press OK to save it.
Self-timer/Burst Include yourself in a picture (page 18). Burst takes a series of pictures in
rapid succession.
Exposure
Compensation
ISO Adjust the camera’s sensitivity to light. Higher ISO indicates greater
White Balance To make picture color more accurate, choose the setting that matches the
Focus Zone Choose Multi-Zone, Center-Zone, Face Priority.
Color Mode Choose Vivid, Full, Basic, Black & White, or Sepia.
Sharpness Choose Sharp, Normal, or Soft.
Settings Choose Vivid, Full, Basic, Black & White, or Sepia.
Adjust the exposure. If a scene is too light, decrease the setting; if it’s
dark, increase the setting.
sensitivity.
NOTE: A higher ISO may produce unwanted “noise” in a picture.
current lighting.
www.kodak.com/go/support
17
Page 24
Taking pictures/videos
10
2
2x
Using the self-timer
Use the self-timer when you want to be included in a picture or to ensure a steady
Shutter button press. For best results, place the camera on a tripod or steady surface.
1 Press the Display button until tools appear at the top of the LCD.
2 Press and to choose the Self-timer/Burst icon.
3 Press to choose a self-timer setting:
Self-timer setting Description
10 Seconds A picture is taken after a 10-second delay (so you have time to get into
the scene).
2 Seconds A picture is taken after a 2-second delay.
2 Picture
Timer
The first picture is taken after a 10-second delay. A second picture is
taken 8 seconds later.
4 Compose the scene. Press the Shutter button halfway, then completely down.
The camera takes the picture/pictures after the delay.
You can use the same procedure to take a video (after a 2- or 10-second delay), but
press the Record button completely down.
Using the burst feature
Use the burst feature to take pictures in rapid succession.
1 Press the Display button until tools appear at the top of the LCD.
2 Press and to choose the Self-timer/Burst icon , then press OK.
3 Press to choose Burst, then press OK.
4 Compose the scene. Press the Shutter button halfway, then down and hold it.
The camera takes pictures until you release the Shutter button, when the burst pictures
are taken, or when there is no more storage space. The flash does not fire.
18 www.kodak.com/go/support
Page 25
Taking pictures/videos
Take
2 or 3
pictures.
Get 1
panoramic
picture.
Taking panoramic pictures
Use panorama to “stitch” up to 3 pictures into a panoramic scene.
NOTE: For best results, use a tripod. Only the panoramic picture is saved; individual pictures are not.
(Exposure and white balance are set with the first picture. The flash is set to Off.)
1 Press the Mode button .
2 Press to choose Scene Modes,
3 Press to choose Panorama Left-Right or Panorama Right-Left
(depending on the direction you want to pan), then press OK.
4 Take the first picture.
After a quickview, the LCD displays the liveview and an “overlay” from the first picture.
5 Compose the second picture. Make the overlay from the first picture cover the
same portion in the new picture.
6 If you are taking/stitching only 2 pictures, press OK to stitch them together.
After you take 3 pictures, the pictures are automatically stitched together.
then press OK.
NOTE: To use the self-timer 10-second or 2-second setting, see page 18.
www.kodak.com/go/support
19
Page 26
3 Reviewing and editing
Keywords, or Videos, then press OK.
Press the Review
button to enter/exit Review.
1
2
Press
to choose All, People, Date,
If you chose People, Date, or Keywords, highlight
a name, date, or keyword, then press OK.
3
You can also review pictures/videos by pressing:
• OK in Liveview, when the most recent picture is highlighted (bottom left of LCD), or
•
during Quickview, while reviewing a new picture
Review
In Liveview In Quickview
In Review
Reviewing pictures/videos
IMPORTANT:
Most
recent
20 www.kodak.com/go/support
Press the Share button to share anytime!
Page 27
Other things you can do in Review
Battery level
Edit
Multi-up
Print
Slideshow
Picture/video
number
Picture has
been marked
for Share
• Press OK to play videos.
• Press to show/hide tools.
• Press
to see previous/next picture/video.
• Press
to delete pictures/videos.
Tags
Back
More tools
Home
Reviewing and editing
www.kodak.com/go/support
21
Page 28
Reviewing and editing
4X
4X
1X2X 2X
Playback speed
Playing a video
When a video is displayed, the Play button is offered. Press OK to play the video.
During playback:
■ To play/pause the video, press the OK button.
■ To fast forward/rewind, press while the video
is playing. To change the speed, press again.
To return to 1X speed, release the button.
■ To forward/rewind one frame at a time, press
while the video is paused.
■ If you don’t like the video, press the Delete button,
then follow the prompts.
Deleting pictures/videos
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, Keywords,
or Videos), then press OK.
If you chose All, People, Date, or Keywords, press to find a picture/video to delete.
(If you chose Videos, thumbnails are displayed.)
3 Press the Delete button, then to choose Picture/Video or All, then press OK.
To delete other pictures, press and repeat this step. When finished, press to
choose Exit, then press OK.
To return to picture-taking mode, press the Shutter button halfway down.
NOTE: Pictures/videos cannot be deleted if the camera is in Safe mode (see page 41).
22 www.kodak.com/go/support
Page 29
Reviewing and editing
Zoom
Viewing pictures/videos in different ways
Magnifying a picture
You can magnify a picture while in review.
