Kodak i5000 Series Scanners
Serious scanning power
for real-world volumes
Real world, real results
At the end of the day, success depends on how much you’ve accomplished
since the start of your day. For years, award-winning Kodak i5000 Series
Scanners have been the choice of the most demanding customers in the
toughest scanning environments – service bureaus, business process
outsourcing organizations, and corporate scanning departments. The
newest i5000 models oer eciency and reliability that can positively
impact productivity and enable true, high-volume processing.
Rated speed and real-world throughput
can be very dierent numbers. Kodak
i5000 Series Scanners get high marks for
delivering on what they promise. Truth in
specifications and engineering know-how
adds up to high volume throughput. It’s the
processing speed, smooth paper flow, and
document handling versatility you need.
• i5000 Scanners can maintain highspeed throughput even at 300 dpi for
both bitonal and color images
• All models can scan an unlimited daily
volume of documents
• Dynamic Flow Technology – delivers
optimized memory allocation and
processing paths, letting the scanner
find the most ecient way to scan,
perform imaging functions and extract
data (not available on V models)
• Speed processing by loading any diverse
mix of documents – including fragile and
extra thick originals
• The large input tray can hold up to
750 documents, keeping the scanner
busy longer
• Spend less time adjusting documents –
controlled stacking technology keeps
documents neatly lined up
Advanced eciency features handle
complex tasks and dicult document
types easily. Anticipating and avoiding
potential problems in advance helps to
minimize interruptions and slowdowns.
• Prevent document damage with
Intelligent Document Protection (IDP);
it listens for problems and alerts you
before they become jams or misfeeds
• Monitor multi-feeds on the PC and
quickly choose to ignore, accept or rescan
images from the scanner control panel
• Save data entry time and enhance
accuracy with barcode reading capability
that delivers data to applications
• Get improved touchscreen visibility
with wide-angle viewing from two
ergonomically correct positions
• Organize large, multi-batch jobs
with Intelligent Imprinting and simple
patch counting
• Reduce the need for rescans and postimage processing – auto image rotation
and skew detection ensure that images
are right side up and straight
Exceptionally clear images are essential
for accurate data capture. Kodak i5000
Series Scanners reliably deliver sharp results
reducing the need for quality assurance
checks or rescans.
• Clear, crisp images greatly enhance
optical character recognition (OCR),
intelligent document recognition (IDR)
and validation rates
• Get great results when you scan a mixture
of dierent-sized documents – from
business cards to 11" x 17", smooth or
messy – without changing settings
• Print important tracking information right
on your documents as they’re scanned
with optional front or rear side imprinter
accessories
With a wide range of speeds, features, and
connectivity, there’s an i5000 Scanner that
will help achieve your real-world throughput
goals and meet your business objectives.
• Easily integrate with your current
software and workflow
• i5250/i5250V and i5650/i5650V
models are placed on a desktop for
easy use
• i5250V and i5650V models are
available with Kofax OEM
VirtualReScan (VRS) Professional
connectivity onboard
The i5850 Scanner is a floor standing
model and a major advance in the art
of ergonomically friendly production
scanning.
• Image addressing permits reading
of patch codes so sequential
numbers can be applied to each
document scanned and each batch
accurately tracked
• Simultaneous three-pocket sorting
delivers flexible document separation
to save time and streamline sorting –
works with your current software
Reliable scanners, reliable support
• Kodak i5000 Series Scanners oer
reliable performance because
they’re built with a rugged design and
steel-welded frame
• Get the best possible performance from
your scanners and software with a full
range of service and support contracts
available to protect your investment and
keep productivity at peak levels
• If you ever need help in a hurry,
count on world-class Alaris Services.
Connectivity Options
Kodak i5250V and i5650V Scanner models
come with Kofax OEM (VRS) Professional
software onboard, so you enjoy all of the
application connectivity, image enhancement,
and error resolution features that VRS
delivers at no added cost.
Optional software – enhance your
scanning solution
Alaris Info Input Solution
Alaris Info Input Solution is a fully
featured, powerful, browser-based
capture solution that allows users to
scan, import, index, convert and submit
documents from their centralized
mailroom, across remote locations /
departments or on the move. Alaris Info
Input Solution Transactional can capture
and index from within your own business
applications. And the Alaris Info Input
Solution Mobile option enables you to
capture on the go.
AlarisWorld.com/go/infoinput
➥
True productivity
evolved and
advanced
Over 99%
accuracy rate achieved by a service
bureau meeting short-term, multi-million
document volume goal
45 million
pages captured with i5000 Series Scanners,
providing doctors at a prestigious UK
hospital better access to patient
information for improved patient care
100,000
transaction documents processed
daily by a service bureau using a
Kodak i5650 Scanner to meet
mandated performance levels and
legal requirement for pages to be
returned in exact order
Kodak i5250/i5250V Scanner Kodak i5650/i5650V Scanner Kodak i5850 Scanner
Feature comparison
Throughput (200 and 300 dpi for
bitonal and color)
Interface Support i5250V/i5650V: Kofax OEM VRS Professional software
150 ppm 180 ppm 210 ppm
Shared features
Recommended Daily Volume No limit with i5000 Series Scanners
Scanning Technology CCD
Optical Resolution 600 dpi
Output Resolution 100 / 150 / 200 / 240 / 300 / 400 / 500 / 600 dpi
Illumination White LEDs
Maximum Document Width 304.8 mm (12 in.)