1 Press the Review button , then locate a picture.
2 Press Telephoto (T) to magnify 2X–8X.
3 Press to view other parts of a picture.
Press OK to return to 1X.
Viewing pictures as thumbnails
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, Keywords,
or Videos), then press OK.
If you chose All, People, Date, or Keywords, a single-up picture is shown. (If you chose
Videos, multi-up is already displayed.)
3 Press the Display button until tools appear at the top of the LCD.
4 Press and to choose Multi-up , then press OK.
Thumbnails are shown.
To select multiple pictures/videos, see page 32.
To return to picture-taking mode, press the Shutter button halfway down.
www.kodak.com/go/support
23
Page 30
Reviewing and editing
Use
to access Keywords
and Videos.
A smarter way to find and enjoy your pictures
Tag pictures—by people or keywords—to make them easy to find, later. For example,
the camera can find all pictures that contain “Mary” or “Dad’s 60th Birthday.” (See
Tagging people, page 36 or Tagging with keywords, page 38.)
1 Press the Review button .
2 Press to see All pictures/videos or those sorted by Date, People, Keywords or
Videos.
If you chose All, People, Date, or Keywords, a single-up picture is shown. (If you chose
Videos, thumbnails are displayed.) If you press OK while a video is highlighted, the video
plays.)
To return to picture-taking mode, press the Shutter button halfway down.
Tip: For best results, make sure the camera date/time is current (see page 41).
24 www.kodak.com/go/support
Page 31
Stop
Video duration
Volume
Video progress
Video controls
Tr im
Make picture from a video
Action Print
Home
Back
Multi-up
Tags
Edit
Hide tools
Picture/video number
Battery level
Picture has been marked
for Share
Videos
Pictures
Print
Slideshow
Understanding the review icons
Reviewing and editing
www.kodak.com/go/support
25
Page 32
Reviewing and editing
Adding a border to a picture
You can enhance a picture by adding a border.
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
A single-up picture is shown. Press to choose a different picture.
3 Press the Display button until tools appear at the top of the LCD.
4 Press and to choose Edit , then press OK.
5 Press to choose Effects , then press OK.
6 Press to choose Borders, then press OK.
7 Press to choose a border style, then press OK.
8 Press to choose Cancel or Apply, then follow the prompts.
To return to picture-taking mode, press the Shutter button halfway down.
26 www.kodak.com/go/support
Page 33
Reviewing and editing
Using photo effects to change a picture’s tint
You can enhance a picture by tinting it.
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
A single-up picture is shown. Press to choose a different picture.
3 Press the Display button until tools appear at the top of the LCD.
4 Press and to choose Edit , then press OK.
5 Press to choose Effects , then press OK.
6 Press to choose Tint, then press OK.
7 Press to choose a tint, then press OK.
8 Press to choose Cancel or Apply, then follow the prompts.
To return to picture-taking mode, press the Shutter button halfway down.
www.kodak.com/go/support
27
Page 34
Reviewing and editing
Cropping a picture
You can crop a picture so that only the desired portion of the picture remains.
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
A single-up picture is shown. Press to choose a different picture.
3 Press the Display button until tools appear at the top of the LCD.
4 Press and to choose Edit , then press OK.
5 Press to choose Crop , then press OK.
6 Follow the prompts to crop the picture.
To return to picture-taking mode, press the Shutter button halfway down.
Rotating pictures
You can rotate a picture to portrait or landscape orientation.
1 Press the Review button.
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
A single-up picture is shown. Press to choose a different picture.
3 Press and to choose Edit , then press OK.
4 Press to choose Rotate Picture, then press OK.
5 Press to highlight Rotate Right or Rotate Left.
6 Press OK.
To return to picture-taking mode, press the Shutter button halfway down.
28 www.kodak.com/go/support
Page 35
Reviewing and editing
Trimming a video
You can remove the start or end of a video, saving only the desired portion.
1 Press the Review button .
2 Press to choose Videos, then press OK.
Thumbnails are displayed.
3 Press and to choose Select Images, then press OK.
4 Press and to choose a video, then press OK.
5 Press and to choose the Edit icon .
6 Press to choose Trim , then press OK.
7 Press to move the Start position. When you’re satisfied, press OK to lock it.
Press to choose the End trim mark , then press OK. Press to move the
End position. When you’re satisfied, press OK to lock it.
8 Press to choose Done, then press the OK button. Follow the prompts to Save as
New, Cancel, or Replace Original.
www.kodak.com/go/support
29
Page 36
Reviewing and editing
Making a picture from a video
You can choose a single frame from a video, then make a picture suitable for a
4 x 6-inch (10 x 15 cm) print.
1 Press the Review button .
2 Press to choose Videos, then press OK.
Thumbnails are displayed.
3 Press and to choose Select Images, then press OK.
4 Press and to choose a video, then press OK.
5 Press and to choose the Edit icon .
6 Press to choose Make Picture , then press the OK button.
7 Press OK to play/pause the video. Press while paused to rewind/forward
frame-by-frame.
8 When you reach the desired frame, press and to choose Make Picture
, then press OK
The picture is created. (The original video is saved.)
To return to picture-taking mode, press the Shutter button halfway down.
30 www.kodak.com/go/support
Page 37
Reviewing and editing
Making an action print from a video
From a video, you can make a 9-up picture, suitable for a 4 x 6-inch
(10 x 15 cm) print.
1 Press the Review button .
2 Press to choose Videos, then press OK.
Thumbnails are displayed.
3 Press and to choose Select Images, then press OK.
4 Press and to choose a video, then press OK.
5 Press and to choose the Edit icon .
6 Choose Action Print , then press OK.
A 9-up picture is created.
To return to picture-taking mode, press the Shutter button halfway down.
www.kodak.com/go/support
31
Page 38
Reviewing and editing
Selecting multiple pictures/videos
Use the multi-select feature when you have two or more pictures to share, delete,
protect/unprotect, tag with keyword, etc. Multi-select is only available in thumbnail
view (see page 23).
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, Keywords,
or Videos), then press OK.
3 If you chose All, People, Date, or Keywords, a single-up picture is shown. Press
and to choose Multi-up , then press OK. (If you chose Videos, multi-up is
already displayed.)
4 Press and to choose Select Images, then press OK.
5 Press to choose a picture/video. Press OK to select it.
A check mark appears on the picture. (Press OK again to remove a check mark.) Repeat
this step to select other pictures/videos.
6 You can now share, delete, choose a tool, etc. and apply it to the selected
pictures/videos.
NOTE: You can also share multiple pictures/videos using the Share button (see page 34).
32 www.kodak.com/go/support
Page 39
Reviewing and editing
Displaying pictures/videos on a television
You can display pictures/videos on a television, computer monitor, or any device
equipped with a composite video input. To connect the camera directly to a television,
use a composite cable (may be sold separately). Use the camera controls to navigate
through pictures/videos on the television.
Purchase accessories www.kodak.com/go/accessories
NOTE: Image quality on a television screen may not be as good as on a computer monitor or when printed.
www.kodak.com/go/support
33
Page 40
4 Sharing pictures/videos
In Liveview In Quickview
In Review
Sharing through email and social networks
It’s never been easier to share pictures on your favorite social networking sites. As
new sites become available, they’ll be offered when you connect the camera to a
networked computer.
IMPORTANT:
1 Press the Share button to share anytime:
2 Press and OK to choose social networking sites or email addresses.
To use the sharing and social networking features, you must install the
KODAK Share Button App. (See page 43.)
3 Press to choose Done, then press OK.
When you transfer these pictures/videos to your computer, they are sent to the sharing
destinations you chose.
34 www.kodak.com/go/support
Page 41
Sharing pictures/videos
Choose which social networking sites to display on your camera
You can show/hide networking sites on your camera so that only your favorite sites
appear.
NOTE: New sites are added when available.
1 Press the Review button .
2 Press the Display button until tools appear at the top of the LCD.
3 Press to choose Settings , then press the OK button.
4 Press to choose Share Button Settings, then press OK.
5 Press OK to check/uncheck each social networking site.
When you are in Review and press the Share button, your chosen sites appear.
To return to picture-taking mode, press the Shutter button halfway down.
Manage email addresses and KODAK PULSE Digital Frames
You can add, edit, or delete email addresses and KODAK PULSE Digital Frames on
your camera. (To use the keyboard, see page 38.)
1 Press the Share button.
2 Tap Manage Email Addresses or Manage Picture Frames, then.
3 Tap a choice to add, delete, or edit an email address or frame.
The keyboard appears when you need to type. See page 38.
4 Tap Done or Next, then tap OK.
To return to picture-taking mode, press the Shutter button halfway down.
www.kodak.com/go/support
35
Page 42
Sharing pictures/videos
Tagging pictures
Tag pictures to make them easy to find, later. You can tag pictures in 2 ways:
■ People, and then find all pictures of “Mary.”
■ Keywords, and then find all pictures from “Dad’s 60th Birthday.”
Tagging people
When you tag faces, you’re helping your camera to recognize people by name. Then it
and
matches names and faces in pictures you’ve taken—
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
If you chose People, Date, or Keywords, choose a person, date, or keyword.
3 Press the Display button until tools appear at the top of the LCD.
4 Press to choose Tags , then press the OK button.
5 Press to choose Tag People, then press OK.
6 Press to choose an existing name or Enter New Name to add a new one
(see page 38), then press OK.
If more than one face is detected, a name or question mark is assigned to each detected
face. To resolve an incorrect name or a question mark, press to select a face,
then press OK.
those you take in the future!
7 If prompted to Update People Tags, press to choose Yes, then press OK.
Other pictures are scanned and updated with the name(s) you applied here.
Press to add names to other pictures. When finished, press to choose
Done, then press OK.
36 www.kodak.com/go/support
Page 43
Sharing pictures/videos
Need to update a name?
If you meet a new friend—James—but you already have pictures tagged with your
old friend, James, you can:
■ Tag the new James with “James Smith” and/or
■ Update the old James to “James Monroe”
Here’s how:
1 Press the Review button .
2 Press to choose Settings , then press the OK button.
3 Press to choose People Tag Settings (or Keyword Tag for videos), then press
OK.
4 Press to choose Modify Names List, then press OK.
5 Press to choose the name you want to modify, then press OK.
The name is highlighted. Press to choose Edit or Delete. (The keyboard appears
when you need to type. See page 38.)
6 Edit the name, press to choose OK, then press OK. (If prompted to Update
People Tags, press to choose Yes, then press OK.)