Long Document Mode Length i5250/i5650/i5850: Up to 4.6 m (180 in.); i5250V/i5650V: Up to 1 m (40 in.)
Minimum Document Size 63.5 mm x 63.5 mm (2.5 in. x 2.5 in.)
Paper Thickness and Weight With standard feeder: 45 g/m
rice paper to 80 g/m
Feeder/Elevator Automatic 750-sheet elevator design; automatic document feeder with four settings: continuous feed, 100-sheet, 250-sheet,
500-sheet and full 750-sheet batches
Multi-feed Detection 5 independent ultrasonic zones
Connectivity USB 2.0 Certified, USB 3.0 compatible
Software Support Standard Software - WINDOWS bundled software: TWAIN, ISIS, WIA Drivers. Kofax certified.
Optional Software: Alaris Capture Pro Software, Alaris Info Input Solution (Windows only), Asset Management Software
Features in the Scanner Features specific to the i5250/i5650/i5850 models: Alaris Perfect Page Technology, enhanced jam recovery, streak filter,
iThresholding, aggressive crop, multi-color dropout, and dual-stream scanning. Features common to all models in the i5000 Series:
Barcode reading in the scanner, rear exit, digital printing, staple detection, image merge, rear side printer, Intelligent Imprinting
(hardware patch counting), controlled stacking, automatic color detection, autocrop, deskew, content-based blank page detection
and deletion, automatic orientation now with defaults, color on the fly toggle patch, operator overrides, Interactive multi-feed host
view, intelligent document protection
Image Addressing Via Sensors (i5850) Multi-level indexing/batching capabilities
Output Compression CCITT Group IV; JPEG or uncompressed output
Warranty (US and Canada) 90 days on-site
Electrical Requirements 100-240 V (international), 50/60 Hz
Power Consumption i5250/i5650: Sleep Mode: < 3.5 watts; Running: < 215 watts; Standby: <0.5 watt
i5250V/i5650V: Sleep Mode: < 5.5 watts; Running: < 205 watts; Standby: <1.0 watt
i5850: Sleep Mode: < 3.5 watts; Running: < 220 watts; Standby: <0.5 watt
Environmental Factors ENERGY STAR qualified scanners, 2008 EuP
Acoustical Noise
(operator position sound pressure level)
i5250/i5650: Standby mode: <39 dB(A); Scanning at 300 dpi <56 dB(A);
i5850: <44 dB(A); Scanning at 300 dpi <64 dB(A)
Recommended PC Configuration i5250/i5650/i5850: PC: Intel C ore i5 (Sandy Bridge or newer), running at 2.7 GHz or higher; USB port 3.0 (Super speed) or
2.0 (High Speed); 4 GB RAM or more
i5250V/i5650V: PC: Int el Qua d Core i5 (Ivy Bridge or newer), running at 3.0 GHz or higher; USB port 3.0
(Super speed) or 2.0 (High Speed); 4 GB RAM or more
Supported Operating Systems Windows 10 (32-bit and 64-bit); Windows 8 (32-bit and 64-bit); Windows 7 (32-bit and 64-bit);
Wind ows XP (TWAIN only) (customer validated – not supported by Kodak Alaris because Micros oft discontinued support in 2014)
Consumables Available Feeder consumables kits, imaging guide set, printer ink cartridge and carrier, transport cleaning sheets, roller cleaning pads,
printer ink blotters, Staticide Wipes, switchable black/white background
Accessories/Options i5250/i5250V/i5650/i5650V/i5850: Enhanced Printer Accessory for Kodak Scanners (front pre-scan and rear post-scan), Lead
Edge Alignment exit tray, i5200 to i5600 upgrade, manual feed shelf, Document Extenders 66.04 cm, 76.02 cm and 86.36 cm (26
in., 30 in. and 34 in.) Kodak Legal Size Flatbed Accessory and the Kodak A3 Flatbed Accessory are available to support all models
Dimensions i5250/i5250V/i5650/i5650V: Height: 43.4 cm (17.1 in.), Width: 69.3 cm (27.3 in.), Depth: 51 cm (20.1 in.) with tray closed, 65.3 cm
(25.7 in.) with tray open i5850: Height: 106.7 cm (42 in.) – 130.8 cm (51.5 in.), Width: 69.3 cm (27.3 in.), Depth: 82.3 cm (32.4 in.)
Weight i5250/i5250V/i5650/i5650V: 57.6 kg (127 lbs.) i5850: 186 kg (410 lbs.)
2
(12 lb.) bond to 200 g/m2 (110 lb.) index. With ultra-lightweight feeder accessory: 25 g/m2 (7 lb.)
2
(20 lb.) bond