NOTE: You can have up to 20 names.
www.kodak.com/go/support
37
Page 44
Sharing pictures/videos
Tagging with keywords
Tag pictures to make them easy to find, later.
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords), then press OK.
A single-up picture is shown. Press to choose a different picture.
3 Press the Display button until tools appear at the top of the LCD.
4 Press to choose Tags , then press the OK button.
5 Press to choose Keyword Tag, then press OK.
6 Press to choose a tag (or and to add a tag using the “+” sign), then
press OK.
7 Press and to choose Done, then press OK.
Using the keyboard
The keyboard appears when you need to type.
1 Press to choose a letter, then press OK.
2 When finished, press to choose Done, then press OK.
38 www.kodak.com/go/support
Page 45
Sharing pictures/videos
Marking pictures/videos as favorites
Mark pictures as favorites to make them easy to find, later.
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, Keywords,
or Videos), then press OK.
3 Press the Display button until tools appear at the top of the LCD.
4 Press to choose Tags , then press OK.
5 Press and to choose Keyword Tags, then press OK.
6 Press to choose Favorite, then press OK.
7 Press to choose Done, then press OK.
www.kodak.com/go/support
39
Page 46
5 Doing more with your camera
Changing settings
You can change settings to get the best results from your camera.
NOTE: Some modes offer limited settings. Some settings remain until you change them; others, until you
change modes or turn off the camera.
1 In liveview or review mode, press the Display button until tools appear at the
top of the LCD.
2 Press to choose Settings , then press the OK button.
3 Press to choose a setting, then press OK.
NOTE: Some settings let you press to change a setting.
4 When finished with a setting, press OK.
Setting More information
Share Button Settings
Choose the people and Web
sites with whom you share
pictures and videos.
People Tag Settings
Maintain names and faces.
Picture or Video Size
Choose a picture or video
resolution.
Edit People—Add, modify, or delete people, email
addresses, and digital picture frames so that you can share
with your favorite people.
Edit Web Sites—Decide which sites (such as KODAK
Gallery, FACEBOOK, YouTube, etc.) are offered on your
camera. Also create sharing messages and titles.
Update People Tags—Matches recently tagged people
with other pictures that may include these people.
Modify Names List—Edit or delete existing names.
See Specifications, starting on page 49.
40 www.kodak.com/go/support
Page 47
Doing more with your camera
Setting More information
Slide Show Settings
Set your slide show
preferences.
AF Control (Still)
Choose an auto-focus setting.
LCD Brightness
Choose LCD brightness during
picture/video capture. (During
Review, the LCD is set to High
Power.)
Sound Volume
Choose volume.
Date & Time Set date and time.
Language Choose your language.
Reset All Camera Settings Reset settings to their default.
Computer Connection
Choose which application is
downloaded or launched when
you connect the camera to the
computer.
Safe Mode
In Safe mode, pictures/videos
cannot be deleted or modified.
Transitions
Loops
Intervals
Continuous AF—Because the camera is always focusing,
there is no need to press the Shutter button halfway down to
focus.
Single AF—Focuses when the Shutter button is pressed
halfway down. (This setting uses less battery power.)
High Power—Brighter LCD; uses more battery power.
Power Save—Dimmer LCD; uses less power.
Auto—LCD brightness is automatically adjusted according to
environment.
High
Medium
Low
Mute
KODAK Software
Other Application (APPLE iPHOTO, etc.)
IMPORTANT:
To use the social networking features, you
must install the KODAK Share Button App
(see page 43).
On
Off
www.kodak.com/go/support
41
Page 48
Doing more with your camera
CAUTION:
Setting More information
Format
Formatting deletes all
pictures/videos,
including those that are
Memory Card—Deletes everything on the card; formats the
card.
Cancel—Exits without making a change.
Internal Memory—Deletes everything in internal memory
including email addresses and keyword tags; formats the
internal memory.
protected. Removing a
card during formatting
may damage the card.
KODAK Camera Software View the URL to download KODAK Software.
About View camera information.
42 www.kodak.com/go/support
Page 49
6 Install software
Install software, transfer pictures, and share
IMPORTANT:
KODAK Share Button App.
1 Make sure the computer is connected to the Internet.
5 After the software is installed, follow the prompts to transfer pictures and videos
to your computer.
Pictures/videos that you tagged for sharing are emailed or uploaded to the desired
social networking sites.
NOTE: You can also use a card reader to transfer pictures/videos to your computer.
To use the sharing and social networking features, you must install the
2 Turn off the camera.
3 Using the KODAK Camera USB Cable,
Micro B / 5-Pin, connect the camera to the
computer. (Use only the cable included with this
camera.)
4 Follow the prompts on your computer screen to
download and install the Share Button App on your
computer.
IMPORTANT:
If the installer does not run, choose and
install the right version for your computer:
www.kodak.com/go/camerasw.
Download KODAK Share Button App www.kodak.com/go/camerasw
Get software help www.kodak.com/go/support
See How-To videos www.kodak.com/go/M5350demos
www.kodak.com/go/support 43
Page 50
Install software
Printing pictures
Direct printing with a KODAK All-in-One Printer
IMPORTANT:
You need a camera, a PICTBRIDGE enabled Printer, and a USB cable.
Connecting the camera to a KODAK All-in-One Printer
1 Turn off the camera and printer.
2 Use the KODAK Camera USB Cable, Micro B / 5-Pin (included with the camera) to
connect the camera to the printer.
Printing from a KODAK All-in-One Printer
1 Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu turns off, press any button to
redisplay it.
2 Choose a printing option, then press OK.
Current Picture—Press to choose a picture.
Tagged Pictures—If your printer is capable, print pictures that you marked for
printing.
Index Print—Print thumbnails of all pictures. (This option requires one or more
sheets of paper.)
All Pictures—Print all pictures in internal memory or on a card.
NOTE: During direct printing, pictures are not permanently transferred or saved to the printer. To transfer
pictures to your computer, see page 43.
To print using PICTBRIDGE Technology, you must change the Computer
Connection setting (in the Settings menu) to Other Application (see
page 41).
Purchase cables, accessories www.kodak.com/go/accessories
44 www.kodak.com/go/support
Page 51
Install software
Ordering prints online
KODAK Gallery (www.kodakgallery.com) makes it easy to:
■ Upload your pictures.
■ Edit, enhance, and add borders to your pictures.
■ Store pictures, and share them with family and friends.
■ Have prints, photo greeting cards, frames, and albums delivered to your door.
Printing from an optional SD or SDHC Card
■ Automatically print tagged pictures when you insert your card into a printer. See
your printer user’s guide for details.
■ Make prints at a KODAK Picture Kiosk. Go to www.kodak.com/go/picturemaker.
■ Take the card to your local photo retailer for professional printing.
Marking your pictures for print
1 Press the Review button .
2 Press to choose a stack of pictures (All, or sorted by People, Date, or
Keywords). Press OK until you see a single-up picture or press OK to choose
multiple pictures.
3 Press the Display button until tools appear at the top of the LCD.
4 Press to choose Print, then press OK.
5 Press to choose the number of copies, then press OK.
The pictures are printed when you transfer them to your computer.;
To return to picture-taking mode, press the Shutter button halfway down
www.kodak.com/go/support
45
Page 52
7 Troubleshooting
Camera
Status Solution
Camera does not
turn on/off or function
LCD is too dark. ■ Adjust the LCD Brightness setting in the Settings menu (see
Short battery life ■ Make sure the battery is charged (see page 1).
Flash does not fire ■ The flash does not fire in all modes. Change modes as needed
Memory card is almost
or entirely full
You cannot take a
Pictures remaining
number does not
decrease after taking a
Memory card not
recognized or camera
freezes with card
■ Make sure the battery is charged and installed correctly (see
page 1).
page 41).
■ Limit the time you review pictures/videos on the camera LCD.
■ Purchase a spare battery at www.kodak.com/go/accessories.
(see page 14).
■ Transfer the pictures to the computer (see page 43).
■ Delete pictures from the card (see page 22) or insert a new card.
■ Turn the camera off, then on again.
■ Depress the Shutter button all the way (see page 8).
■ Insert a new/charged battery (see page 1).
■ Memory is full. Transfer pictures to the computer (see page 43),
delete pictures (see page 22), or insert another card.
■ Continue taking pictures. The camera is operating normally.
(The camera estimates the number of pictures remaining after each
picture is taken, based on picture size and content.)
■ Card may be corrupted. Format the card in the camera (see
page 42).
■ Use another memory card. Only SD or SDHC Cards are supported.
46 www.kodak.com/go/support
Page 53
Troubleshooting
Status Solution
Cannot find the
■ To view pictures on a card or in internal memory, see page 20.
desired picture/video
Computer/connectivity
Status Solution
Computer does not
communicate with
the camera
■ Turn off the camera, then turn it back on.
■ Make sure the battery is charged and installed correctly (see
page 1).
■ Make sure the KODAK Camera USB Cable, Micro B / 5-Pin is
connected to the camera and the computer (see page 43). Then
turn on the camera.
■ See KODAK Software Downloads at
www.kodak.com/go/camerasw.
Direct printing (PICTBRIDGE enabled Printer)
Status Solution
Cannot print ■ The camera must be in PTP (not mass storage) mode. Change the
Computer Connection setting (in the Settings menu) to Other
Application (see page 41).
Picture quality
Status Solution
Picture is not clear ■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ Clean the lens (see page 51).
■ Place the camera on a flat, steady surface or use a tripod (especially
in high-zoom settings or in low light).
■ Use a larger picture size (see page 40).
■ If you’re manually adjusting the ISO speed, realize that a high ISO
setting may cause grainy pictures (see page 17).
www.kodak.com/go/support
47
Page 54
Troubleshooting
Status Solution
Picture is too dark ■ Reposition the camera for more available light.
■ Use Fill flash (see page 14) in Program mode, change your position
so light is not behind the subject, or use the Backlight SCN mode.
■ Move so that the distance between you and the subject is within the
effective flash range. (See Specifications starting on page 49.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ In Program mode, increase the Exposure Compensation (see
page 17).
Picture is too light ■ Reposition the camera to reduce the amount of available light.
■ Turn the flash off (see page 14).
■ Move so that the distance between you and the subject is within the
effective flash range. (See Specifications starting on page 49.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ In Program mode, decrease the Exposure Compensation (see
page 17).
Getting help on the Web
Get support for your product (FAQs, troubleshooting
www.kodak.com/go/support
information, etc.)
Purchase camera accessories www.kodak.com/go/accessories
Download the latest camera firmware and software www.kodak.com/go/M5350downloads
Register your camera www.kodak.com/go/register
Chat, email, write, or phone Kodak
www.kodak.com/go/contact
(Chat not available in all languages)
48 www.kodak.com/go/support
Page 55
8 Appendix
Specifications
CCD—1/2.3-type
Effective pixels—16 MP (4632 x 3472)
LCD—2.7 in. (6.9 cm) LCD; 230K dots; 4:3 aspect ratio
Image storage—Optional SD/SDHC Card (The SD logo is a trademark of the
SD Card Association.) Maximum supported card size: 32 GB
Internal storage capacity—32 MB internal memory (18 MB available for image
storage. 1 MB equals one million bytes.)
Taking lens—5X optical zoom; f/3.9–f/5.7; 35 mm equivalent: 28–140 mm
Digital zoom—5X continuous
Focus system—TTL-AF (through-the-lens auto focus); Multi-Zone, Center-Zone,
Face Priority. Working range:
0.5 m (1.6 ft)–infinity @ wide, normal
1.5 m (4.9 ft)–infinity @ telephoto, normal
5–80 cm (2–31.5 in.) @ wide, Macro mode
1–1.8 m (3.3–5.9 ft) @ telephoto, Macro mode
Auto focus control—Continuous and Single AF
Face detection—Ye s
Face recognition—Yes
Shutter speed—1/8–1/1600 seconds
Long time exposure—1/2–8 seconds
ISO speed—Auto: 64–400; Manual: 64, 100, 200, 400, 800, 1600
Focus/Exposure Zone—TTL-AE; Face Priority, Multi-Zone, Center-Zone
www.kodak.com/go/support 49
Page 56
Appendix
Exposure compensation—+/-2.0 EV with 1/3 EV step
White Balance—Auto, Daylight, Tungsten, Fluorescent, Open Shade
Electronic Flash—Auto flash; Auto, Fill, Red Eye, Off; Guide No. 6.2 (m) @ ISO
400; working range in Smart Capture mode: 0.5–3.1 m (1.6–10.2 ft) @ wide; 1–2.1
m (3.3–6.9 ft) @ telephoto
Self-timer mode—2 seconds, 10 seconds, 2 picture timer
Burst mode—Maximum 3 pictures @ 1.0 fps
Capture modes—Smart Capture, Film Effects, Photobooth, Scene modes, Video
Image file format—
Still: EXIF 2.3 (JPEG compression); file organization DCF
Video: MP4, CODEC H.264
Picture size—16 MP (4:3): 4608 x 3456 pixels
14 MP (3:2): 4608 x 3072 pixels
12 MP (16:9): 4608 x 2592 pixels
6 MP (4:3): 2880 x 2160 pixels
3 MP (4:3): 2048 x 1536 pixels
Video size—
HDV (1280 x 720 @ 30 fps)
VGA (640 x 480 @ 30 fps)
Recording limit —VGA: < 4 GB; HD: < 4 GB or < 29 mins.
Color modes—Viv id Co l or, Ful l C ol o r, B as i c C ol o r, B la ck & Wh it e, S ep ia
Sharpness modes—Sharp, Normal, Soft
Communication with computer—USB 2.0 high speed (PIMA 15740 protocol);
via KODAK Camera USB Cable, Micro B / 5-Pin
Microphone—Yes
Speaker—Yes
PICTBRIDGE support—Yes
50 www.kodak.com/go/support
Page 57
Appendix
Power—KODAK Li-Ion Rechargeable Digital Camera Battery KLIC-7006
Tripod mount—1/4 inch
Size—93 x 55 x 19 mm (3.7 x 2.2 x 0.7 in.) @ power off
Weight—120 g (4.2 oz) with battery and card
Operating temperature—0–40
° C (32–104° F)
Care and maintenance
■ If you suspect water has gotten inside the camera, remove the battery and card.
Allow all components to air-dry for at least 24 hours before using the camera.
■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■ Service agreements may be available in your country. Contact a dealer of KODAK
Products for more information.
■ For digital camera disposal or recycling information, contact your local authorities.
In the US, go to the Electronics Industry Alliance site at www.eiae.org or go to
www.kodak.com/go/support.
Upgrading your software and firmware
We occasionally update KODAK Software and firmware (the software that runs on the
camera). For instructions on installing the latest version, go to
www.kodak.com/go/M5350downloads.
Storage capacities
The LCD displays the approximate number of pictures (or minutes/seconds of video)
remaining. Actual storage capacity varies depending on subject composition, card
size, and other factors. You may be able to store more or fewer pictures and videos.
www.kodak.com/go/support
51
Page 58
Appendix
CAUTION:
Important safety instructions
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. KODAK AC Adapters
and Battery Chargers are intended for indoor use only. The use of
controls, adjustments, or procedures other than those specified herein
may result in exposure to shock and/or electrical or mechanical hazards. If
the LCD breaks, do not touch the glass or liquid. Contact Kodak customer
support.
■ The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, go to www.kodak/go/accessories.
■ Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■ If using this product in an airplane, observe all instructions of the airline.
■ When removing the battery, allow it to cool; it may be hot.
■ Follow all warnings and instructions supplied by the battery manufacturer.
■ Use only batteries approved for this product to avoid risk of explosion.
■ Keep batteries out of the reach of children.
■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery
may short circuit, discharge energy, become hot, or leak.
■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,
or extreme temperature.
■ Remove the battery when the product is stored for an extended period of time. In
the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.
■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.
52 www.kodak.com/go/support
Page 59
Appendix
■ Go to www.kodak.com/go/reach for information about the presence of substances
included on the candidate list according to article 59(1) of Regulation (EC) No.
1907/2006 (REACH).
■ Dispose of batteries according to local and national regulations. Go to
www.kodak.com/go/kes.
■ Do not charge non-rechargeable batteries.
Battery replacement, battery life
KODAK Li-Ion Rechargeable Digital Camera Battery KLIC-7006: 200 pictures per
charge. Battery life per CIPA testing method. (Approximate number of pictures in
Smart Capture mode, using an SD Card.) Actual life may vary based on usage.
Extending battery life
■ Use a power-saving LCD Brightness setting (see page 41).
■ Charge the battery whenever necessary.
■ Dirt on the battery contacts can affect battery life. Wipe the contacts with a pencil
eraser before loading the battery in the camera.
■ Battery performance is reduced at temperatures below 41° F (5° C). When using
your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.
Limited warranty
Kodak warrants its digital cameras and accessories (excluding batteries) to be free
from malfunctions and defects in both materials and workmanship for the warranty
period specified on your KODAK Product packaging. Retain the original dated sales
receipt. Proof of purchase date is required with any request for warranty repair.
www.kodak.com/go/support
53
Page 60
Appendix
Limited warranty coverage
Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased. Kodak
will repair or replace Products if they fail to function properly during the warranty
period, subject to any conditions and/or limitations stated herein. Warranty service
will include all labor as well as any necessary adjustments and/or replacement parts. If
Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the
purchase price paid for the Product provided the Product has been returned to Kodak
along with proof of the purchase price paid. Repair, replacement, or refund of the
purchase price are the sole remedies under the warranty. If replacement parts are
used in making repairs, those parts may be remanufactured, or may contain
remanufactured materials. If it is necessary to replace the entire Product, it may be
replaced with a remanufactured Product. Remanufactured Products, parts and
materials are warranted for the remaining warranty term of the original Product, or 90
days after the date of repair or replacement, whichever is longer.
Limitations
This warranty does not cover circumstances beyond Kodak's control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak's
operation, maintenance or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
warranty. Kodak makes no other express or implied warranty for this product. In the
event that the exclusion of any implied warranty is ineffective under the law, the
duration of the implied warranty will be the length of the express warranty period
specified on your Kodak product packaging. The option of repair, replacement, or
refund is Kodak's only obligation. Kodak will not be responsible for any special,
consequential or incidental damages resulting from the sale, purchase, or use of this
product regardless of the cause. Liability for any special, consequential or incidental
damages (including but not limited to loss of revenue or profit, downtime costs, loss
of the use of the equipment, cost of substitute equipment, facilities or services, or
54 www.kodak.com/go/support
Page 61
Appendix
claims of your customers for such damages resulting from the purchase, use, or failure
of the Product), regardless of cause or for breach of any written or implied warranty is
expressly disclaimed. The limitations and exclusions of liability set forth herein apply
to both Kodak and its suppliers.
Your rig ht s
Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. This warranty gives you specific
rights, and you may have other rights which vary from state to state or by jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.
Regulatory compliance
FCC compliance and advisory
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed or used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: 1) reorient or relocate the
receiving antenna; 2) increase the separation between the equipment and the
receiver; 3) connect the equipment to an outlet on a circuit different from that to
www.kodak.com/go/support
55
Page 62
Appendix
N137
which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions. Any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment. Where shielded interface cables have been provided with the
product or specified additional components or accessories elsewhere defined to be
used with the installation of the product, they must be used in order to ensure
compliance with FCC regulation. The KODAK High Performance USB AC Adapter
K20-AM complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Waste Electrical and Electronic Equipment/Battery disposal
In Europe: For human/environmental protection, it is your responsibility to
dispose of this equipment and batteries at a collection facility established for
this purpose (separate from municipal waste.) For more information, contact
your retailer, collection facility, or appropriate local authorities; or go to
www.kodak.com/go/recycle. Product weight: 120 g (4.2 oz) with battery
Canadian DOC statement
DOC Class B Compliance—This Class B digital apparatus complies with Canadian
ICES-003.
Observation des normes-Classe B—Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
CE
Hereby, Eastman Kodak Company declares that this KODAK Product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Australian C-Tick
56 www.kodak.com/go/support
Page 63
VCCI Class B ITE
Eastman Kodak Company
Rochester, NY 14650
Korean Class B ITE
Russian GOST-R
Appendix
www.kodak.com/go/support
57
Page 64
Appendix
Korean Li-Ion Regulatory
58 www.kodak.com/go/support
Page 65
China RoHS
Appendix
www.kodak.com/go/support
59
Page 66
Index 1
A
A/V out, 33
about this camera, 42
accessories
battery, 53
buying, 48
SD/SDHC Card, 6
action print, 31
add keywords, names, 38
adding a border, 26
AF control, 41
auto
focus control, 41
focus framing marks, 8
B
backlight, 15
battery
charging, 2
expected life, 53
icons, 11
loading, 1
types, 53
beach, 16
brightness, LCD, 12
burst, 18
button
Delete, 22
Display, 9
Mode, 15
Review, 40
Share, 34
Telephoto/Zoom, 13
C
cable
audio/video, 33
Camera Setup App, 43
camera sounds, 41
Canadian compliance, 56
care and maintenance, 51
charging
battery icon, 11
external charger, 3
internal charger, 2
USB, 4
charging the battery, 2
children, 15
clock, setting, 5
computer
connect camera, 43
transfer to, 43
computer connection, 41
connector, USB / A/V, 33
copy pictures
to computer, 43
cropping pictures, 28
D
date setting, 5
date stamp, 13
Delete button, 22
deleting
from internal memory, 22
60 www.kodak.com/go/support
Page 67
Index
from SD/SDHC Card, 22
digital zoom, 13
Display button, 9
display, brightness, 12
disposal, recycling, 51
download
KODAK Software, 43
download pictures, 43
E
edit videos, 29
email, 34
emailing pictures, videos, 39
erase, 42
expected battery life, 53
exposure
long time, 40
external charging, 3
external video device
viewing pictures, videos, 33
F
faces, tagging, recognition, 36
FCC compliance, 55
find pictures, 24
fireworks, 16
firmware, upgrading, 51
flash, using, 14
flower, 15
focus framing marks, 8
format, 42
framing marks, 8
G
guidelines, battery, 53
H
help
Web links, 46
high ISO, 16
I
icons
battery, 11
icons, modes, 15
in-camera charging, 2
installing
battery, 1
SD/SDHC Card, 6
K
keyboard, 38
keywords, 38
KODAK Camera Setup App, 43
KODAK EASYSHARE Software
upgrading, 51
KODAK Software, download, 43
Kodak Web sites, 46
L
language, 41
LCD
brightness, 41
reviewing pictures, 20
reviewing videos, 20
LCD brightness, 12
lens
cleaning lens, 51
loading
battery, 1
SD/SDHC Card, 6
www.kodak.com/go/support 61
Page 68
Index
locate pictures, 24
long time exposure, 40
M
magnify a picture, 23
maintenance, camera, 51
make picture from video, 30
manner/museum, 16
marking
for email, 39
memory
inserting card, 6
menu settings, 40
mode
safe, 41
Mode button, 15
modes, 15
backlight, 15
beach, 16
children, 15
fireworks, 16
flower, 15
high ISO, 16
manner/museum, 16
night landscape, 16
night portrait, 16
self-portrait, 16
text, 16
multiple selections, 32
multi-up, thumbnail, 23
N
night landscape, 16
night portrait, 16
O
online prints, ordering, 45
optical zoom, 13
P
panoramic pictures, 19
people, tagging, 36
photo effect, tinting, 27
photobooth, 16
PICTBRIDGE enabled printer, 44
picture size, 40
picture taking, 8
pictures
adding date stamp, 13
border, adding, 26
cropping, 28
emailing marked, 39
marking, 45
review icons, 25
reviewing, 20
taking, modes, 15
tinting, 27
transfer to computer, 43
pictures/video
deleting, 22
playing a video, 22
power
camera, 5
power icon, 11
print from a video, 31
printing
from a card, 45
optimizing printer, 46
order online, 45
62 www.kodak.com/go/support
Page 69
Index
PICTBRIDGE, 44
tagged pictures, 45
R
record button, 12
recycling, disposal, 51
regulatory information, 55
reset camera, 41
Review button, 40
reviewing pictures/video
deleting, 22
LCD, 20
S
safe mode, 41
safety, 52
SD/SDHC Card
inserting, 6
printing from, 45
search pictures, 24
select multiple pictures/videos, 32
self-portrait, 16
self-timer, 18
setting
about this camera, 42
auto focus, 41
camera sounds, 41
computer connection, 41
date and time, 5
format, 42
language, 41
LCD brightness, 41
long time exposure, 40
picture size, 40
picture-taking mode, 15
reset all settings, 41
safe mode, 41
self-timer, 18
slide show, 41
tag people, 40
setting up the camera, 1
settings
picture, video size, 40
Share, 40
settings menu, 40
Share button, 34
Share settings, 40
shutter
problems, 46
self-timer delay, 18
shutter button, 8
single frame, 31
slide show settings, 41
smart find, 24
social networks, 34
software
upgrading, 51
software downloader, 43
sounds, 41
specifications, camera, 49
strap, 7
T
tag people setting, 40
tagging
keywords, 38
people, faces, 36
taking a picture, 8
www.kodak.com/go/support 63
Page 70
Index
taking a video, 12
taking pictures, videos, 8
television, slide show, 33
text, 16
thumbnail view, 23
time, setting, 5
timer, shutter delay, 18
tinting a picture, 27
tips
battery guidelines, 53
care & maintenance, 51
transfer pictures, 43
trimming a video, 29
troubleshooting, 46
turning camera on and off, 5
typing, 38
U
upgrading software, firmware, 51
URLs, Kodak Web sites, 46
USB
transfer pictures, 43
USB charging, 4
V
VCCI compliance, 57
video
edit, 29
emailing marked, 39
playback, 22
recording, 12
review icons, 25
transfer to computer, 43
viewing, 20
video action print, 31
video button, 12
video size, 40
viewing
by multi-up, thumbnails, 23
picture, after taking, 20
W
warranty, 53
Z
zoom
digital, 13
optical, 13
64 www.kodak.com/go/support
Loading...
